Panic Kernel every 15 min after big sur update problem.

P

PatiPhillips

macrumors newbie
Original poster
Aug 8, 2018
18
3
I'm thinking that since this is a new problem that it needs a new post?

Original post for big sur update problem is here:


forums.macrumors.com

Big Sur fried my computer Again!

I posted this on another forum but no replies so thought I would try here: Automatic Big Sur update, now will computer not boot. Long story will just try to make it shorter: Late 2015 imac had been updated to Big Sur Beta from Catalina: then last year Big Sur beta update (2.something I...
forums.macrumors.com forums.macrumors.com

Late 2015 imac 27" desktop. Original problem was booting up after update. After many solutions that did not work. I erased the drive and reinstalled Big Sur. Then I started having panic kernel every 15 min. Thought the solution might be to go back to Catalina. I now have erased everything again and installed Catalina. All is fine with catalina except I still have a panic kernel every 15 min or so. This prevents me from restoring any of my data through time machine disk or through migration from my laptop. I can deal with that in other ways but cannot figure out what is causing the panic kernel. It appears that something is timing out. Is it ok to post the panic data here for someone knowledgeable on panic kernel to look at?

Panics are sometimes caused by bad RAM. What do you have for RAM? (Make and size of each stick).

I think it is "ok" to post panic data, as people have done that before, but I wouldn't expect to get much feedback. I don't remember ever seeing a thread where someone diagnosed the issue from panic data, but you might get lucky.

Last edited:
wilberforce said:
Panics are sometimes caused by bad RAM. What do you have for RAM? (Make and size of each stick).
Click to expand...
I have 24 total ram, 2 4's and 2 8's. 1867mhz DDR3 I don't recall the make, I installed them several years ago. They are not apple brand.

PatiPhillips said:
I have 24 total ram, 2 4's and 2 8's. 1867mhz DDR3 I don't recall the make, I installed them several years ago. They are not apple brand.
Click to expand...
OK, take out one pair (say the two 4's) and try that.
Then do the opposite and take out the other pair (the two 8's) and try that.

If you are lucky, this process of elimination might show one stick/pair is bad, which will be an easy fix

btw, each matched pair of sticks should be installed in slots 1&3 or slots 2&4

  • Like
Reactions: Quackers
wilberforce said:
OK, take out one pair (say the two 4's) and try that.
Then do the opposite and take out the other pair (the two 8's) and try that.

If you are lucky, this process of elimination might show one stick/pair is bad, which will be an easy fix
Click to expand...
Worth a try, will have to wait until I have help lifting it though. I did check the system report and it says all 4 are ok.

It's unlikely I can help with the panics but you can post the contents of the kernel panic report in code tags (so it doesn't take up the whole page :) )
Copy the text then in the reply box click on the 3 vertical dots next to the smiley face up above then choose the right side option in the drop down options "code" (it's a left arrow then a slash then a right arrow) then paste in what you've copied.

Quackers said:
It's unlikely I can help with the panics but you can post the contents of the kernel panic report in code tags (so it doesn't take up the whole page :) )
Copy the text then in the reply box click on the 3 vertical dots next to the smiley face up above then choose the right side option in the frop down options "code" (it's a left arrow then a slash then a right arrow) then paste in what you've copied.
Click to expand...

Code:
panic(cpu 2 caller 0xffffff8002c12667): "AppleAHCIDiskQueueManager::setPowerState(0xffffff8031803b40 : 0xffffff7f83dab5d2, 3 -> 2) timed out after 100270 ms"@/AppleInternal/BuildRoot/Library/Caches/com.apple.xbs/Sources/xnu/xnu-6153.141.2.2/iokit/Kernel/IOServicePM.cpp:5296
Backtrace (CPU 2), Frame : Return Address
0xffffff82bea93b40 : 0xffffff800251868d
0xffffff82bea93b90 : 0xffffff8002652ab5
0xffffff82bea93bd0 : 0xffffff800264463e
0xffffff82bea93c20 : 0xffffff80024bea40
0xffffff82bea93c40 : 0xffffff8002517d57
0xffffff82bea93d40 : 0xffffff8002518147
0xffffff82bea93d90 : 0xffffff8002cbf2bc
0xffffff82bea93e00 : 0xffffff8002c12667
0xffffff82bea93e50 : 0xffffff8002c11f49
0xffffff82bea93e60 : 0xffffff8002c294de
0xffffff82bea93ea0 : 0xffffff8002c10cf8
0xffffff82bea93ec0 : 0xffffff800255a645
0xffffff82bea93f40 : 0xffffff800255a171
0xffffff82bea93fa0 : 0xffffff80024be13e

