BerndL

macrumors newbie
Original poster
Sep 12, 2022
8
1
Hi there,
I have successfully installed Windows 10 onto a separate SSD in Mac Pro 2012.
Details as follows:
Mac OS: Mojave, version 10.14.6 installed on HDD - GPT - Mac OS Extended Journaled - Drive Bay 3
Windows OS: Windows 10 Legacy version 20H2 installed on SSD (SATA 860 EVO) - MBR - NTFS - Drive Bay 4
BootRom: 144.0.0.0.0
GPU = Radeon RX570, as such I have no Boot Screen
Procedure to install:

created a DVD with version 1803
used Brigadier to get the Apple drivers and Bootcamp control panel

upgraded Windows to version 20H2
upgraded AMD drivers
used Brigadier again for Apple drivers and Bootcamp control panel

To play safe, I installed Legacy option for Windows and don't want to use Open Core.

While I can access and change the startup Drive in the Bootcamp Control Panel, my System always starts in Windows, even if I select Mac OS.

What am I doing wrong? Does the Mac OS and the Windows have to be installed on the same drive for Bootcamp to work?

Any advice very much appreciated.

Cheers Bernd


tsialex

Contributor
Jun 13, 2016
13,459
13,608
Hi there,
I have successfully installed Windows 10 onto a separate SSD in Mac Pro 2012.
Details as follows:
Mac OS: Mojave, version 10.14.6 installed on HDD - GPT - Mac OS Extended Journaled - Drive Bay 3
Windows OS: Windows 10 Legacy version 20H2 installed on SSD (SATA 860 EVO) - MBR - NTFS - Drive Bay 4
BootRom: 144.0.0.0.0
GPU = Radeon RX570, as such I have no Boot Screen
Procedure to install:

created a DVD with version 1803
used Brigadier to get the Apple drivers and Bootcamp control panel

upgraded Windows to version 20H2
upgraded AMD drivers
used Brigadier again for Apple drivers and Bootcamp control panel

To play safe, I installed Legacy option for Windows and don't want to use Open Core.

While I can access and change the startup Drive in the Bootcamp Control Panel, my System always starts in Windows, even if I select Mac OS.

What am I doing wrong? Does the Mac OS and the Windows have to be installed on the same drive for Bootcamp to work?

Any advice very much appreciated.

Cheers Bernd

Windows boot coups can be solved with a continuous NVRAM reset, unless you already have a corrupted NVRAM.

Start by physically removing the Windows disk from your Mac Pro and then try to reset at least four times consecutively, from a wired keyboard, only let CMD-Option-P-R keys go after the 5th chime.

After reset is done, you can install back your Windows disk and check if it's working as expected.

Definitively not, this is a Mac Pro, not a MacBook.


BerndL

macrumors newbie
Original poster
Sep 12, 2022
8
1
Thanks tsialex,
There was some erratic behavior on my machine that is gone after the reset of the NVRAM. Thank you for that :)
Is is a good idea to reset NVRAM from time to time (even if there are no issues)?

Unfortunately, Windows is still not able to initiate a boot into Mac OS. The system can see the Mac Drive, I can select it, but it will stubbornly stick to Windows.

AppleControlPanel.exe is Version 6.1.7800.4
AppleOSSMgr.exe is Version 6.1.7600.0


macguru9999

macrumors 6502a
Aug 9, 2006
817
387
pull the windows drive and force it to boot off macos. then select mac in the osx control panel as your boot drive.


BerndL

macrumors newbie
Original poster
Sep 12, 2022
8
1
Thanks macguru9999,
I am working predominantly with Windows. But from time to time, I want to switch back to Mac OS. Pulling the windows drive every time I want to switch back is no fun. And since I read that I should be able to switch after restart using Apple Control Panel from the Bootcamp utility in Windows to select my startup drive, it is becoming frustrating.


Dayo

macrumors 68020
Dec 21, 2018
2,257
1,279
You can install a boot manager such as RefindPlus to allow you select between Mac OS and Windows each time you boot. You can configure it to always boot one option unless you intervene or to wait for you to make a selection each time. RefindPlus is derived from rEFInd which can also be used, but rEFInd does not natively support RX 570 on cMP.

You say you don't want to use OpenCore so you can follow instructions on installing RefindPlus on its GitHub page but it might however be easier to use MyBootMgr, (linked in my signature below).

This will set both RefindPlus and OpenCore up. You can keep and try OpenCore in this case and maybe you will see the virtues after this; but if you do indeed not want it at all, just delete the OpenCore folders it creates as well as the entries for running it in the RefindPlus config. These will be near the bottom of the RefindPlus config file.

