M1 Air keeps crashing

BootLoxes

BootLoxes

macrumors 6502a
Original poster
Apr 15, 2019
749
897
It happens randomly where the screen will turn purple and then it restarts. I have no idea how to stop it.

It happens every 2 or so days
Code:
panic(cpu 0 caller 0xfffffe001e6cc4c4): "dart-disp0 (0xfffffe23366f4000): SMMU(SMMU) error: SID 0 PTE invalid exception on read with DVA 0x3694000 (TTBR 0 SEG 0x1 PTE 0x5a5) ERROR_STATUS 0x80000004 TIME 0x15b093605538 TTE 0 AXI_ID 0)"
Debugger message: panic
Memory ID: 0x6
OS release type: User
OS version: 20D91
Kernel version: Darwin Kernel Version 20.3.0: Thu Jan 21 00:06:51 PST 2021; root:xnu-7195.81.3~1/RELEASE_ARM64_T8101
Fileset Kernelcache UUID: F78A48EC84D7C3283E7C6C67D00889A7
Kernel UUID: 9FE8C0DA-8ED0-381C-9CEC-2A779F3E1503
iBoot version: iBoot-6723.81.1
secure boot?: YES
Paniclog version: 13
KernelCache slide: 0x0000000015524000
KernelCache base:  0xfffffe001c528000
Kernel slide:      0x0000000016058000
Kernel text base:  0xfffffe001d05c000
Kernel text exec base:  0xfffffe001d124000
mach_absolute_time: 0x85430a440b
Epoch Time:        sec       usec
  Boot    : 0x60670c1a 0x000a7fa8
  Sleep   : 0x606a2c8e 0x000af820
  Wake    : 0x606a2d9c 0x00060ec4
  Calendar: 0x606a43b9 0x000d2c02

CORE 0 recently retired instr at 0xfffffe001d28d748
CORE 1 recently retired instr at 0xfffffe001d28ec0c
CORE 2 recently retired instr at 0xfffffe001d28ec0c
CORE 3 recently retired instr at 0xfffffe001d28ec0c
CORE 4 recently retired instr at 0xfffffe001d28ec10
CORE 5 recently retired instr at 0xfffffe001d28ec10
CORE 6 recently retired instr at 0xfffffe001d28ec10
CORE 7 recently retired instr at 0xfffffe001d28ec10
Panicked task 0xfffffe166f3d4000: 4484 pages, 20 threads: pid 349: WindowServer
Panicked thread: 0xfffffe166f25c000, backtrace: 0xfffffe301587b4e0, tid: 3110
          lr: 0xfffffe001d171fd0  fp: 0xfffffe301587b550
          lr: 0xfffffe001d171d9c  fp: 0xfffffe301587b5c0
          lr: 0xfffffe001d293f0c  fp: 0xfffffe301587b5e0
          lr: 0xfffffe001d2858b8  fp: 0xfffffe301587b690
          lr: 0xfffffe001d12b7e8  fp: 0xfffffe301587b6a0
          lr: 0xfffffe001d171a2c  fp: 0xfffffe301587ba30
          lr: 0xfffffe001d171a2c  fp: 0xfffffe301587baa0
          lr: 0xfffffe001d90c65c  fp: 0xfffffe301587bac0
          lr: 0xfffffe001e6cc4c4  fp: 0xfffffe301587bae0
          lr: 0xfffffe001e6c90e0  fp: 0xfffffe301587bd40
          lr: 0xfffffe001e6c8c1c  fp: 0xfffffe301587bdd0
          lr: 0xfffffe001e6c8470  fp: 0xfffffe301587be80
          lr: 0xfffffe001d843284  fp: 0xfffffe301587bec0
          lr: 0xfffffe001d877778  fp: 0xfffffe301587bf20
          lr: 0xfffffe001e27e808  fp: 0xfffffe301587bfb0
          lr: 0xfffffe001d869694  fp: 0xfffffe301587bfc0
          lr: 0xfffffe001d2881bc  fp: 0xfffffe301587bfe0
          lr: 0xfffffe001d12b85c  fp: 0xfffffe301587bff0
      Kernel Extensions in backtrace:
         com.apple.driver.AppleT8020DART(1.0)[8CE20231-0416-310B-BFA4-3861C14A7C0F]@0xfffffe001e6c4000->0xfffffe001e6cffff
            dependency: com.apple.driver.AppleARMPlatform(1.0.2)[53D29C42-BCB1-384D-BE79-DAB9ED503C6C]@0xfffffe001da64000->0xfffffe001daaffff
            dependency: com.apple.driver.IODARTFamily(1)[AC191CE6-9C7A-3BDC-B2C9-E077ADE86866]@0xfffffe001f1a0000->0xfffffe001f1b3fff
         com.apple.driver.AppleInterruptController(1.0d1)[B5629E50-71D8-3336-9FEB-315F74FD0954]@0xfffffe001e27c000->0xfffffe001e27ffff
            dependency: com.apple.driver.AppleARMPlatform(1.0.2)[53D29C42-BCB1-384D-BE79-DAB9ED503C6C]@0xfffffe001da64000->0xfffffe001daaffff