BSD process name corresponding to current thread: kernel_task

Mac OS version:
19H15
Kernel version:
Darwin Kernel Version 19.6.0: Thu Oct 29 22:56:45 PDT 2020; root:xnu-6153.141.2.2~1/RELEASE_X86_64
Kernel UUID: 9B5A7191-5B84-3990-8710-D9BD9273A8E5
Kernel slide:    0x0000000002200000
Kernel text base: 0xffffff8002400000
__HIB  text base: 0xffffff8002300000
System model name: iMac17,1 (Mac-DB15BD556843C820)
System shutdown begun: NO
Panic diags file available: YES (0x0)

System uptime in nanoseconds: 1148708022209
last loaded kext at 576496005413: >!U!SCoexistentDriver 489.120.1 (addr 0xffffff7f84697000, size 28672)
loaded kexts:
>!U!SCoexistentDriver 489.120.1
@filesystems.smbfs 3.4.4
>!ATopCaseHIDEventDriver 3430.1
>DiskImages.SparseDiskImage 493.0.0
>DiskImages.ReadWriteDiskImage 493.0.0
>DiskImages.CryptoEncoding 493.0.0
>DiskImages.UDIFDiskImage 493.0.0
>DiskImages.HTTPBackingStore 493.0.0
>DiskImages.RAMBackingStore 493.0.0
>DiskImages.FileBackingStore 493.0.0
>!AUpstreamUserClient 3.6.8
@kext.AMDFramebuffer 3.1.0
>AudioAUUC 1.70
@kext.AMDRadeonX4000 3.1.0
@kext.AMDRadeonServiceManager 3.1.0
>!AGraphicsDevicePolicy 5.2.6
@AGDCPluginDisplayMetrics 5.2.6
@fileutil 20.036.15
>!AHV 1
|IOUserEthernet 1.0.1
|IO!BSerialManager 7.0.6f7
>AGPM 111.4.4
>!APlatformEnabler 2.7.0d0
>X86PlatformShim 1.0.0
>pmtelemetry 1
>!AHDAHardwareConfigDriver 283.15
>!AMikeyHIDDriver 131
>!A!ISKLGraphics 14.0.7
@Dont_Steal_Mac_OS_X 7.0.0
>AGDCBacklightControl 5.2.6
>!AHDA 283.15
>ACPI_SMC_PlatformPlugin 1.0.0
>!AMikeyDriver 283.15
>!ABacklight 180.3
>!AThunderboltIP 3.1.4
|Broadcom!B20703USBTransport 7.0.6f7
|!ABCM5701Ethernet 10.3.5
>!A!IPCHPMC 2.0.1
>eficheck 1
>!ASMCLMU 212
>AirPort.BrcmNIC 1400.1.1
@kext.AMD7000!C 3.1.0
>!A!ISKLGraphicsFramebuffer 14.0.7
>!A!ISlowAdaptiveClocking 4.0.0
>!AFIVRDriver 4.1.0
>!AMCCSControl 1.14
@filesystems.autofs 3.0
|IO!BUSBDFU 7.0.6f7
|SCSITaskUserClient 422.120.3
>!AFileSystemDriver 3.0.1
>!AVirtIO 1.0
@filesystems.hfs.kext 522.100.5
@!AFSCompression.!AFSCompressionTypeDataless 1.0.0d1
@BootCache 40
@!AFSCompression.!AFSCompressionTypeZlib 1.0.0
>!ASDXC 1.7.7
@filesystems.apfs 1412.141.1
@private.KextAudit 1.0
>!AAHCIPort 341.140.1
>!AACPIButtons 6.1
>!ARTC 2.0
>!ASMBIOS 2.1
>!AACPIEC 6.1
>!AAPIC 1.7
$!AImage4 1
@nke.applicationfirewall 303
$TMSafetyNet 8
@!ASystemPolicy 2.0.0
|EndpointSecurity 1
|IOUSBMass!SClass 4.0.4
>!A!BHIDKeyboard 209
>!AMultitouchDriver 3440.1
>!AInputDeviceSupport 3440.8
>!AHS!BDriver 3430.1
>IO!BHIDDriver 7.0.6f7
>DiskImages.KernelBacked 493.0.0
@kext.AMDRadeonX4030HWLibs 1.0
@kext.AMDRadeonX4000HWServices 3.1.0
>!UAudio 323.4
>!AGraphicsControl 5.2.6
|IOAVB!F 850.1
@plugin.IOgPTPPlugin 840.3
>DspFuncLib 283.15
@kext.OSvKernDSPLib 529
>IOPlatformPluginLegacy 1.0.0
@!AGPUWrangler 5.2.6
>!ABacklightExpert 1.1.0
|IONDRVSupport 576.1
>!AHIDKeyboard 209
>!AHDA!C 283.15
|IOHDA!F 283.15
>X86PlatformPlugin 1.0.0
|Broadcom!BHost!CUSBTransport 7.0.6f7
|IO!BHost!CUSBTransport 7.0.6f7
|IO!BHost!CTransport 7.0.6f7
|IO!B!F 7.0.6f7
|IO!BPacketLogger 7.0.6f7
|IOEthernetAVB!C 1.1.0
>IOPlatformPlugin!F 6.0.0d8
>!ASMBusPCI 1.0.14d1
|IO80211!F 1200.12.2b1
>mDNSOffloadUserClient 1.0.1b8
>corecapture 1.0.4
|IOSkywalk!F 1
@kext.AMDSupport 3.1.0
@!AGraphicsDeviceControl 5.2.6
|IOAccelerator!F2 438.7.3
|IOSlowAdaptiveClocking!F 1.0.0
>!ASMBus!C 1.0.18d1
|IOGraphics!F 576.1
>!AThunderboltEDMSink 4.2.3
@kext.triggers 1.0
>usb.IOUSBHostHIDDevice 1.2
>usb.!UHub 1.2
>usb.cdc 5.0.0
>usb.networking 5.0.0
>usb.!UHostCompositeDevice 1.2
|IOAudio!F 300.2
@vecLib.kext 1.2.0
|IOSerial!F 11
|IOSurface 269.11
@filesystems.hfs.encodings.kext 1
>!AThunderboltDPOutAdapter 6.2.6
>!AThunderboltDPInAdapter 6.2.6
>!AThunderboltDPAdapter!F 6.2.6
>!AThunderboltPCIDownAdapter 2.5.4
>!AThunderboltNHI 5.8.6
|IOThunderbolt!F 7.6.1
>!A!ILpssI2C 3.0.60
>!AXsanScheme 3
|IOAHCIBlock!S 316.100.5
>usb.!UHostPacketFilter 1.0
>!A!ILpssGspi 3.0.60
|IOUSB!F 900.4.2
|IOAHCI!F 290.0.1
>usb.!UXHCIPCI 1.2
>usb.!UXHCI 1.2
>!AEFINVRAM 2.1
>!AEFIRuntime 2.1
|IOSMBus!F 1.1
|IOHID!F 2.0.0
$quarantine 4
$sandbox 300.0
@kext.!AMatch 1.0.0d1
>DiskImages 493.0.0
>!AFDEKeyStore 28.30
>!AEffaceable!S 1.0
>!ASSE 1.0
>!AKeyStore 2
>!UTDM 489.120.1
|IOSCSIBlockCommandsDevice 422.120.3
>!ACredentialManager 1.0
>KernelRelayHost 1
>!ASEPManager 1.0.1
>IOSlaveProcessor 1
|IOTimeSync!F 840.3
|IONetworking!F 3.4
|IOUSBMass!SDriver 157.140.1
|IOSCSIArchitectureModel!F 422.120.3
|IO!S!F 2.1
|IOUSBHost!F 1.2
>!UHostMergeProperties 1.2
>usb.!UCommon 1.0
>!ABusPower!C 1.0
|CoreAnalytics!F 1
>!AMobileFileIntegrity 1.0.5
@kext.CoreTrust 1
|IOReport!F 47
>!AACPIPlatform 6.1
>!ASMC 3.1.9
>watchdog 1
|IOPCI!F 2.9
|IOACPI!F 1.4
@kec.pthread 1
@kec.Libm 1
@kec.corecrypto 1.0

I hope this worked. If not I am sorry to have taken up so much space. You can delete.
