Mac Pro (Late 2013) GPU (Driver) Issues
- Thread starter bax2003
- Start date
- Sort by reaction score
Well, people with D500/D700 got their hardware replaced when the replacement program went out, right? I would imagine most at least. There is a post in another thread I didn't annotate but I think someone did a GPU replacement with no effect but there was another component they replaced that was related to it, like a riser card or something, I haven't opened mine up in a while i don't remember the layout.
I don't know if that hardware replacement resolved the issue for them entirely or not, either.
I suppose I can reseat my GPUs. I'm on my regular user account and it hasn't panic'ed in five days. The last time it did panic though it was idle at a login window and it just spontaneously kernel panics and reboots 🙄 my home office space is shared with my family room so when my kids and I are just hanging out I'm used to watching log tails from across the room and I saw it go black and the console starts scrolling and all I could do was laugh.
My annoyance with this issue is currently at "If they don't announce an m-series Pro Desktop before they're shipping iPhone 13s, I'm buying a 7,1 refurb" stage. I don't need any of the expensive add-ons, just a lot of memory and I'm all set. I'd love to spend less and I'm really excited about the Apple Silicon platform, but a 7,1 would take me at least another four years so what the hell?
as the other guy replied to me on the apple forums and suggested that I follow the PRAM battery replacement procedure as it touched on reseating everything, this I did.
I also as per his recommendation connected/reconnected everything 3-4 times.
So far:
Mihai:~ mihait$ uptime
0:04 up 11 days, 4:53, 9 users, load averages: 2.41 2.77 2.52
fingers crossed that it remains stable...it was annoying before as I was having GPU Freezes in the logs (+ panic and reboot) daily.
I also as per his recommendation connected/reconnected everything 3-4 times.
So far:
Mihai:~ mihait$ uptime
0:04 up 11 days, 4:53, 9 users, load averages: 2.41 2.77 2.52
fingers crossed that it remains stable...it was annoying before as I was having GPU Freezes in the logs (+ panic and reboot) daily.
Modern Macs, anything after 2008, don't have PRAM, nor require battery to store configuration parameters, all configs are stored in the NVRAM inside the BootROM SPI flash memory. PRAM is a relic of OpenFirmware era.
Battery is just to keep the Real Time Clock (RTC) working - RTC is not just the clock, but all time related functions like timesinceboot and other time related counters.
Thanks for the explanation Alex. Did not know that part.
What I meant to say above was that I followed the instructions from ifixit for replacing the battery as those instructions go through removing all the boards, connectors, etc.
To quote the guy that suggested this on the apple forums:
"
There is a 30 step tear-down to replace the PRAM backup battery. Your symptoms do NOT indicate any problem with the battery.
However, during this process you will remove and re-seat the ribbon cable and card-edge connectors that tie the graphics cards together and into the rest of the system. Remove and replace these connectors several times to clear any accumulated corrosion. If that fixes the problem, you are probably good for several more years."
What I meant to say above was that I followed the instructions from ifixit for replacing the battery as those instructions go through removing all the boards, connectors, etc.
To quote the guy that suggested this on the apple forums:
"
There is a 30 step tear-down to replace the PRAM backup battery. Your symptoms do NOT indicate any problem with the battery.
However, during this process you will remove and re-seat the ribbon cable and card-edge connectors that tie the graphics cards together and into the rest of the system. Remove and replace these connectors several times to clear any accumulated corrosion. If that fixes the problem, you are probably good for several more years."
My D300 has been surprisingly stable the past month or so; no freezing or resets. I have it set to auto update, so its running whatever the current version of Big Sur is. I was all set to sell it last year, but I'm starting to reconsider.
for me maybe that help deal with random freeze for about 1 year now use Catalina but see that got something outdated. Anyway replace today RAM clean check battery 2.95V / 3 also use original Apple SSD strange
Last edited:
I am hitting my new high with 6,1 uptime in half an hour; 7 full days and with eGPU VII 4K + D300 WQHD. Mac Pro not put to sleep ever between that time, only the two monitors sleep occasionally. This is with Big Sur 11.5.1. I know there is 11.5.2 available, but didn't want to ruin my record uptime with this.
Only difference this time is that I don't run MacFansControl, I let the system do the cooling by itself (AppleSMC?).
My usage has been quite light though, only one ArchiCAD instance open and mostly at background, so just surfing, youtubing and messaging mostly with this. But it's up and running still after a full week. RTC battery to be replaced soon, but as said, it's a tedious task, so not today, I don't feel like it just now.
Maybe if didn't use it at all, it would have crashed, I don't know.
Only difference this time is that I don't run MacFansControl, I let the system do the cooling by itself (AppleSMC?).
My usage has been quite light though, only one ArchiCAD instance open and mostly at background, so just surfing, youtubing and messaging mostly with this. But it's up and running still after a full week. RTC battery to be replaced soon, but as said, it's a tedious task, so not today, I don't feel like it just now.
Maybe if didn't use it at all, it would have crashed, I don't know.
The D500 has a different graphics driver than the D300. The Tahiti driver is stable.
Yeah, it seems so, and I had read about that earlier here in MR forums I believe. Thanks for a reminder.
There was a repair program for Mac Pro 6,1 with D500/D700 (Tahiti) if I recall it right. Wasn't that more about and because of heat problems that occured and broke things inside the tube? But then again, no repairs for D300 (Pitcairn) unstable drivers. Would have thought they'd put some sw-engineer(s) to work to straighten this out by now.
I have sent reports to Apple every freaking time there is a freeze or an unnecessary reboot at night, or at will, to put it more in perspective. But I guess it's too late by now to make a difference with this.
Yep, I might now move to D500 black metal tube as my main driver. A 2TB Kingston NVME bought allready to make the transition.
There was a repair program for Mac Pro 6,1 with D500/D700 (Tahiti) if I recall it right. Wasn't that more about and because of heat problems that occured and broke things inside the tube? But then again, no repairs for D300 (Pitcairn) unstable drivers. Would have thought they'd put some sw-engineer(s) to work to straighten this out by now.
I have sent reports to Apple every freaking time there is a freeze or an unnecessary reboot at night, or at will, to put it more in perspective. But I guess it's too late by now to make a difference with this.
Yep, I might now move to D500 black metal tube as my main driver. A 2TB Kingston NVME bought allready to make the transition.
I had two kernel panics today but this time I caught some additional detail that I don't recall seeing before; I'll post some excerpts. I can't find much on public search engines about these messages.
sample:
and possibly of note as well:
What is driving me crazy right now is that google search for "amd gpu driver macos recover display enable dpm" turns up nothing even remotely interesting. Same for "macpro amd fail DPM LB stuck". wtaf 😂
sample:
Code:
[ 2637.214692]: Trying to restart GPU (AMD FirePro D300)...
[ 2637.217112]: AMD FAIL: >>> Recover Display: 1 \M-b\M^@\M^S LB stuck
[ 2637.217135]: AMD FAIL: >>> Disable DPM
[ 2637.217296]: AMD FAIL: <<< Disable DPM
[ 2637.217301]: AMD FAIL: <<< Recover Display: 1 - LB stuck
[ 2637.218465]: AMD FAIL: >>> Recover Display: 2 \M-b\M^@\M^S LB stuck
[ 2637.219521]: AMD FAIL: >>> Recover Display: 3 \M-b\M^@\M^S LB stuck
[ 2637.220617]: AMD FAIL: >>> Recover Display: 4 \M-b\M^@\M^S LB stuck
[ 2637.221779]: AMD FAIL: >>> Recover Display: 5 \M-b\M^@\M^S LB stuck
[ 2637.221805]: AMD FAIL: >>> Enable DPM
[ 2637.221808]: AMD FAIL: <<< Enable DPM
[ 2637.221871]: GPU restart previously failed and will not be attempted again.
Code:
: 0x00000000 : 0x00000000
: ** GPU Debug Info End **
could not be reset. Further submissions will not be accepted.
[ 2607.871100]:
[ 2607.871115]: Trying to restart GPU (AMD FirePro D300)...
[ 2607.873511]: AMD FAIL: >>> Recover Display: 1 \M-b\M^@\M^S LB stuck
[ 2607.873538]: AMD FAIL: >>> Disable DPM
[ 2607.873704]: AMD FAIL: <<< Disable DPM
[ 2607.873709]: AMD FAIL: <<< Recover Display: 1 - LB stuck
[ 2607.874732]: AMD FAIL: >>> Recover Display: 2 \M-b\M^@\M^S LB stuck
[ 2607.875878]: AMD FAIL: >>> Recover Display: 3 \M-b\M^@\M^S LB stuck
[ 2607.876934]: AMD FAIL: >>> Recover Display: 4 \M-b\M^@\M^S LB stuck
[ 2607.877965]: AMD FAIL: >>> Recover Display: 5 \M-b\M^@\M^S LB stuck
[ 2607.877987]: AMD FAIL: >>> Enable DPM
[ 2607.877990]: AMD FAIL: <<< Enable DPM
[ 2607.878088]: GPU restart previously failed and will not be attempted again.
[ 2607.880375]: AMD FAIL: >>> Recover Display: 1 \M-b\M^@\M^S LB stuck
[ 2607.880400]: AMD FAIL: >>> Disable DPM
[ 2607.880568]: AMD FAIL: <<< Disable DPM
[ 2607.880573]: AMD FAIL: <<< Recover Display: 1 - LB stuck
[ 2607.881589]: AMD FAIL: >>> Recover Display: 2 \M-b\M^@\M^S LB stuck
[ 2607.882650]: AMD FAIL: >>> Recover Display: 3 \M-b\M^@\M^S LB stuck
[ 2607.883795]: AMD FAIL: >>> Recover Display: 4 \M-b\M^@\M^S LB stuck
[ 2607.884827]: AMD FAIL: >>> Recover Display: 5 \M-b\M^@\M^S LB stuck
[ 2607.884852]: AMD FAIL: >>> Enable DPM
[ 2607.884855]: AMD FAIL: <<< Enable DPM
[ 2607.884860]: void IOAccelEventMachine2::restart_channel(): GPURestartEnd stampIdx=4 type=2
[ 2608.157095]: ALF, old data swfs_pid_entry <ptr>, updaterules_msg <ptr>, updaterules_state <ptr>Sandbox: suggestd(2343) deny(1) mach-lookup com.apple.chronoservicesvirtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): initial wait for 1 second expired. Continue wait for 4 seconds. stamp 158671 (gpu_stamp=158666)
[ 2608.370740]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): initial wait for 1 second expired. Continue wait for 4 seconds. stamp 158712 (gpu_stamp=158666)
[ 2608.370744]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): initial wait for 1 second expired. Continue wait for 4 seconds. stamp 158705 (gpu_stamp=158666)and possibly of note as well:
Code:
----------------------------------------
--- DRIVER STATE TRACE---
DeviceID : [6:0:0]
----------------------
u64AllAccel : 0x0000000000003fff
----------------------
accelStart_entry : 1
accelStarted : 1
accelStart_exit : 1
configureDevice_entry : 1
deviceConfigured : 1
configureDevice_exit : 1
initLinkToPeer : 1
createHWHandler : 1
createHWInterface : 1
accelPowerUpHW_entry : 1
accelPowerUpHW : 1
accelPowerUpHW_exit : 1
bltMgrInitialized : 1
atomicBltMgrInitialized : 1
----------------------
u64AllHW : 0x0000000000ff7fdf
----------------------
hardwareInit_entry : 1
hardwareInit : 1
hardwareInit_exit : 1
initExternalInterfaces : 1
hwRegistersInitialized : 1
mapDoorbellMemory : 0
setupCail : 1
initCail : 1
setupInitHWCapabilities : 1
allocateHWEngines : 1
initializeHWEngines : 1
powerUpHWEngines : 1
startHWEngines : 1
initHWInfo : 1
hardwarePowerUp_entry : 1
hardwarePowerUp : 1
hardwarePowerUp_exit : 1
initializeTtl : 0
hwMemoryInitialized : 1
hwGartInitialized : 1
hwVmmInitialized : 1
initHWDisplay : 1
setVirtualSpace : 1
initializeHWRegisters : 1
----------------------------------------
---THE STATE OF THE GPU---
GPU is connected to PCIe bus and Register access is correct.
timeSinceLastPowerUp = 0:41:37.617048
[00] HWChannel: GFX, Priority 2, last reset 0:00:00.000000
CompletedTS = 0x00026bcb, SubmittedTS = 0x00026bcb
Ring: ENABLED
GPUAddress = 0x0000000080020000, Size = 0x20000, ReadPtr = 0x0001e600, WritePtr = 0x0001e600
[01] HWChannel: Compute0, Priority 2, last reset 0:00:00.000000
CompletedTS = 0x00000000, SubmittedTS = 0x00000000
Ring: ENABLED
GPUAddress = 0x00000000800c0000, Size = 0x8000, ReadPtr = 0x00000000, WritePtr = 0x00000000
[02] HWChannel: Compute1, Priority 2, last reset 0:00:00.000000
CompletedTS = 0x00000698, SubmittedTS = 0x00000698
Ring: ENABLED
GPUAddress = 0x0000000080100000, Size = 0x8000, ReadPtr = 0x00004c00, WritePtr = 0x00004c00
[03] HWChannel: DMA0, Priority 2, last reset 0:00:00.000000
CompletedTS = 0x00011446, SubmittedTS = 0x0001144a
PendingTS = 0x11447, sent at 0:42:28.440584, AccelChannel: 3, TS = 0x11447
Ring: ENABLED
GPUAddress = 0x0000000080140000, Size = 0x8000, ReadPtr = 0x00001181, WritePtr = 0x00001280
Command Ring Snapshot:
0x1100 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x1108 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x1110 : f0000000 f0000000 f0000000 f0000000 f0000000 40200000 0040e8e0 00008004
0x1118 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x1120 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x1128 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x1130 : 60000000 800000c0 00000000 00011445 30000002 800000d0 800000c0 00000000
0x1138 : 00000000 70000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
--- Frame Boundary ---
0x1140 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x1148 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x1150 : f0000000 f0000000 f0000000 f0000000 f0000000 40200000 0040e900 00008004
0x1158 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x1160 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x1168 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x1170 : 60000000 800000c0 00000000 00011446 30000002 800000d0 800000c0 00000000
0x1178 : 00000000 70000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
--- Frame Boundary ---
0x1180 : f0000000 >f0000000< f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x1188 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x1190 : f0000000 f0000000 f0000000 f0000000 f0000000 40200000 0040e920 00008004
0x1198 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x11a0 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x11a8 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x11b0 : 60000000 800000c0 00000000 00011447 30000002 800000d0 800000c0 00000000
0x11b8 : 00000000 70000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
[04] HWChannel: DMA1, Priority 2, last reset 0:00:00.000000
CompletedTS = 0x0000da12, SubmittedTS = 0x0000da36
PendingTS = 0xda13, sent at 0:42:28.740164, AccelChannel: 15, TS = 0xc433
Ring: ENABLED
GPUAddress = 0x0000000080160000, Size = 0x8000, ReadPtr = 0x00000d80, WritePtr = 0x00000d80
Command Ring Snapshot:
0x0d00 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0d08 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0d10 : f0000000 f0000000 f0000000 f0000000 f0000000 40000000 80d01e22 00009000
0x0d18 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0d20 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0d28 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0d30 : 60000000 80000100 00000000 0000da35 30000002 80000110 80000100 00000000
0x0d38 : 00000000 70000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
--- Frame Boundary ---
0x0d40 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0d48 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0d50 : f0000000 f0000000 f0000000 f0000000 f0000000 40000000 80d01e82 00009000
0x0d58 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0d60 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0d68 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0d70 : 60000000 80000100 00000000 0000da36 30000002 80000110 80000100 00000000
0x0d78 : 00000000 70000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
--- Frame Boundary ---
0x0d80 :>f0000000< f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0d88 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0d90 : f0000000 f0000000 f0000000 f0000000 f0000000 40000000 80ca2742 00009000
0x0d98 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0da0 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0da8 : f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
0x0db0 : 60000000 80000100 00000000 0000d837 30000002 80000110 80000100 00000000
0x0db8 : 00000000 70000000 f0000000 f0000000 f0000000 f0000000 f0000000 f0000000
Sync: DISABLED TimeSinceSyncDisabled = 2467617 msec
[05] HWChannel: UVD, Priority 2, last reset 0:00:00.000000
CompletedTS = 0x00000000, SubmittedTS = 0x00000000
Ring: DISABLED
GPUAddress = 0x0000000080180000, Size = 0x0800, ReadPtr = 0x00000000, WritePtr = 0x00000000
[06] HWChannel: VCE, Priority 2, last reset 0:00:00.000000
CompletedTS = 0x00000000, SubmittedTS = 0x00000000
Ring: DISABLED
GPUAddress = 0x00000000801a0000, Size = 0x0800, ReadPtr = 0x00000000, WritePtr = 0x00000000
[07] HWChannel: VCELLQ, Priority 2, last reset 0:00:00.000000
CompletedTS = 0x00000000, SubmittedTS = 0x00000000
Ring: DISABLED
GPUAddress = 0x00000000801c0000, Size = 0x0800, ReadPtr = 0x00000000, WritePtr = 0x00000000
[08] HWChannel: SPU, Priority 2, last reset 0:00:00.000000
CompletedTS = 0x00000002, SubmittedTS = 0x00000002
Ring: DISABLED
GPUAddress = 0x00000000801e0000, Size = 0x0180, ReadPtr = 0x00000000, WritePtr = 0x00000018
Graphic and Compute(GC):
Graphic Ring: GPUAddress = 0x0000000080020000, Size = 0x00020000, ReadPtr = 0x0001e600, WritePtr = 0x0001e600
Compute Ring 1: GPUAddress = 0x00000000800c0000, Size = 0x00008000, ReadPtr = 0x00000000, WritePtr = 0x00000000
IB: GPUAddress = 0x0000000403770000, ConsumedSize = 0x00000000, RemainSize=0x00000000
Compute Ring 2: GPUAddress = 0x0000000080100000, Size = 0x00008000, ReadPtr = 0x00004c00, WritePtr = 0x00004c00
IB: GPUAddress = 0x0000000400400000, ConsumedSize = 0x00000000, RemainSize=0x00000000
GC Pipeline Status:
Command Processor(CP): IDLE
PreFetchParser(PFP): ACTIVE
PFP Last Processed Commands:
0xc0431000
0xc0044700
0xc0044700
0xc0001700
0xc0034300
MicroEngine(ME): ACTIVE
ME Last Processed Commands:
0xc0044700
0xc0044700
0xc0001700
0xc0034300
0xc0034300
Graphic Engine Setup: IDLE
Unified Shader Processor and Input: IDLE
Texture Pipe: IDLE
Render Backend: IDLE
DRMDMA: ACTIVE and BUSY
Ring: GPUAddress = 0x00801400, Size = 0x00008000, ReadPtr = 0x00001181, WritePtr = 0x00001280
IB: [ENABLE] GPUAddress = 0x000000040040e900, ConsumedSize = 0x00000008
DRMDMA1: ACTIVE and IDLE
Ring: GPUAddress = 0x00801600 Size = 0x00008000, ReadPtr = 0x00000d80 WritePtr = 0x00000d80
IB: [ENABLE] GPUAddress = 0x0000000400398a00, ConsumedSize = 0x00000008
UVD0: Disabled
VCE: Disabled
SAMU: Disabled
System Domain: NO
GPUAddress = 0x0000000000000000, VMID = 0
Failing Protection =
Virtual Domain: NO
GPUAddress = 0x0000000000000000, VMID = 0
Failing Protection =
------------------------
: ** GPU Debug Info Start **
: 0x00006810 : 0x0000011e : 0x00000001 : 0x00000018 : 0x0000a060 : 0x00000001 : 0x00000001 : 0x00006810
: 0x00000001 : 0x00000015 : 0x00000000 : 0x00000001 : 0x00000047 : 0x00005009 : 0x00000001 : 0x00000058
: 0x00000012 : 0x00000001 : 0x00000055 : 0x00000000 : 0x00000001 : 0x0000004a : 0x0000106b : 0x00000001
: 0x0000004d : 0x0000012a : 0x00000000 : 0x00000010 : 0x00010900 : 0x00000000 : 0x00000021 : 0x00000080
: 0x00000000 : 0x00000011 : 0x00000007 : 0x00000002 : 0x0000263d : 0x00000001 : 0x00000002 : 0x000021a0
: 0x00000000 : 0x00000002 : 0x0000219f : 0x00000000 : 0x00000002 : 0x0000219d : 0x00000000 : 0x00000002
: 0x0000219e : 0x00000000 : 0x00000002 : 0x0000219c : 0x00000000 : 0x00000002 : 0x0000a0da : 0x00000000
: 0x00000002 : 0x00003051 : 0x00000000 : 0x00000002 : 0x00002e14 : 0x00000000 : 0x00000002 : 0x0000a0d9
: 0x00000000 : 0x00000002 : 0x000021da : 0x01000040 : 0x00000002 : 0x000021db : 0x00000080 : 0x00000002
: 0x000021dd : 0x00000180 : 0x00000002 : 0x000021e0 : 0x00000000 : 0x00000002 : 0x000021e1 : 0x01600160
: 0x00000002 : 0x000021e2 : 0x04600460 : 0x00000002 : 0x000021e3 : 0x04fe04fe : 0x00000002 : 0x000021e5
: 0x01780178 : 0x00000002 : 0x000021b4 : 0x00000000 : 0x00000002 : 0x0000217f : 0x00000000 : 0x00000002
: 0x00002100 : 0x80000000 : 0x00000002 : 0x00002101 : 0x22000000 : 0x00000002 : 0x00002102 : 0x00026bcb
: 0x00000002 : 0x00002103 : 0x00000000 : 0x00000002 : 0x00002104 : 0x00026bcb : 0x00000002 : 0x00002105
: 0x00000000 : 0x00000002 : 0x000021b6 : 0x00000000 : 0x00000002 : 0x0000216d : 0x00008000 : 0x00000002
: 0x0000216e : 0x00000004 : 0x00000002 : 0x00002169 : 0x00008000 : 0x00000002 : 0x0000216a : 0x02000004
: 0x00000002 : 0x0000216b : 0x00025d14 : 0x00000002 : 0x0000216c : 0x00000000 : 0x00000002 : 0x00003041