I know you already have Windows but I find it better to have it installed Bare Metal (without BootCamp) as there are some irritations with BootCamp. Basically, the whole BootCamp setup is a nasty hack to make Windows work for Apple by setting up "HybridMBR" disks.

It might not be as bad with Mojave, but there are sometimes issues such as Spotlight indexing BootCamp forever and chewing up CPU cycles. You can read about other potential HybridMBR issues here: rodsbooks.com/gdisk/hybrid.html.

Bare Metal Windows might not be an option for you since you are already up and running with BootCamp though and the HybridMBR stuff might not be relevant for you either.

Last edited:
  • Like
Reactions: JedNZ

BerndL

macrumors newbie
Original poster
Sep 12, 2022
8
1
Thanks Dayo,
Very much appreciated, I may give it a thought.

But the questions remains: Is it possible to use the Bootcamp utility from Windows 10, i.e. select your startup disk if Windows is installed on its own drive instead of the hybrid MBR?

If so, what do I need to do to get it work?

I was under the impression that AppleControlPanel.exe is able to write into NVRAM. Or is it that AppleCotrolPanel.exe makes changes to the hybrid MBR partition and this in consequence will change the NVRAM? I am lost here.


Dayo

macrumors 68020
Dec 21, 2018
2,257
1,279
Sorry, I don't use BootCamp myself. Perhaps someone else would be able to chime in on that


tsialex

Contributor
Jun 13, 2016
13,459
13,608
BootCamp Windows control panel/applet can boot macOS without any trouble, dedicated disk or not. If it's not working you have something wrong with your BootROM.

It's easy to confirm or disprove, remove the Windows drive, boot macOS, go to SysPref/StartUp disk and select your macOS disk, reboot. Check if you can boot macOS, shutdown. Install your Windows disk again, power up.

If your Mac Pro boots Windows directly, you have a corrupt BootROM and will need a reconstruction service. This is relatively common with people that installed UEFI Windows in the past without OpenCore Windows SecureBoot protection/block.


JedNZ

macrumors 6502a
Dec 6, 2015
647
247
Deep South
Thanks Dayo,
Very much appreciated, I may give it a thought.

But the questions remains: Is it possible to use the Bootcamp utility from Windows 10, i.e. select your startup disk if Windows is installed on its own drive instead of the hybrid MBR?

If so, what do I need to do to get it work?

I was under the impression that AppleControlPanel.exe is able to write into NVRAM. Or is it that AppleCotrolPanel.exe makes changes to the hybrid MBR partition and this in consequence will change the NVRAM? I am lost here.

I first used BootCamp (Windows 7) on a partition in an iMac, but when I bought my first cMP 1,1 (which I upgraded to a 2,1) I copied the partition to a separate SSD - it was a long time ago but I remember there being much pain to get it to work. Since then, I upgraded to Windows 8.1 and then copied the SSD to a newer and bigger SSD, and then upgraded again to Windows 10 (found out the Windows 8.1 key I bought was bogus but Microsoft sorted it for me) and then 11 (which requires some modifications to upgrade).

Throughout my time, up to and including Windows 8.1 and including when I upgraded to a cMP 4.1>5,1 (but before RefindPlus|OpenCore chainloader), I used the BootCamp Control Panel to boot to macOS from Windows, and used Paragon's NTFS for Mac to boot from macOS to Windows. But with the awesome advent of MyBootMgr's chainloader setup, I don't have to do that any more - I simply select either an instance of OpenCore to run Mojave, BigSur or Monterey, or I boot natively to Mojave or Windows 11. For my usage it works perfectly, and is incredibly well supported by @Dayo and other's tireless work.

I have never used the BootCamp Control Panel since moving to RefindPlus|OpenCore chainloader. Well actually I did one time, by mistake, and I then had convoluted issues booting back to RefindPlus: Remove my Windows SSD > boot natively into Mojave RecoveryHD > disable SIP > boot back into Mojave and used Terminal to firm bless my RefindPlus boot EFI ESP thingy).


eicca

Suspended
Oct 23, 2014
1,773
3,605
But the questions remains: Is it possible to use the Bootcamp utility from Windows 10, i.e. select your startup disk if Windows is installed on its own drive instead of the hybrid MBR?

I don't know why others are saying this isn't possible, I did it all the time before I set up RefindPlus.

You're talking about right-clicking the Boot Camp Assistant icon in the task bar and choosing macOS as the startup disk from there, right?

I did it on the daily. Win 10 on an SSD in SATA bay 2, macOS 10.14 on an SSD in SATA bay 1.
