Hi,
I bought a used Mac Pro 5.1 as a back up (was assured it was a 5.1 not a 4.1 flashed to 5.1). I put into it a radeon 580 card from macvidcards. Since it is a back up I have not used it much, but have now experienced two what seem kernel panics. I was running VMware fusion / windows 10. no other software on Mac side. I am not experienced much in trouble shooting, but I was hoping someone might be able to understand the system report to give me some clues what is possibly going on. below is copy of the problem report. Any guidance is appreciated.
I bought a used Mac Pro 5.1 as a back up (was assured it was a 5.1 not a 4.1 flashed to 5.1). I put into it a radeon 580 card from macvidcards. Since it is a back up I have not used it much, but have now experienced two what seem kernel panics. I was running VMware fusion / windows 10. no other software on Mac side. I am not experienced much in trouble shooting, but I was hoping someone might be able to understand the system report to give me some clues what is possibly going on. below is copy of the problem report. Any guidance is appreciated.
Code:
Anonymous UUID: 63157997-584D-2B13-5A4A-C388C75C6459
Fri Apr 8 11:15:48 2022
*** Panic Report ***
Panic(CPU 0, time 12272032838968): NMIPI for unresponsive processor: cross-call timeout
RAX: 0x0000000031df7b91, RBX: 0xffffff805d0f6a80, RCX: 0x0000000000000001, RDX: 0x0000022331df7b91
RSP: 0xffffff8536d47d90, RBP: 0xffffff8536d47dc0, RSI: 0x0000024195a5bdd4, RDI: 0xffffff8001213620
R8: 0x0000000000000001, R9: 0x0000000000000100, R10: 0xffffff80012a0700, R11: 0xffffff8536d8e000
R12: 0xffffff805d724800, R13: 0xffffff8536428f20, R14: 0xffffff8001213620, R15: 0xffffff8062886a40
RFL: 0x0000000000000006, RIP: 0xffffff7f83ade20a, CS: 0x0000000000000008, SS: 0x0000000000000010
Backtrace (CPU 0), Frame : Return Address
0xffffff8536d47c30 : 0xffffff8000ada0cb
0xffffff8536d47c90 : 0xffffff800095acd7
0xffffff8536d47dc0 : 0xffffff8000ae58a6
0xffffff8536d47de0 : 0xffffff80009c80e9
0xffffff8536d47e20 : 0xffffff80009c7fae
0xffffff8536d47e50 : 0xffffff80009f616d
0xffffff8536d47f10 : 0xffffff8000ac7e17
0xffffff8536d47f50 : 0xffffff8000ae2a93
0xffffff8536d47f70 : 0xffffff8000ada0cb
0xffffff8536d47fd0 : 0xffffff800095ab7d
0xffffff9d6d00bf30 : 0xffffff80009cf207
0xffffff9d6d00bf80 : 0xffffff80009cf3f0
0xffffff9d6d00bfa0 : 0xffffff800095a0ce
Kernel Extensions in backtrace:
com.apple.driver.AppleIntelCPUPowerManagement(220.0)[99F2E7B9-A130-3CAA-88F4-0AFE406C81AC]@0xffffff7f83adb000->0xffffff7f83b03fff
BSD process name corresponding to current thread: kernel_task
Mac OS version:
18G9323
Kernel version:
Darwin Kernel Version 18.7.0: Tue Jun 22 19:37:08 PDT 2021; root:xnu-4903.278.70~1/RELEASE_X86_64
Kernel UUID: 041B6A6D-CD16-36FA-88B9-E32FF46EF89F
Kernel slide: 0x0000000000600000
Kernel text base: 0xffffff8000800000
__HIB text base: 0xffffff8000700000
System model name: MacPro5,1 (Mac-F221BEC8)
System upti
EOF
Model: MacPro5,1, BootROM 144.0.0.0.0, 6 processors, 6-Core Intel Xeon, 3.46 GHz, 48 GB, SMC 1.39f11
Graphics: Radeon RX 580, Radeon RX 580, spdisplays_pcie_device, 8 GB
Memory Module: DIMM 1, 16 GB, DDR3 ECC, 1333 MHz, 0x80CE, 0x4D33393342324737304442302D434D412020
Memory Module: DIMM 2, 16 GB, DDR3 ECC, 1333 MHz, 0x80CE, 0x4D33393342324737304442302D434D412020
Memory Module: DIMM 3, 16 GB, DDR3 ECC, 1333 MHz, 0x80CE, 0x4D33393342324737304442302D434D412020
AirPort: spairport_wireless_card_type_airport_extreme (0x14E4, 0x8E), Broadcom BCM43xx 1.0 (5.106.98.102.31)
Bluetooth: Version 6.0.14d13, 3 services, 27 devices, 1 incoming serial ports
Network Service: Wi-Fi, AirPort, en2
PCI Card: Radeon RX 580, Display Controller, Slot-1
PCI Card: pci1002,aaf0, Audio Device, Slot-1
Serial ATA Device: HL-DT-ST DVD-RW GH61N
Serial ATA Device: INTEL SSDSC2BP240G4, 240.06 GB
Serial ATA Device: WDC WD1600AAJS-00B4A0, 160.04 GB
USB Device: USB 2.0 Bus
USB Device: USB 2.0 Bus
USB Device: Keyboard Hub
USB Device: Apple Keyboard
USB Device: USB Bus
USB Device: USB Bus
USB Device: G203 LIGHTSYNC Gaming Mouse
USB Device: USB Bus
USB Device: BRCM2046 Hub
USB Device: Bluetooth USB Host Controller
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
FireWire Device: built-in_hub, Up to 800 Mb/sec
Thunderbolt Bus:
