Interesting. I'll have to have a look to see if I can fine the original. I thought I was already using it. Has anyone had success with a replacement cable? E.g. the apple thunderbolt 3
Got a tip for us?
Let us know
Become a MacRumors Supporter for $50/year with no ads, ability to filter front page stories, and private forums.
LG UltraFine 5K - Owners Thread
- Thread starter iBrooker
- Start date
- Sort by reaction score
I've been using this Belkin cable and it works just fine. I had a 2018 13" MBP and now a 2020 and they both work at 5K with this monitor. The original cable works fine also, it was just a little long and I did not like it all coiled up behind the monitor.
As an Amazon Associate, MacRumors earns a commission from qualifying purchases made through links in this post.
Can anyone let me know what scaled (HDPI) resolutions are available for this monitor on an M1 Mac?
For those that have had problems restoring the native 5K resolution even by swapping the TB cable multiple times (after the Mac has awaken from sleep):
Plug off the power cable behind the monitor and plug it back in. Not the Thunderbolt cable. It seems like the trick is to completely cut the power to the monitor.
Plug off the power cable behind the monitor and plug it back in. Not the Thunderbolt cable. It seems like the trick is to completely cut the power to the monitor.
- 5120x2880
- 2880x1620
- 2560x1440
- 2048x1152
- 1920x1090
- 1600x900
- 1440x810
- 1280x720
I was looking at this for my M1 MBA / M1 MBP .... I got as far as ordering then had a touch of the seconds after reading re 4K instead of 5K and screen ghosting.
Is this now the wrong time to buy one of these ? One website I saw suggested it is not stocked in Apple stores as being replaced.
Any comment for a prospective buyer and alternatives if there are obvious ones ?
I intend to use it for web browsing, Netflix and photo editing in Lightroom Classic (thus wanting as sharp as I can).
Is this now the wrong time to buy one of these ? One website I saw suggested it is not stocked in Apple stores as being replaced.
Any comment for a prospective buyer and alternatives if there are obvious ones ?
I intend to use it for web browsing, Netflix and photo editing in Lightroom Classic (thus wanting as sharp as I can).
People are losing their minds in these forums regarding the M1 platforms.
They are good machines. I think the traditional overly hyped YouTube videos skewed expectations.
From a usability perspective, they are better than the machines they replaced in the product line. Don’t expect them to be top-tier options.
in short, it works fine for Lightroom. And will be better when the app is native.
It is the best external display available, if we don’t count the Apple Pro Display XDR at $6k.
It can run with the full 5K resolution, right now with the M1 Macs it just has some bugs after sleep/wake.
Ahhh so it's missing the 3200x1800 one! So this means there is some sort of limitation on the M1 doing HDPI resolutions greater than 3008 horizontally (when put together with the wonky LG 5k2k monitor results).
They may have a 6016 width limit (the normal resolution of the XDR) so the max HiDPI resolution is 3008. 3200 HiDPI requires the limit to be increased up to 6400. I wonder if this can be done with a software patch (lilu.kext for M1 Macs? - There are still some things Lilu can't do in Big Sur on Intel Macs).
Yeah, that's what I'm going to have to wait for. I ended up cancelling my air order as the available resolution on the LG 5K2K was too low in HDPI but too small in native. I have a 5K ultra fine as well and would drop to one monitor, but this was a step too far, even for the power and silence of the M1. Looks like I'm going to have to wait for a patch, or the 14" to come out!
I don’t see anything being released soon. Could be a few years if at all, no one knows.
There are a few quirks with the M1 and this monitor but it’s manageable. Such a lovely screen and a pleasure to use, the bugs will be addressed soon I’m certain.
I ordered a Macbook Air M1 to use with my Ultrafine 5K, but I'm glad I saw this thread so I could cancel the order for now. I'm gonna wait and see if they fix the sleep and resolution bugs in the M1 or if it will work better with the upcoming 16 inch revision.
I'm not even sure if I can expect Apple to do something about it since it's a monitor from 2016 and it might also be LG's problem not Apple's?
I'm not even sure if I can expect Apple to do something about it since it's a monitor from 2016 and it might also be LG's problem not Apple's?
He could be doing 4K with a DisplayPort to USB-C cable or an onboard Thunderbolt controller that has one DisplayPort input.
Or he could be doing 5K from a Thunderbolt 3 add-in card that has two DisplayPort inputs.
A Thunderbolt connection or USB-C connection that includes USB 2.0 is required to use the USB features of the display (such as audio or camera or USB ports). In that case, Boot Camp drivers can be installed for brightness control.
Yes. TitanRidge Thunderbolt 3 card.
GIGABYTE GC-Titan Ridge 2.0 (Titan Ridge Thunderbolt 3 PCIe Card Component)
Intel Thunderbolt 3 Certified add-in card Intel DSL7540 Thunderbolt 3 controller Dual Thunderbolt 3 Ports (USB Type-C) Max Bandwidth 40 Gb/s DisplayPort 1.4 Capable with 4K Video Throughout Daisy-chain up to 12 Devices (6 devices per port) Support PD3.0 standard (up to 100W)
www.amazon.com
Couldn’t be easier to set up: The TB3 card has 2x miniDP ports and 2x TB3 ports. Connect the included two short miniDP-to-DP cables from the TB3 card to the GPU. And then one TB3 cable from the TB3 port on the TB3 card to the LG display’s input.
Works a treat. And yes, full 5K. Not 4K.
As an Amazon Associate, MacRumors earns a commission from qualifying purchases made through links in this post.
i went for this in the end as an interim as I don't want hassle with my M1 not seeing 5K ... so spent £399 on this 4K monitor ... not from Amazon though. V happy with image for stuff in LRC.
LG Electronics UHD 27UL850 27 Inch Monitor 4K Vesa DisplayHDR 400 IPS (3840 x 2160) - 2x HDMI, DisplayPort, USB-C, 350 cd/m2, 5ms, AMD Radeon Freesync, Height Adjustable, White
LG 27UL850 27-inch 4K UHD Vesa DisplayHDR 400 IPS Monitor (3840 x 2160, 2x HDMI, DisplayPort, USB-C, 350 cd/m2, 5ms, AMD Radeon Freesync, Height Adjustable) White
smile.amazon.co.uk
The UltraFine 5K is not a big volume seller for LG, and Apple is one of the few places left to buy it, but it works well with the M1 MacBooks. It was Apple's "officially sanctioned" high-end monitor before they introduced the XDR, and is still the same panel they use in the 5K iMacs.
If you go for the monitor in a "business" shipping box it comes with a 3 year warranty: https://www.lg.com/us/business/computer-monitors/lg-27md5klb-b