last started kext at 178073152184: com.apple.driver.AppleXsanScheme    3 (addr 0xfffffe001cb5c000, size 16384)
last stopped kext at 202274964460: com.apple.driver.AppleXsanScheme    3 (addr 0xfffffe001cb5c000, size 16384)
loaded kexts:
com.apple.filesystems.autofs    3.0
com.apple.fileutil    20.036.15
com.apple.driver.AppleTopCaseHIDEventDriver    4030.5
com.apple.iokit.IOBluetoothSerialManager    8.0.3d9
com.apple.driver.AppleBiometricServices    1
com.apple.driver.usb.AppleUSBHostBillboardDevice    1.0
com.apple.driver.AppleALSColorSensor    1.0.0d1
com.apple.driver.AppleAOPVoiceTrigger    11.5
com.apple.driver.BCMWLANFirmware4378.Hashstore    1
com.apple.driver.CoreKDL    1
com.apple.driver.SEPHibernation    1
com.apple.driver.AppleUSBDeviceNCM    5.0.0
com.apple.driver.AppleThunderboltIP    4.0.3
com.apple.filesystems.apfs    1677.81.1
com.apple.driver.AppleSmartBatteryManager    161.0.0
com.apple.nke.l2tp    1.9
com.apple.filesystems.tmpfs    1
com.apple.driver.ApplePMP    1
com.apple.driver.AppleCS42L83Audio    437.96
com.apple.driver.ApplePMPFirmware    1
com.apple.IOTextEncryptionFamily    1.0.0
com.apple.driver.AppleSmartIO2    1
com.apple.filesystems.hfs.kext    556.60.1
com.apple.security.BootPolicy    1
com.apple.BootCache    40
com.apple.AppleFSCompression.AppleFSCompressionTypeZlib    1.0.0
com.apple.AppleFSCompression.AppleFSCompressionTypeDataless    1.0.0d1
com.apple.driver.AppleTAS5770LAmp    437.96
com.apple.AGXG13G    172.26.2
com.apple.driver.AppleDPDisplayTCON    1
com.apple.AppleEmbeddedSimpleSPINORFlasher    1
com.apple.driver.AppleAVD    376
com.apple.driver.AppleJPEGDriver    4.6.0
com.apple.driver.AppleSPMIPMU    1.0.1
com.apple.driver.AppleAVE2    401.63.3
com.apple.driver.AppleT8020SOCTuner    1
com.apple.driver.AppleT8103CLPCv3    1
com.apple.driver.AppleMobileDispH13G-DCP    140.0
com.apple.driver.usb.AppleUSBHostT8103    1
com.apple.driver.AudioDMAController-T8103    1.59
com.apple.driver.AppleS5L8960XNCO    1
com.apple.driver.AppleT8103PMGR    1
com.apple.driver.AppleS8000AES    1
com.apple.driver.AppleS8000DWI    1.0.0d1
com.apple.driver.AppleS5L8960XWatchDogTimer    1
com.apple.driver.AppleInterruptController    1.0.0d1
com.apple.driver.AppleT8020DART    1
com.apple.driver.AppleBluetoothModule    1
com.apple.driver.AppleSamsungSerial    1.0.0d1
com.apple.driver.AppleBCMWLANBusInterfacePCIe    1
com.apple.driver.AppleS5L8920XPWM    1.0.0d1
com.apple.driver.AppleS5L8940XI2C    1.0.0d2
com.apple.driver.AppleSPIMC    1
com.apple.driver.AppleM68Buttons    1.0.0d1
com.apple.driver.AppleT8101    1
com.apple.iokit.IOUserEthernet    1.0.1
com.apple.iokit.IOKitRegistryCompatibility    1
com.apple.iokit.EndpointSecurity    1
com.apple.driver.AppleDiskImages2    1
com.apple.AppleSystemPolicy    2.0.0
com.apple.nke.applicationfirewall    310
com.apple.kec.InvalidateHmac    1
com.apple.vecLib.kext    1.2.0
com.apple.kext.triggers    1.0
com.apple.driver.AppleActuatorDriver    4400.28
com.apple.driver.AppleHIDKeyboard    223
com.apple.driver.AppleMultitouchDriver    4400.28
com.apple.driver.AppleHSBluetoothDriver    4030.5
com.apple.driver.IOBluetoothHIDDriver    8.0.3d9
com.apple.iokit.IOAVBFamily    930.1
com.apple.plugin.IOgPTPPlugin    900.11
com.apple.iokit.IOEthernetAVBController    1.1.0
com.apple.driver.AppleMesaSEPDriver    100.99
com.apple.iokit.IOBiometricFamily    1
com.apple.driver.AppleAOPAudio    14.32
com.apple.driver.AppleSEPHDCPManager    1.0.1
com.apple.iokit.AppleSEPGenericTransfer    1
com.apple.driver.usb.networking    5.0.0
com.apple.driver.AppleThunderboltDPInAdapter    8.1.4
com.apple.driver.AppleThunderboltDPAdapterFamily    8.1.4
com.apple.driver.AppleThunderboltUSBDownAdapter    1.0.4
com.apple.driver.AppleThunderboltPCIDownAdapter    4.1.1
com.apple.driver.IOBluetoothHostControllerPCIeTransport    8.0.3d9
com.apple.iokit.IOBluetoothHostControllerTransport    8.0.3d9
com.apple.driver.AppleBTM    1.0.1
com.apple.driver.AppleConvergedIPCOLYBTControl    1
com.apple.driver.AppleConvergedPCI    1
com.apple.driver.AppleBluetoothDebug    1
com.apple.driver.AppleDCPDPTXProxy    1.0.0
com.apple.AGXFirmwareKextG13GRTBuddy    172.26.2
com.apple.AGXFirmwareKextRTBuddy64    172.26.2
com.apple.nke.ppp    1.9
com.apple.driver.DCPDPFamilyProxy    1
com.apple.driver.AppleHIDTransportSPI    4400.35
com.apple.driver.AppleHIDTransport    4400.35
com.apple.driver.AppleInputDeviceSupport    4400.35
com.apple.driver.AppleCSEmbeddedAudio    437.96
com.apple.driver.AppleSPU    1
com.apple.driver.AppleBSDKextStarter    3
com.apple.filesystems.hfs.encodings.kext    1
com.apple.driver.AppleHPM    3.4.4