: 0x00c00a10 : 0x00000002 : 0x00003040 : 0x00800200 : 0x00000002 : 0x00003042 : 0x00000000 : 0x00000002
: 0x00003043 : 0x80000008 : 0x00000002 : 0x000021c0 : 0x0001e600 : 0x00000002 : 0x00003045 : 0x0001e600
: 0x00000002 : 0x00003061 : 0x00c00a0e : 0x00000002 : 0x00003060 : 0x00800c00 : 0x00000002 : 0x00003062
: 0x80000048 : 0x00000002 : 0x000021bf : 0x00000000 : 0x00000002 : 0x00003064 : 0x00000000 : 0x00000002
: 0x00003066 : 0x00c00a0e : 0x00000002 : 0x00003065 : 0x00801000 : 0x00000002 : 0x00003067 : 0x80000088
: 0x00000002 : 0x000021be : 0x00004c00 : 0x00000002 : 0x00003069 : 0x00004c00 : 0x00000002 : 0x000021cc
: 0x03770000 : 0x00000002 : 0x000021cd : 0x00000004 : 0x00000002 : 0x000021ce : 0x00000000 : 0x00000002
: 0x00002192 : 0x00000000 : 0x00000002 : 0x000021cf : 0x00400000 : 0x00000002 : 0x000021d0 : 0x00000004
: 0x00000002 : 0x000021d1 : 0x00000000 : 0x00000002 : 0x00002193 : 0x00000000 : 0x00000002 : 0x000021dc
: 0x000000c0 : 0x00000002 : 0x00002170 : 0x00000000 : 0x00000002 : 0x00002171 : 0x00000000 : 0x00000002
: 0x00002175 : 0x00000000 : 0x00000002 : 0x00002176 : 0x00000000 : 0x00000002 : 0x00003057 : 0x00000086
: 0x00000002 : 0x00003054 : 0x0000004c : 0x00000002 : 0x0000305a : 0x00000038 : 0x00000002 : 0x00001508
: 0x00080200 : 0x00000002 : 0x00000b00 : 0x8f200029 : 0x00000002 : 0x00000bd1 : 0x00000000 : 0x00000002
: 0x00000bf8 : 0x00000000 : 0x00000002 : 0x00000504 : 0x20492491 : 0x00000002 : 0x0000050c : 0x00000002
: 0x00000002 : 0x00000536 : 0x00000000 : 0x00000002 : 0x00000503 : 0x00000000 : 0x00000002 : 0x00002000
: 0x00000018 : 0x00000002 : 0x00002004 : 0x00003028 : 0x00000002 : 0x00002002 : 0x00000000 : 0x00000002
: 0x00002005 : 0x00000006 : 0x00000002 : 0x00002006 : 0x00000006 : 0x00000002 : 0x000021a3 : 0x00080808
: 0x00000002 : 0x00002016 : 0x9000b850 : 0x00000002 : 0x00000390 : 0x000103ff : 0x00000002 : 0x00000394
: 0x200200c0 : 0x00000002 : 0x00000393 : 0x00000020 : 0x00000002 : 0x000003a6 : 0x81001e9c : 0x00000002
: 0x00000f88 : 0x00000442 : 0x00000002 : 0x0000380a : 0x0c000000 : 0x00000002 : 0x00003808 : 0xc0000000
: 0x00000002 : 0x00001576 : 0x00000000 : 0x00000002 : 0x0000340b : 0x04208401 : 0x00000002 : 0x0000340d
: 0x44483142 : 0x00000002 : 0x0000340c : 0x008000c0 : 0x00000002 : 0x00003409 : 0x82000001 : 0x00000002
: 0x0000340a : 0x00000020 : 0x00000002 : 0x00003416 : 0x00000000 : 0x00000002 : 0x00003413 : 0x00000008
: 0x00000002 : 0x00003414 : 0x0040e900 : 0x00000002 : 0x00003415 : 0x00000004 : 0x00000002 : 0x00003401
: 0x00801400 : 0x00000002 : 0x00003400 : 0x0000001f : 0x00000002 : 0x00003402 : 0x00004604 : 0x00000002
: 0x00003408 : 0x00000000 : 0x00000002 : 0x00003407 : 0x00000000 : 0x00000002 : 0x00003403 : 0x00004a00
: 0x00000002 : 0x00003404 : 0x00401000 : 0x00000002 : 0x00003406 : 0x00000000 : 0x00000002 : 0x00003405
: 0x00000000 : 0x00000002 : 0x0000360d : 0x44c83d57 : 0x00000002 : 0x0000360c : 0x008000c0 : 0x00000002
: 0x00003609 : 0x82000001 : 0x00000002 : 0x0000360a : 0x00000020 : 0x00000002 : 0x00003616 : 0x00000000
: 0x00000002 : 0x00003613 : 0x00000008 : 0x00000002 : 0x00003614 : 0x00398a00 : 0x00000002 : 0x00003615
: 0x00000004 : 0x00000002 : 0x00003601 : 0x00801600 : 0x00000002 : 0x00003600 : 0x0000001f : 0x00000002
: 0x00003602 : 0x00003600 : 0x00000002 : 0x00003608 : 0x00000000 : 0x00000002 : 0x00003607 : 0x00000000
: 0x00000002 : 0x00003603 : 0x00003600 : 0x00000002 : 0x00003604 : 0x00401000 : 0x00000002 : 0x00003606
: 0x00000000 : 0x00000002 : 0x00003605 : 0x00000000 : 0x00000002 : 0x0000360b : 0x04208401 : 0x00000002
: 0x0000360e : 0x00000000 : 0x00000002 : 0x0000360f : 0x00000000 : 0x00000002 : 0x00003610 : 0x00000000
: 0x00000002 : 0x00003611 : 0x00000000 : 0x00000002 : 0x00003612 : 0x00000000 : 0x00000002 : 0x00003617
: 0x00010000 : 0x00000002 : 0x00003618 : 0x00000000 : 0x00000002 : 0x0000361b : 0x00000000 : 0x00000002
: 0x0000361c : 0x00000000 : 0x00000002 : 0x0000361d : 0x00000000 : 0x00000002 : 0x0000361e : 0x00000000
: 0x00000002 : 0x0000361f : 0x00000000 : 0x00000002 : 0x00003620 : 0x00000000 : 0x00000002 : 0x00003621
: 0x00000000 : 0x00000002 : 0x00003622 : 0x00000000 : 0x00000002 : 0x00003623 : 0x00000000 : 0x00000002
: 0x00003624 : 0x00000000 : 0x00000002 : 0x00003625 : 0x00000000 : 0x00000002 : 0x00003626 : 0x00000000
: 0x00000002 : 0x00003627 : 0x00000000 : 0x00000002 : 0x00003628 : 0x00000000 : 0x00000002 : 0x00003629
: 0x00000000 : 0x00000002 : 0x0000362a : 0x00000000 : 0x00000002 : 0x0000362b : 0x00000000 : 0x00000002
