// BulgeChasing.swift
//
//
// Created by Philip Turner on 3/11/24.
//
import Accelerate
extension Diagonalization {
// Returns a sequence of reflectors.
mutating func chaseBulges() -> [Float] {
// Allocate a matrix to store the bulge reflectors.
var bulgeReflectors = [Float](
repeating: .zero, count: problemSize * problemSize)
let reflectors = bulgeReflectors
.withContiguousMutableStorageIfAvailable { $0.baseAddress! }!
let dotProducts: UnsafeMutablePointer<Float> =
.allocate(capacity: 3 * blockSize)
defer { dotProducts.deallocate() }
// Loop over the bulge chasing sweeps.
let sweepEnd = max(0, problemSize - 2)
for sweepID in 0..<sweepEnd {
var maxOperationID = (problemSize - 2) - (sweepID + 1)
maxOperationID /= blockSize
// Loop over the bulges within this sweep.
for operationID in 0...maxOperationID {
let startOfRow = operationID &* blockSize
let startOfColumn = sweepID &* problemSize
let startRowID = (sweepID + 1) &+ startOfRow
// Create a reflector using the 'ReflectorGeneration' API.
var generationDesc = ReflectorGenerationDescriptor()
let columnID = (sweepID + 1) &+ max(-1, startOfRow &- blockSize)
let matrixBaseAddress = columnID &* problemSize &+ startRowID
let matrixSource = UnsafePointer(matrixPointer! + matrixBaseAddress)
generationDesc.source = matrixSource
// Find the address to begin writing data at.
let reflectorBaseAddress = startOfColumn &+ (sweepID + 1) &+ startOfRow
let reflector = reflectors + reflectorBaseAddress
generationDesc.destination = reflector
// Determine the dimension of the reflector.
let maxReflectorElementID = problemSize &- (sweepID + 1)
let endOfRow = min(startOfRow &+ blockSize, maxReflectorElementID)
generationDesc.dimension = endOfRow &- startOfRow
ReflectorGeneration(descriptor: generationDesc)
// Apply to the trailing submatrix.
let endRowID = min(startRowID &+ blockSize, problemSize)
applyBulgeChase(
reflector: reflector,
dotProducts: dotProducts,
startRowID: startRowID,
endRowID: endRowID)
}
}
return bulgeReflectors
}
// Applies the reflector to the trailing submatrix.
@_transparent
private mutating func applyBulgeChase(
reflector: UnsafePointer<Float>,
dotProducts: UnsafeMutablePointer<Float>,
startRowID: Int,
endRowID: Int
) {
let startApplicationID = max(startRowID &- blockSize, 0)
let endApplicationID = min(endRowID &+ blockSize, problemSize)
let dotProductCount = endApplicationID &- startApplicationID
let rangeCount = endRowID &- startRowID
// Apply the reflector to the matrix, from the left.
do {
let matrixOffset = startApplicationID &* problemSize &+ startRowID
let A = matrixPointer! + matrixOffset
let B = reflector
let C = dotProducts
#if false
for m in 0..<dotProductCount {
for n in 0..<1 {
var dotProduct: Float = .zero
for k in 0..<rangeCount {
let lhsValue = matrix[matrixOffset + m * problemSize + k]
let rhsValue = reflector[n * dotProductCount + k]
dotProduct += lhsValue * rhsValue
}
dotProducts[m * 1 + n] = dotProduct
}
}
#else
var TRANSA = CChar(84) // T
var TRANSB = CChar(78) // N
var M = Int32(truncatingIfNeeded: dotProductCount)
var N = Int32(1)
var K = Int32(truncatingIfNeeded: rangeCount)
var ALPHA = Float(1)
var LDA = Int32(truncatingIfNeeded: problemSize)
var BETA = Float(0)
var LDB = Int32(truncatingIfNeeded: dotProductCount)
var LDC = Int32(truncatingIfNeeded: dotProductCount)
sgemm_(
&TRANSA,
&TRANSB,
&M,
&N,
&K,
&ALPHA,
A, &LDA,
B, &LDB,
&BETA,
C, &LDC)
#endif
}
do {
let matrixOffset = startApplicationID &* problemSize &+ startRowID
let X = reflector
let Y = dotProducts
let A = matrixPointer! + matrixOffset
#if false
for m in 0..<dotProductCount {
for n in 0..<rangeCount {
let lhsValue = dotProducts[m * 1]
let rhsValue = reflector[n * 1]
matrix[matrixOffset + m * problemSize + n] -= lhsValue * rhsValue
}
}
#else
var M = Int32(truncatingIfNeeded: rangeCount)
var N = Int32(truncatingIfNeeded: dotProductCount)
var ALPHA = Float(-1)
var INCX = Int32(1)
var INCY = Int32(1)
var LDA = Int32(truncatingIfNeeded: problemSize)
sger_(
&M,
&N,
&ALPHA,
X, &INCX,
Y, &INCY,
A, &LDA)
#endif
}
// Apply the reflector to the matrix, from the right.
do {
let matrixOffset = startRowID &* problemSize &+ startApplicationID
let A = matrixPointer! + matrixOffset
let B = reflector
let C = dotProducts
#if false
for m in 0..<dotProductCount {
for n in 0..<1 {
var dotProduct: Float = .zero
for k in 0..<rangeCount {
let lhsValue = matrix[matrixOffset + k * problemSize + m]
let rhsValue = reflector[n * dotProductCount + k]
dotProduct += lhsValue * rhsValue
}
dotProducts[m * 1 + n] = dotProduct
}
}
#else
var TRANSA = CChar(78) // N
var TRANSB = CChar(78) // N
var M = Int32(truncatingIfNeeded: dotProductCount)
var N = Int32(1)
var K = Int32(truncatingIfNeeded: rangeCount)
var ALPHA = Float(1)
var LDA = Int32(truncatingIfNeeded: problemSize)
var BETA = Float(0)
var LDB = Int32(truncatingIfNeeded: dotProductCount)
var LDC = Int32(truncatingIfNeeded: dotProductCount)
sgemm_(
&TRANSA,
&TRANSB,
&M,
&N,
&K,
&ALPHA,
A, &LDA,
B, &LDB,
&BETA,
C, &LDC)
#endif
}
do {
let matrixOffset = startRowID &* problemSize &+ startApplicationID
let X = dotProducts
let Y = reflector
let A = matrixPointer! + matrixOffset
#if false
for m in 0..<rangeCount {
for n in 0..<dotProductCount {
let lhsValue = reflector[m]
let rhsValue = dotProducts[n]
matrix[matrixOffset + m * problemSize + n] -= lhsValue * rhsValue
}
}
#else
var M = Int32(truncatingIfNeeded: dotProductCount)
var N = Int32(truncatingIfNeeded: rangeCount)
var ALPHA = Float(-1)
var INCX = Int32(1)
var INCY = Int32(1)
var LDA = Int32(truncatingIfNeeded: problemSize)
sger_(
&M,
&N,
&ALPHA,
X, &INCX,
Y, &INCY,
A, &LDA)
#endif
}
}
}