com.apple.driver.AppleEmbeddedAudio    437.96
com.apple.iokit.AppleARMIISAudio    80.34
com.apple.iokit.IOGPUFamily    20.23
com.apple.driver.AppleDiagnosticDataAccessReadOnly    1.0.0
com.apple.iokit.IONVMeFamily    2.1.0
com.apple.driver.AppleNANDConfigAccess    1.0.0
com.apple.driver.AppleStockholmControl    1.0.0
com.apple.driver.AppleDialogPMU    1.0.1
com.apple.driver.AppleH13CameraInterface    2.82.0
com.apple.driver.AppleH10PearlCameraInterface    14.70.0
com.apple.driver.AppleH11ANEInterface    4.52.0
com.apple.driver.ApplePassthroughPPM    3.0
com.apple.driver.DCPAVFamilyProxy    1
com.apple.iokit.IOMobileGraphicsFamily-DCP    343.0.0
com.apple.driver.AppleDCP    1
com.apple.driver.AppleFirmwareKit    1
com.apple.iokit.IOMobileGraphicsFamily    343.0.0
com.apple.driver.AppleSPMI    1.0.1
com.apple.driver.AppleUSBXDCIARM    1.0
com.apple.driver.AppleUSBXDCI    1.0
com.apple.iokit.IOUSBDeviceFamily    2.0.0
com.apple.driver.usb.AppleUSBXHCIARM    1
com.apple.driver.usb.AppleUSBXHCI    1.2
com.apple.driver.AppleEmbeddedUSBHost    1
com.apple.driver.usb.AppleUSBHub    1.2
com.apple.driver.usb.AppleUSBHostCompositeDevice    1.2
com.apple.driver.AppleT8103TypeCPhy    1
com.apple.driver.AppleSART    1
com.apple.driver.ApplePMGR    1
com.apple.driver.watchdog    1
com.apple.driver.AppleDisplayCrossbar    1.0.0
com.apple.iokit.IODisplayPortFamily    1.0.0
com.apple.driver.AppleTypeCPhy    1
com.apple.driver.AppleThunderboltNHI    7.2.8
com.apple.driver.AppleT8103PCIeC    1
com.apple.iokit.IOThunderboltFamily    9.3.2
com.apple.driver.ApplePIODMA    1
com.apple.driver.AppleT8103PCIe    1
com.apple.driver.AppleBluetoothDebugService    1
com.apple.driver.AppleBCMWLANCore    1.0.0
com.apple.iokit.IO80211FamilyV2    1200.12.2b1
com.apple.driver.IOImageLoader    1.0.0
com.apple.driver.AppleMCA2-T8103    510.72
com.apple.driver.AppleGPIOICController    1.0.2
com.apple.driver.AppleMobileApNonce    1
com.apple.driver.AppleFireStormErrorHandler    1
com.apple.driver.AppleMultiFunctionManager    1
com.apple.driver.corecapture    1.0.4
com.apple.driver.AppleEmbeddedPCIE    1
com.apple.iokit.IOTimeSyncFamily    900.11
com.apple.driver.DiskImages    493.0.0
com.apple.iokit.IOGraphicsFamily    585
com.apple.iokit.IOBluetoothFamily    8.0.3d9
com.apple.iokit.IOBluetoothPacketLogger    8.0.3d9
com.apple.driver.FairPlayIOKit    68.6.0
com.apple.iokit.CoreAnalyticsFamily    1
com.apple.driver.AppleSSE    1.0
com.apple.driver.AppleSEPKeyStore    2
com.apple.driver.AppleUSBTDM    511.60.2
com.apple.iokit.IOUSBMassStorageDriver    184.40.6
com.apple.iokit.IOPCIFamily    2.9
com.apple.iokit.IOSCSIBlockCommandsDevice    436.40.6
com.apple.iokit.IOSCSIArchitectureModelFamily    436.40.6
com.apple.driver.AppleIPAppender    1.0
com.apple.driver.AppleFDEKeyStore    28.30
com.apple.driver.AppleEffaceableStorage    1.0
com.apple.driver.AppleCredentialManager    1.0
com.apple.driver.KernelRelayHost    1
com.apple.iokit.IOUSBHostFamily    1.2
com.apple.driver.AppleUSBHostMergeProperties    1.2
com.apple.driver.usb.AppleUSBCommon    1.0
com.apple.driver.AppleSMC    3.1.9
com.apple.driver.RTBuddy    1.0.0
com.apple.driver.AppleEmbeddedTempSensor    1.0.0
com.apple.driver.AppleARMPMU    1.0
com.apple.iokit.IOAccessoryManager    1.0.0
com.apple.driver.AppleOnboardSerial    1.0
com.apple.iokit.IOSkywalkFamily    1
com.apple.driver.mDNSOffloadUserClient    1.0.1b8
com.apple.iokit.IONetworkingFamily    3.4
com.apple.iokit.IOSerialFamily    11
com.apple.driver.AppleSEPManager    1.0.1
com.apple.driver.AppleA7IOP    1.0.2
com.apple.driver.IOSlaveProcessor    1
com.apple.driver.AppleBiometricSensor    2
com.apple.iokit.IOHIDFamily    2.0.0
com.apple.AUC    1.0
com.apple.iokit.IOAVFamily    1.0.0
com.apple.iokit.IOHDCPFamily    1.0.0
com.apple.iokit.IOCECFamily    1
com.apple.iokit.IOAudio2Family    1.0
com.apple.driver.AppleEmbeddedAudioLibs    1.17
com.apple.driver.AppleFirmwareUpdateKext    1
com.apple.driver.AppleM2ScalerCSCDriver    265.0.0
com.apple.iokit.IOSurface    289.3
com.apple.driver.IODARTFamily    1
com.apple.security.quarantine    4
com.apple.security.sandbox    300.0
com.apple.kext.AppleMatch    1.0.0d1
com.apple.driver.AppleMobileFileIntegrity    1.0.5
com.apple.kext.CoreTrust    1
com.apple.security.AppleImage4    3.0.0
com.apple.iokit.IOCryptoAcceleratorFamily    1.0.1
com.apple.driver.AppleARMPlatform    1.0.2
com.apple.iokit.IOStorageFamily    2.1
com.apple.iokit.IOSlowAdaptiveClockingFamily    1.0.0
com.apple.iokit.IOReportFamily    47
com.apple.kec.pthread    1
com.apple.kec.corecrypto    11.1
com.apple.kec.Libm    1