: 0x0000362c : 0x00000000 : 0x00000002 : 0x0000362d : 0x00000000 : 0x00000002 : 0x0000362e : 0x00000000
: 0x00000002 : 0x0000362f : 0x00000000 : 0x00000002 : 0x00003630 : 0x00000100 : 0x00000002 : 0x00003631
: 0x00000010 : 0x00000002 : 0x00003632 : 0x00000000 : 0x00000002 : 0x00003633 : 0x00000000 : 0x00000002
: 0x00003634 : 0x00000000 : 0x00000002 : 0x00000f99 : 0x00000000 : 0x00000002 : 0x00000a25 : 0x5fc30049
: 0x00000002 : 0x00000a05 : 0x00000000 : 0x00000002 : 0x00000a36 : 0x6000e016 : 0x00000002 : 0x00000a76
: 0x00000000 : 0x00000002 : 0x00000a7d : 0x00000300 : 0x00000002 : 0x00000a20 : 0x00000300 : 0x00000002
: 0x00000a13 : 0x00000000 : 0x00000002 : 0x00000a38 : 0x00100000 : 0x00000002 : 0x00000abc : 0x2c2c2c2c
: 0x00000002 : 0x00000832 : 0x00000000 : 0x00000002 : 0x00000847 : 0x00000400 : 0x00000002 : 0x00000838
: 0x0000781f : 0x00000002 : 0x00000839 : 0x0000001e : 0x00000002 : 0x0000083a : 0x0000000f : 0x00000002
: 0x00000895 : 0x00000000 : 0x00000002 : 0x00000896 : 0x00000000 : 0x00000002 : 0x00000897 : 0x00000000
: 0x00000002 : 0x000008a6 : 0x00000000 : 0x00000002 : 0x0000099b : 0x00000000 : 0x00000002 : 0x0000099c
: 0x00000000 : 0x00000002 : 0x0000099d : 0x00000000 : 0x00000002 : 0x000009a8 : 0x00000000 : 0x00000002
: 0x000009b0 : 0x00000000 : 0x00000002 : 0x000009b1 : 0x00000000 : 0x00000002 : 0x00002284 : 0x00000000
: 0x00000002 : 0x00002294 : 0x00000000 : 0x00000002 : 0x000022f3 : 0x00000000 : 0x00000002 : 0x0000223c
: 0x00000000 : 0x00000002 : 0x0000225c : 0x00000000 : 0x00000002 : 0x00002256 : 0x00000000 : 0x00000002
: 0x000021b8 : 0x20000000 : 0x00000002 : 0x000030c0 : 0x00000001 : 0x00000002 : 0x000030d3 : 0x0000000a
: 0x00000002 : 0x000030d1 : 0x00000000 : 0x00000002 : 0x00002b01 : 0x00000000 : 0x00000002 : 0x00002b06
: 0x80400200 : 0x00000002 : 0x00002b00 : 0x00000000 : 0x00000002 : 0x00002300 : 0x00000000 : 0x00000002
: 0x00002140 : 0x00000000 : 0x00000002 : 0x0000263d : 0x00000001 : 0x00000002 : 0x000026df : 0x00000000
: 0x00000002 : 0x0000263e : 0x10000000 : 0x00000002 : 0x0000263f : 0x76543210 : 0x00000002 : 0x00002640
: 0x00000000 : 0x00000002 : 0x000021d5 : 0x38181008 : 0x00000002 : 0x000021d6 : 0xa8907858 : 0x00000002
: 0x000021d9 : 0x00006030 : 0x00000002 : 0x000021d7 : 0x00b0a090 : 0x00000002 : 0x00000505 : 0x07492413
: 0x00000002 : 0x0000050d : 0x00000000 : 0x00000002 : 0x00000500 : 0x0c0b8e03 : 0x00000002 : 0x00000502
: 0x00120004 : 0x00000002 : 0x00000535 : 0x00000000 : 0x00000002 : 0x00000550 : 0x0007bbf3 : 0x00000002
: 0x00000551 : 0x0007bc74 : 0x00000002 : 0x00000552 : 0x0007c582 : 0x00000002 : 0x00000553 : 0x0007be76
: 0x00000002 : 0x00000554 : 0x0007bef7 : 0x00000002 : 0x00000555 : 0x0007bf78 : 0x00000002 : 0x00000556
: 0x0007bff9 : 0x00000002 : 0x0000050e : 0x0007c07a : 0x00000002 : 0x0000050f : 0x0007c0fb : 0x00000002
: 0x00000510 : 0x0007c17c : 0x00000002 : 0x00000511 : 0x0007c27d : 0x00000002 : 0x00000512 : 0x0007c2fe
: 0x00000002 : 0x00000513 : 0x0007c37f : 0x00000002 : 0x00000514 : 0x0007c400 : 0x00000002 : 0x00000515
: 0x0007c501 : 0x00000002 : 0x00000558 : 0x00400000 : 0x00000002 : 0x00000560 : 0x023fffff : 0x00000002
: 0x0000053f : 0x00000000 : 0x00000002 : 0x00000537 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000
: 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442
: 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002
: 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000
: 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442
: 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002
: 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000
: 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442
: 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002
: 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000
: 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442
: 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002
: 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000
: 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442
: 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002
: 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000
: 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000002 : 0x00002442
: 0x00000000 : 0x00000002 : 0x00002442 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0xc0431000 : 0xc0044700
: 0xc0044700 : 0xc0001700 : 0xc0034300 : 0xc0044700 : 0xc0044700 : 0xc0001700 : 0xc0034300 : 0xc0034300
: 0x00000040 : 0x00000140 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000
