Resolved cannot install catalina error restoring bases system volume is formatted as HSF+

[Serendipity823]

Trying to follow this tutorial

How to install macOS Catalina on an unsupported Mac

Learn how to install macOS Catalina on an unsupported Mac with a non-Metal compatible graphics card, using macOS Catalina Patcher tool.

wccftech.com

Stuck at step 5.

When I run the option for bootable installer it begins patching. It takes a few moments to load and then I get the attached error message.

View attachment 916322

Below is the log info. Assistance appreciated.


Mounting BaseSystem.dmg...

/dev/disk4 GUID_partition_scheme
/dev/disk4s1 Apple_HFS /private/tmp/basesystem


Patching BaseSystem.dmg...

"disk4" unmounted.
"disk4" ejected.
Preparing imaging engine…
Reading Protective Master Boot Record (MBR : 0)…
(CRC32 $05BD9B8F: Protective Master Boot Record (MBR : 0))
Reading GPT Header (Primary GPT Header : 1)…
(CRC32 $0B9401A9: GPT Header (Primary GPT Header : 1))
Reading GPT Partition Data (Primary GPT Table : 2)…
(CRC32 $DFDDEEE9: GPT Partition Data (Primary GPT Table : 2))
Reading (Apple_Free : 3)…
(CRC32 $00000000: (Apple_Free : 3))
Reading disk image (Apple_HFS : 4)…
(CRC32 $A89F7555: disk image (Apple_HFS : 4))
Reading (Apple_Free : 5)…
(CRC32 $00000000: (Apple_Free : 5))
Reading GPT Partition Data (Backup GPT Table : 6)…
(CRC32 $DFDDEEE9: GPT Partition Data (Backup GPT Table : 6))
Reading GPT Header (Backup GPT Header : 7)…
(CRC32 $0A9BF70B: GPT Header (Backup GPT Header : 7))
Adding resources…
Elapsed Time: 12.978s
File size: 713588907 bytes, Checksum: CRC32 $616B497C
Sectors processed: 4189376, 3590164 compressed
Speed: 135.1Mbytes/sec
Savings: 66.7%
created: /private/tmp/BaseSystem.dmg


Restoring BaseSystem.dmg...

Validating target...done
Validating source...done
Could not unmount volume "/Volumes/MCRCNTR16GB" (Resource busy)

View attachment 916413



[chabig]

Reformat the USB stick using the GUID partition map, not Master Boot Record (Macs us GUID. PCs use MBR). Then start over from the instructions.



[Serendipity823]

It was done as an HSF+ volume shown in attachment 916413. I solved the running bootable installer and unmounting issue by using two USBs. One USB to host the catalina installer and the other to target for creation of the bootable install.



[txuss32]

Hi all,

Just tried running @dosdude1 Catalina patch - Im using a MP 3,1 running Mojave (per Dosdude1 patch) and after following all steps and getting to apply post install patches I get a message saying "There's no valid install of catalina on the selected drive..." but there is... Would you recommend starting from the beginning and following all steps again?..