** Stackshot Succeeded ** Bytes Traced 313283 (Uncompressed 769440) **

Last edited by a moderator:
S

Significant1

macrumors 68000
Dec 20, 2014
1,686
780
Searching for dart-disp0 shows you are not the first, but didn't see any solution. If it is connected to anything, try disconnecting it and see if it still chrashes.

BootLoxes

BootLoxes

macrumors 6502a
Original poster
Apr 15, 2019
749
897
Significant1 said:
Searching for dart-disp0 shows you are not the first, but didn't see any solution. If it is connected to anything, try disconnecting it and see if it still chrashes.
Click to expand...
By connected do you mean physical and wireless or just physical?

xraydoc

xraydoc

Contributor
Oct 9, 2005
11,027
5,488
192.168.1.1
BootLoxes said:
By connected do you mean physical and wireless or just physical?
Click to expand...
Run it with nothing attached (physical or bluetooth; delete all paired BT devices, except for AirPods since those are tied to your iCloud account) and see if it crashes. If not, add devices back one by one until you see which is causing the crashes.
If it crashes with nothing attached, contact Apple Support for help reinstalling the operating system. If crashes persist after that, it's a hardware issue).

BootLoxes

BootLoxes

macrumors 6502a
Original poster
Apr 15, 2019
749
897
xraydoc said:
Run it with nothing attached (physical or bluetooth; delete all paired BT devices, except for AirPods since those are tied to your iCloud account) and see if it crashes. If not, add devices back one by one until you see which is causing the crashes.
If it crashes with nothing attached, contact Apple Support for help reinstalling the operating system. If crashes persist after that, it's a hardware issue).
Click to expand...
Rather than delete the bluetooth devices can I just turn off bluetooth? Also is using wifi ok or should I turn that off too?

xraydoc

xraydoc

Contributor
Oct 9, 2005
11,027
5,488
192.168.1.1
BootLoxes said:
Rather than delete the bluetooth devices can I just turn off bluetooth? Also is using wifi ok or should I turn that off too?
Click to expand...
You can turn BT off, but when you turn it back on, all your devices will re-connect, making it harder to figure out if one of those is the culprit. But you do what's best.
Can't hurt to test wifi as well.

S

Significant1

macrumors 68000
Dec 20, 2014
1,686
780
BootLoxes

BootLoxes

macrumors 6502a
Original poster
Apr 15, 2019
749
897
Alright I will bookmark this and go through the steps one at a time until I find something. I will update if it stops for those who run into this in the future

S

Significant1

macrumors 68000
Dec 20, 2014
1,686
780
BootLoxes said:
Alright I will bookmark this and go through the steps one at a time until I find something. I will update if it stops for those who run into this in the future
Click to expand...
Looking at your error-log again, I think is display related, because of disp0 and panicked task i WindowServer. I suppose disp0 is the internal display and an external display would be disp1, however it can also mean which one is the main display (you can change that by moving the menubar in screen setup in settings, when an external display is connected). Anyway, if you have an external display connected, I would try and see if the problem still occour if it is not connected.

Edit: Have been digging a bit more in your crashlog, just to get more confused. The first extension i the backtrace is com.apple.driver.AppleT8020DART, which is weird, because T8020 is actually the codename for A12, the M1 processor is called T8103
https://www.theiphonewiki.com/wiki/Application_Processor . I hope you are sending those logs to Apple.

Last edited:
Quackers

Quackers

macrumors 68000
Sep 18, 2013
1,938
708
Manchester, UK
I'm sure I read that T802DART was something to do with HDMI connected monitors. I don't know whether that was supposed, proven or later disproved, but it has been suspected previously.
Do you have a HDMI connected monitor? Or even a USB-C connected monitor?
As already stated above I'd unplug everything and see if it still crashes (I suspect it won't) then add things one by one until the crashes return.

BootLoxes

BootLoxes

macrumors 6502a
Original poster
Apr 15, 2019
749
897
Significant1 said:
Looking at your error-log again, I think is display related, because of disp0 and panicked task i WindowServer. I suppose disp0 is the internal display and an external display would be disp1, however it can also mean which one is the main display (you can change that by moving the menubar in screen setup in settings, when an external display is connected). Anyway, if you have an external display connected, I would try and see if the problem still occour if it is not connected.

Edit: Have been digging a bit more in your crashlog, just to get more confused. The first extension i the backtrace is com.apple.driver.AppleT8020DART, which is weird, because T8020 is actually the codename for A12, the M1 processor is called T8103
https://www.theiphonewiki.com/wiki/Application_Processor . I hope you are sending those logs to Apple.
Click to expand...

I dont remember if i replied to or made a thread about my m1 mac randomly disconnecting from my monitor for a second or two a few weeks back. Now I am starting to wonder if they are connected. Its connected via a usbc to hdmi cable. I bought it to avoid adapters.

So far no crashes since making the thread

MBAir2010

MBAir2010

macrumors 604
May 30, 2018
6,975
6,354
there
i have been reading this year that certain Monitors are impeding the M1's performance.
so dont feel bad, my advice would be to find one that works well with your MacBook air.

BootLoxes

BootLoxes

macrumors 6502a
Original poster
Apr 15, 2019
749
897
MtLoin2020 said:
i have been reading this year that certain Monitors are impeding the M1's performance.
so dont feel bad, my advice would be to find one that works well with your MacBook air.
Click to expand...

I have been considering getting one with USB C ports but I also use it for gaming and high refresh monitors dont come with those ports. Living in Japan I am in a shoebox so I can only fit one monitor in my home. Hopefully the answer to my prayers comes sooner rather than later. 4k 144hz monitor with displayport for my desktop and usb c for my air

E

eatingseeds

macrumors newbie
Apr 11, 2021
2
1
BootLoxes said:
It happens randomly where the screen will turn purple and then it restarts. I have no idea how to stop it.

It happens every 2 or so days
Code:
panic(cpu 0 caller 0xfffffe001e6cc4c4): "dart-disp0 (0xfffffe23366f4000): SMMU(SMMU) error: SID 0 PTE invalid exception on read with DVA 0x3694000 (TTBR 0 SEG 0x1 PTE 0x5a5) ERROR_STATUS 0x80000004 TIME 0x15b093605538 TTE 0 AXI_ID 0)"
Debugger message: panic
Memory ID: 0x6
OS release type: User
OS version: 20D91
Kernel version: Darwin Kernel Version 20.3.0: Thu Jan 21 00:06:51 PST 2021; root:xnu-7195.81.3~1/RELEASE_ARM64_T8101
Fileset Kernelcache UUID: F78A48EC84D7C3283E7C6C67D00889A7
Kernel UUID: 9FE8C0DA-8ED0-381C-9CEC-2A779F3E1503
iBoot version: iBoot-6723.81.1
secure boot?: YES
Paniclog version: 13
KernelCache slide: 0x0000000015524000
KernelCache base:  0xfffffe001c528000
Kernel slide:      0x0000000016058000
Kernel text base:  0xfffffe001d05c000
Kernel text exec base:  0xfffffe001d124000
mach_absolute_time: 0x85430a440b
Epoch Time:        sec       usec
  Boot    : 0x60670c1a 0x000a7fa8
  Sleep   : 0x606a2c8e 0x000af820
  Wake    : 0x606a2d9c 0x00060ec4
  Calendar: 0x606a43b9 0x000d2c02

CORE 0 recently retired instr at 0xfffffe001d28d748
CORE 1 recently retired instr at 0xfffffe001d28ec0c
CORE 2 recently retired instr at 0xfffffe001d28ec0c
CORE 3 recently retired instr at 0xfffffe001d28ec0c
CORE 4 recently retired instr at 0xfffffe001d28ec10
CORE 5 recently retired instr at 0xfffffe001d28ec10
CORE 6 recently retired instr at 0xfffffe001d28ec10
CORE 7 recently retired instr at 0xfffffe001d28ec10
Panicked task 0xfffffe166f3d4000: 4484 pages, 20 threads: pid 349: WindowServer
Panicked thread: 0xfffffe166f25c000, backtrace: 0xfffffe301587b4e0, tid: 3110
          lr: 0xfffffe001d171fd0  fp: 0xfffffe301587b550
          lr: 0xfffffe001d171d9c  fp: 0xfffffe301587b5c0
          lr: 0xfffffe001d293f0c  fp: 0xfffffe301587b5e0
          lr: 0xfffffe001d2858b8  fp: 0xfffffe301587b690
          lr: 0xfffffe001d12b7e8  fp: 0xfffffe301587b6a0
          lr: 0xfffffe001d171a2c  fp: 0xfffffe301587ba30
          lr: 0xfffffe001d171a2c  fp: 0xfffffe301587baa0
          lr: 0xfffffe001d90c65c  fp: 0xfffffe301587bac0
          lr: 0xfffffe001e6cc4c4  fp: 0xfffffe301587bae0
          lr: 0xfffffe001e6c90e0  fp: 0xfffffe301587bd40
          lr: 0xfffffe001e6c8c1c  fp: 0xfffffe301587bdd0
          lr: 0xfffffe001e6c8470  fp: 0xfffffe301587be80
          lr: 0xfffffe001d843284  fp: 0xfffffe301587bec0
          lr: 0xfffffe001d877778  fp: 0xfffffe301587bf20
          lr: 0xfffffe001e27e808  fp: 0xfffffe301587bfb0
          lr: 0xfffffe001d869694  fp: 0xfffffe301587bfc0
          lr: 0xfffffe001d2881bc  fp: 0xfffffe301587bfe0
          lr: 0xfffffe001d12b85c  fp: 0xfffffe301587bff0
      Kernel Extensions in backtrace:
         com.apple.driver.AppleT8020DART(1.0)[8CE20231-0416-310B-BFA4-3861C14A7C0F]@0xfffffe001e6c4000->0xfffffe001e6cffff
            dependency: com.apple.driver.AppleARMPlatform(1.0.2)[53D29C42-BCB1-384D-BE79-DAB9ED503C6C]@0xfffffe001da64000->0xfffffe001daaffff
            dependency: com.apple.driver.IODARTFamily(1)[AC191CE6-9C7A-3BDC-B2C9-E077ADE86866]@0xfffffe001f1a0000->0xfffffe001f1b3fff
         com.apple.driver.AppleInterruptController(1.0d1)[B5629E50-71D8-3336-9FEB-315F74FD0954]@0xfffffe001e27c000->0xfffffe001e27ffff
            dependency: com.apple.driver.AppleARMPlatform(1.0.2)[53D29C42-BCB1-384D-BE79-DAB9ED503C6C]@0xfffffe001da64000->0xfffffe001daaffff