: 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000
: 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000
: 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000
: 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000
: 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000
: 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000
: 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000 : 0x80000000
: 0x80000000 : 0x80000000 : 0xc0026900 : 0x000000cc : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000157
: 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000ce
: 0x00000000 : 0x3f800000 : 0xc0066900 : 0x0000015d : 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000
: 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000d0 : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000163
: 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000d2
: 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000169 : 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000
: 0x3f800000 : 0x00000000 : 0xc0026900 : 0x0000008e : 0x0000000f : 0x0000000f : 0xc0086900 : 0x000001e0
: 0x65010501 : 0x20010001 : 0x20010001 : 0x20010001 : 0x20010001 : 0x20010001 : 0x20010001 : 0x20010001
: 0xc0026900 : 0x00000003 : 0x00000000 : 0x00000080 : 0xc0036900 : 0x00000201 : 0x00301101 : 0x00cc0010
: 0x00000010 : 0xc0016900 : 0x00000207 : 0x00000000 : 0xc0016900 : 0x000002f8 : 0x00000000 : 0xc0016900
: 0x000001b1 : 0x00000002 : 0xc0046900 : 0x000001b3 : 0x00000002 : 0x00000002 : 0x0000246a : 0x00000002
: 0xc0016900 : 0x000001b8 : 0x01000000 : 0xc0036900 : 0x000001c3 : 0x00000004 : 0x00000000 : 0x00000004
: 0xc0026900 : 0x00000191 : 0x00000000 : 0x00000001 : 0xc0047600 : 0x00000008 : 0x04032864 : 0x00000000
: 0x002c0082 : 0x00000014 : 0xc0047600 : 0x00000048 : 0x040064cb : 0x00000000 : 0x002c00c3 : 0x0000000c
: 0xc00a7600 : 0x0000000c : 0x036f01f0 : 0x00000004 : 0x036f0000 : 0x00000004 : 0x00660230 : 0x00000004
: 0x036f01d0 : 0x00000004 : 0x036f0210 : 0x00000004 : 0xc0047600 : 0x0000004c : 0x00000000 : 0x00000000
: 0x036f0220 : 0x00000004 : 0xc0027600 : 0x0000004c : 0x00000000 : 0x00000000 : 0xc0016800 : 0x00000256
: 0x00000004 : 0xc0002f00 : 0x00000001 : 0xc0042700 : 0xffffffff : 0x2c501700 : 0x00000004 : 0x00000006
: 0x00000000 : 0xc0004600 : 0x00000410 : 0xc0004200 : 0x00000000 : 0xc0004600 : 0x00000016 : 0xc0034300
: 0x82804000 : 0xffffffff : 0x00000000 : 0x00000004 : 0xc0034300 : 0x80800000 : 0xffffffff : 0x00000000
: 0x00000004 : 0x80000000 : 0xc0026900 : 0x000000bc : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000127
: 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000be
: 0x00000000 : 0x3f800000 : 0xc0066900 : 0x0000012d : 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000
: 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000c0 : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000133
: 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000c2
: 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000139 : 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000
: 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000c4 : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x0000013f
: 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000c6
: 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000145 : 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000
: 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000c8 : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x0000014b
: 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000ca
: 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000151 : 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000
: 0x3f800000 : 0x00000000 : 0x00000000 : 0x00000000 : 0xc0016800 : 0x000001ff : 0x00000001 : 0xc0004600
: 0x00000017 : 0xc0004600 : 0x00000019 : 0xc00d6000 : 0x0002a000 : 0x00000004 : 0x00000232 : 0x00000001
: 0x00000233 : 0x00000001 : 0x00000256 : 0x00000001 : 0x00000262 : 0x00000001 : 0x0000026c : 0x00000001
: 0x0000026e : 0x00000001 : 0xc06d6100 : 0x0002aa00 : 0x00000004 : 0x00000000 : 0x00000006 : 0x00000008
: 0x00000006 : 0x0000000f : 0x00000009 : 0x00000020 : 0x00000001 : 0x00000080 : 0x00000004 : 0x0000008c
: 0x00000006 : 0x00000094 : 0x00000041 : 0x00000100 : 0x00000004 : 0x00000105 : 0x00000004 : 0x0000010b
: 0x00000003 : 0x0000010f : 0x00000078 : 0x00000191 : 0x00000021 : 0x000001b3 : 0x00000004 : 0x000001b8
: 0x00000001 : 0x000001ba : 0x00000001 : 0x000001c1 : 0x00000005 : 0x000001e0 : 0x00000008 : 0x000001f5