last started kext at 178073152184: com.apple.driver.AppleXsanScheme    3 (addr 0xfffffe001cb5c000, size 16384)
last stopped kext at 202274964460: com.apple.driver.AppleXsanScheme    3 (addr 0xfffffe001cb5c000, size 16384)
loaded kexts:
com.apple.filesystems.autofs    3.0
com.apple.fileutil    20.036.15
com.apple.driver.AppleTopCaseHIDEventDriver    4030.5
com.apple.iokit.IOBluetoothSerialManager    8.0.3d9
com.apple.driver.AppleBiometricServices    1
com.apple.driver.usb.AppleUSBHostBillboardDevice    1.0
com.apple.driver.AppleALSColorSensor    1.0.0d1
com.apple.driver.AppleAOPVoiceTrigger    11.5
com.apple.driver.BCMWLANFirmware4378.Hashstore    1
com.apple.driver.CoreKDL    1
com.apple.driver.SEPHibernation    1
com.apple.driver.AppleUSBDeviceNCM    5.0.0
com.apple.driver.AppleThunderboltIP    4.0.3
com.apple.filesystems.apfs    1677.81.1
com.apple.driver.AppleSmartBatteryManager    161.0.0
com.apple.nke.l2tp    1.9
com.apple.filesystems.tmpfs    1
com.apple.driver.ApplePMP    1
com.apple.driver.AppleCS42L83Audio    437.96
com.apple.driver.ApplePMPFirmware    1
com.apple.IOTextEncryptionFamily    1.0.0
com.apple.driver.AppleSmartIO2    1
com.apple.filesystems.hfs.kext    556.60.1
com.apple.security.BootPolicy    1
com.apple.BootCache    40
com.apple.AppleFSCompression.AppleFSCompressionTypeZlib    1.0.0
com.apple.AppleFSCompression.AppleFSCompressionTypeDataless    1.0.0d1
com.apple.driver.AppleTAS5770LAmp    437.96
com.apple.AGXG13G    172.26.2
com.apple.driver.AppleDPDisplayTCON    1
com.apple.AppleEmbeddedSimpleSPINORFlasher    1
com.apple.driver.AppleAVD    376
com.apple.driver.AppleJPEGDriver    4.6.0
com.apple.driver.AppleSPMIPMU    1.0.1
com.apple.driver.AppleAVE2    401.63.3
com.apple.driver.AppleT8020SOCTuner    1
com.apple.driver.AppleT8103CLPCv3    1
com.apple.driver.AppleMobileDispH13G-DCP    140.0
com.apple.driver.usb.AppleUSBHostT8103    1
com.apple.driver.AudioDMAController-T8103    1.59
com.apple.driver.AppleS5L8960XNCO    1
com.apple.driver.AppleT8103PMGR    1
com.apple.driver.AppleS8000AES    1
com.apple.driver.AppleS8000DWI    1.0.0d1
com.apple.driver.AppleS5L8960XWatchDogTimer    1
com.apple.driver.AppleInterruptController    1.0.0d1
com.apple.driver.AppleT8020DART    1
com.apple.driver.AppleBluetoothModule    1
com.apple.driver.AppleSamsungSerial    1.0.0d1
com.apple.driver.AppleBCMWLANBusInterfacePCIe    1
com.apple.driver.AppleS5L8920XPWM    1.0.0d1
com.apple.driver.AppleS5L8940XI2C    1.0.0d2
com.apple.driver.AppleSPIMC    1
com.apple.driver.AppleM68Buttons    1.0.0d1
com.apple.driver.AppleT8101    1
com.apple.iokit.IOUserEthernet    1.0.1
com.apple.iokit.IOKitRegistryCompatibility    1
com.apple.iokit.EndpointSecurity    1
com.apple.driver.AppleDiskImages2    1
com.apple.AppleSystemPolicy    2.0.0
com.apple.nke.applicationfirewall    310
com.apple.kec.InvalidateHmac    1
com.apple.vecLib.kext    1.2.0
com.apple.kext.triggers    1.0
com.apple.driver.AppleActuatorDriver    4400.28
com.apple.driver.AppleHIDKeyboard    223
com.apple.driver.AppleMultitouchDriver    4400.28
com.apple.driver.AppleHSBluetoothDriver    4030.5
com.apple.driver.IOBluetoothHIDDriver    8.0.3d9
com.apple.iokit.IOAVBFamily    930.1
com.apple.plugin.IOgPTPPlugin    900.11
com.apple.iokit.IOEthernetAVBController    1.1.0
com.apple.driver.AppleMesaSEPDriver    100.99
com.apple.iokit.IOBiometricFamily    1
com.apple.driver.AppleAOPAudio    14.32
com.apple.driver.AppleSEPHDCPManager    1.0.1
com.apple.iokit.AppleSEPGenericTransfer    1
com.apple.driver.usb.networking    5.0.0
com.apple.driver.AppleThunderboltDPInAdapter    8.1.4
com.apple.driver.AppleThunderboltDPAdapterFamily    8.1.4
com.apple.driver.AppleThunderboltUSBDownAdapter    1.0.4
com.apple.driver.AppleThunderboltPCIDownAdapter    4.1.1
com.apple.driver.IOBluetoothHostControllerPCIeTransport    8.0.3d9
com.apple.iokit.IOBluetoothHostControllerTransport    8.0.3d9
com.apple.driver.AppleBTM    1.0.1
com.apple.driver.AppleConvergedIPCOLYBTControl    1
com.apple.driver.AppleConvergedPCI    1
com.apple.driver.AppleBluetoothDebug    1
com.apple.driver.AppleDCPDPTXProxy    1.0.0
com.apple.AGXFirmwareKextG13GRTBuddy    172.26.2
com.apple.AGXFirmwareKextRTBuddy64    172.26.2
com.apple.nke.ppp    1.9
com.apple.driver.DCPDPFamilyProxy    1
com.apple.driver.AppleHIDTransportSPI    4400.35
com.apple.driver.AppleHIDTransport    4400.35
com.apple.driver.AppleInputDeviceSupport    4400.35
com.apple.driver.AppleCSEmbeddedAudio    437.96
com.apple.driver.AppleSPU    1
com.apple.driver.AppleBSDKextStarter    3
com.apple.filesystems.hfs.encodings.kext    1
com.apple.driver.AppleHPM    3.4.4
com.apple.driver.AppleEmbeddedAudio    437.96
com.apple.iokit.AppleARMIISAudio    80.34
com.apple.iokit.IOGPUFamily    20.23
com.apple.driver.AppleDiagnosticDataAccessReadOnly    1.0.0
com.apple.iokit.IONVMeFamily    2.1.0
com.apple.driver.AppleNANDConfigAccess    1.0.0
com.apple.driver.AppleStockholmControl    1.0.0
com.apple.driver.AppleDialogPMU    1.0.1
com.apple.driver.AppleH13CameraInterface    2.82.0
com.apple.driver.AppleH10PearlCameraInterface    14.70.0
com.apple.driver.AppleH11ANEInterface    4.52.0
com.apple.driver.ApplePassthroughPPM    3.0
com.apple.driver.DCPAVFamilyProxy    1
com.apple.iokit.IOMobileGraphicsFamily-DCP    343.0.0
com.apple.driver.AppleDCP    1
com.apple.driver.AppleFirmwareKit    1
com.apple.iokit.IOMobileGraphicsFamily    343.0.0
com.apple.driver.AppleSPMI    1.0.1
com.apple.driver.AppleUSBXDCIARM    1.0
com.apple.driver.AppleUSBXDCI    1.0
com.apple.iokit.IOUSBDeviceFamily    2.0.0
com.apple.driver.usb.AppleUSBXHCIARM    1
com.apple.driver.usb.AppleUSBXHCI    1.2
com.apple.driver.AppleEmbeddedUSBHost    1
com.apple.driver.usb.AppleUSBHub    1.2
com.apple.driver.usb.AppleUSBHostCompositeDevice    1.2
com.apple.driver.AppleT8103TypeCPhy    1
com.apple.driver.AppleSART    1
com.apple.driver.ApplePMGR    1
com.apple.driver.watchdog    1
com.apple.driver.AppleDisplayCrossbar    1.0.0
com.apple.iokit.IODisplayPortFamily    1.0.0
com.apple.driver.AppleTypeCPhy    1
com.apple.driver.AppleThunderboltNHI    7.2.8
com.apple.driver.AppleT8103PCIeC    1
com.apple.iokit.IOThunderboltFamily    9.3.2
com.apple.driver.ApplePIODMA    1
com.apple.driver.AppleT8103PCIe    1
com.apple.driver.AppleBluetoothDebugService    1
com.apple.driver.AppleBCMWLANCore    1.0.0
com.apple.iokit.IO80211FamilyV2    1200.12.2b1
com.apple.driver.IOImageLoader    1.0.0
com.apple.driver.AppleMCA2-T8103    510.72
com.apple.driver.AppleGPIOICController    1.0.2
com.apple.driver.AppleMobileApNonce    1
com.apple.driver.AppleFireStormErrorHandler    1
com.apple.driver.AppleMultiFunctionManager    1
com.apple.driver.corecapture    1.0.4
com.apple.driver.AppleEmbeddedPCIE    1
com.apple.iokit.IOTimeSyncFamily    900.11
com.apple.driver.DiskImages    493.0.0
com.apple.iokit.IOGraphicsFamily    585
com.apple.iokit.IOBluetoothFamily    8.0.3d9
com.apple.iokit.IOBluetoothPacketLogger    8.0.3d9
com.apple.driver.FairPlayIOKit    68.6.0
com.apple.iokit.CoreAnalyticsFamily    1
com.apple.driver.AppleSSE    1.0
com.apple.driver.AppleSEPKeyStore    2
com.apple.driver.AppleUSBTDM    511.60.2
com.apple.iokit.IOUSBMassStorageDriver    184.40.6
com.apple.iokit.IOPCIFamily    2.9
com.apple.iokit.IOSCSIBlockCommandsDevice    436.40.6
com.apple.iokit.IOSCSIArchitectureModelFamily    436.40.6
com.apple.driver.AppleIPAppender    1.0
com.apple.driver.AppleFDEKeyStore    28.30
com.apple.driver.AppleEffaceableStorage    1.0
com.apple.driver.AppleCredentialManager    1.0
com.apple.driver.KernelRelayHost    1
com.apple.iokit.IOUSBHostFamily    1.2
com.apple.driver.AppleUSBHostMergeProperties    1.2
com.apple.driver.usb.AppleUSBCommon    1.0
com.apple.driver.AppleSMC    3.1.9
com.apple.driver.RTBuddy    1.0.0
com.apple.driver.AppleEmbeddedTempSensor    1.0.0
com.apple.driver.AppleARMPMU    1.0
com.apple.iokit.IOAccessoryManager    1.0.0
com.apple.driver.AppleOnboardSerial    1.0
com.apple.iokit.IOSkywalkFamily    1
com.apple.driver.mDNSOffloadUserClient    1.0.1b8
com.apple.iokit.IONetworkingFamily    3.4
com.apple.iokit.IOSerialFamily    11
com.apple.driver.AppleSEPManager    1.0.1
com.apple.driver.AppleA7IOP    1.0.2
com.apple.driver.IOSlaveProcessor    1
com.apple.driver.AppleBiometricSensor    2
com.apple.iokit.IOHIDFamily    2.0.0
com.apple.AUC    1.0
com.apple.iokit.IOAVFamily    1.0.0
com.apple.iokit.IOHDCPFamily    1.0.0
com.apple.iokit.IOCECFamily    1
com.apple.iokit.IOAudio2Family    1.0
com.apple.driver.AppleEmbeddedAudioLibs    1.17
com.apple.driver.AppleFirmwareUpdateKext    1
com.apple.driver.AppleM2ScalerCSCDriver    265.0.0
com.apple.iokit.IOSurface    289.3
com.apple.driver.IODARTFamily    1
com.apple.security.quarantine    4
com.apple.security.sandbox    300.0
com.apple.kext.AppleMatch    1.0.0d1
com.apple.driver.AppleMobileFileIntegrity    1.0.5
com.apple.kext.CoreTrust    1
com.apple.security.AppleImage4    3.0.0
com.apple.iokit.IOCryptoAcceleratorFamily    1.0.1
com.apple.driver.AppleARMPlatform    1.0.2
com.apple.iokit.IOStorageFamily    2.1
com.apple.iokit.IOSlowAdaptiveClockingFamily    1.0.0
com.apple.iokit.IOReportFamily    47
com.apple.kec.pthread    1
com.apple.kec.corecrypto    11.1
com.apple.kec.Libm    1



** Stackshot Succeeded ** Bytes Traced 313283 (Uncompressed 769440) **
Click to expand...
Have the crashes stopped? My new MacBook Air M1 rebooted following the pink screen crash and I got pretty much the same report as above. (dart-disp0 + com.apple.driver.AppleT8020DART).

This has happened twice so far in the 2 days since I started using this laptop. I am using a Samsung HDTV connected via a HDMI cable to a USB-C multiport adapter which is connected to my MacBook.

BootLoxes

BootLoxes

macrumors 6502a
Original poster
Apr 15, 2019
749
897
eatingseeds said:
Have the crashes stopped? My new MacBook Air M1 rebooted following the pink screen crash and I got pretty much the same report as above. (dart-disp0 + com.apple.driver.AppleT8020DART).

This has happened twice so far in the 2 days since I started using this laptop. I am using a Samsung HDTV connected via a HDMI cable to a USB-C multiport adapter which is connected to my MacBook.
Click to expand...

So far no crashes. Neither connected nor disconnected. Still waiting for something to happen. It literally went from happening almost daily to stopped as soon as I made this thread

iHorseHead

iHorseHead

macrumors 68000
Jan 1, 2021
1,594
2,003
This happened to me too today!!!
Screenshot 2021-04-12 at 08.37.46.png

The screen turned purple and it restarted. I was just reading the news and nothing was connected

iHorseHead

iHorseHead

macrumors 68000
Jan 1, 2021
1,594
2,003
mi7chy said:
What app were you running at the time? Symptoms sound like graphics driver or graphics hardware/memory.
Click to expand...
Oh, should I be worried then? I was running Chrome and Safari and Mail on the background. I was just reading the news.

M

mxrider88

macrumors 6502a
Mar 8, 2019
812
1,009
Sydney, AU
"It just works"... I just got an email today with a survey and I blasted them. The ecosystem is so buggy that it is not even fun anymore. Just a frustrating experience.

BootLoxes

BootLoxes

macrumors 6502a
Original poster
Apr 15, 2019
749
897
mxrider88 said:
"It just works"... I just got an email today with a survey and I blasted them. The ecosystem is so buggy that it is not even fun anymore. Just a frustrating experience.
Click to expand...
Honestly my first dip into macs havent been as good as i had expected. Might just stick with iphones and ipads from apple and keep building desktops for windows as my main driver

  • Like
Reactions: VaruLV
BootLoxes

BootLoxes

macrumors 6502a
Original poster
Apr 15, 2019
749
897
I wonder if its an m1 thing or if the intel ones had this issue too

B

bobcomer

macrumors 601
May 18, 2015
4,949
3,699
BootLoxes said:
I wonder if its an m1 thing or if the intel ones had this issue too
Click to expand...
I never get kernel panics on my Intel Mac Mini (2020). It's slowed down, but my MBA gets panics every couple of weeks, and it used to be every week. Both running the latest non-beta Big Sur.

You must log in or register to reply here.
Register on MacRumors! This sidebar will go away, and you'll see fewer ads.
Top Bottom