: 0x00000004 : 0x00000200 : 0x00000009 : 0x00000280 : 0x00000005 : 0x00000286 : 0x00000002 : 0x00000290
: 0x00000001 : 0x00000292 : 0x00000002 : 0x00000295 : 0x00000007 : 0x000002a1 : 0x00000001 : 0x000002a3
: 0x00000001 : 0x000002a5 : 0x00000001 : 0x000002a8 : 0x00000002 : 0x000002aa : 0x00000009 : 0x000002b4
: 0x00000002 : 0x000002b7 : 0x00000003 : 0x000002bb : 0x00000003 : 0x000002bf : 0x00000003 : 0x000002c3
: 0x00000001 : 0x000002ce : 0x00000001 : 0x000002d5 : 0x00000008 : 0x000002de : 0x00000009 : 0x000002f5
: 0x0000001b : 0x00000316 : 0x00000008 : 0x0000031f : 0x00000006 : 0x00000327 : 0x00000006 : 0x0000032e
: 0x00000006 : 0x00000336 : 0x00000006 : 0x0000033d : 0x00000006 : 0x00000345 : 0x00000006 : 0x0000034c
: 0x00000006 : 0x00000354 : 0x00000006 : 0x0000035b : 0x00000006 : 0x00000363 : 0x00000006 : 0x0000036a
: 0x00000006 : 0x00000372 : 0x00000006 : 0x00000379 : 0x00000006 : 0x00000381 : 0x00000006 : 0x00000388
: 0x00000006 : 0xc00d5f00 : 0x0002b900 : 0x00000004 : 0x00000000 : 0x0000001c : 0x00000040 : 0x0000001c
: 0x00000100 : 0x0000001c : 0x00000140 : 0x0000001c : 0x00000080 : 0x0000001c : 0x000000c0 : 0x0000001c
: 0xc0081000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000140 : 0x0000001c : 0x00000080 : 0x0000001c : 0x000000c0 : 0x0000001c
: 0xc0081000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0xc0012800 : 0x80010003 : 0x80010003 : 0xc0036000 : 0x0002a000 : 0x00000004
: 0x00000000 : 0x00000000 : 0xc0036100 : 0x0002aa00 : 0x00000004 : 0x00000000 : 0x00000000 : 0xc0035f00
: 0x0002b900 : 0x00000004 : 0x00000000 : 0x00000000 : 0x00000000 : 0xc0016900 : 0x000002a1 : 0x00000000
: 0xc0016900 : 0x000002ad : 0x00000000 : 0xc0026900 : 0x00000286 : 0x00000000 : 0x00000000 : 0xc0026900
: 0x000002d5 : 0x00000100 : 0x00000000 : 0xc0206900 : 0x00000191 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0xc0012800 : 0x80000002 : 0x80000000
: 0xc0012800 : 0x80000000 : 0x80000000 : 0xc0002a00 : 0x00000000 : 0xc0002f00 : 0x00000000 : 0xc0016800
: 0x00000256 : 0x00000000 : 0xc0046900 : 0x000002fa : 0x42320b61 : 0x3f800000 : 0x419068c8 : 0x3f800000
: 0xc0026900 : 0x000000b6 : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000115 : 0x44d70000 : 0x44d70000
: 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000b8 : 0x00000000 : 0x3f800000
: 0xc0066900 : 0x0000011b : 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000
: 0xc0026900 : 0x000000ba : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000121 : 0x44d70000 : 0x44d70000
: 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000bc : 0x00000000 : 0x3f800000
: 0xc0066900 : 0x00000127 : 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000
: 0xc0026900 : 0x000000be : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x0000012d : 0x44d70000 : 0x44d70000
: 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000c0 : 0x00000000 : 0x3f800000
: 0xc0066900 : 0x00000133 : 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000
: 0xc0026900 : 0x000000c2 : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000139 : 0x44d70000 : 0x44d70000
: 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000c4 : 0x00000000 : 0x3f800000
: 0xc0066900 : 0x0000013f : 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000
: 0xc0026900 : 0x000000c6 : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000145 : 0x44d70000 : 0x44d70000
: 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000c8 : 0x00000000 : 0x3f800000
: 0xc0066900 : 0x0000014b : 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000
: 0xc0026900 : 0x000000ca : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000151 : 0x44d70000 : 0x44d70000
: 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000cc : 0x00000000 : 0x3f800000
: 0xc0066900 : 0x00000157 : 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000
: 0xc0026900 : 0x000000ce : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x0000015d : 0x44d70000 : 0x44d70000
: 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x000000d0 : 0x00000000 : 0x3f800000
: 0xc0066900 : 0x00000163 : 0x44d70000 : 0x44d70000 : 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000
: 0xc0026900 : 0x000000d2 : 0x00000000 : 0x3f800000 : 0xc0066900 : 0x00000169 : 0x44d70000 : 0x44d70000
: 0xc4340000 : 0x44340000 : 0x3f800000 : 0x00000000 : 0xc0026900 : 0x0000008e : 0x0000000f : 0x0000000f
: 0xc0086900 : 0x000001e0 : 0x65010501 : 0x20010001 : 0x20010001 : 0x20010001 : 0x20010001 : 0x20010001
: 0x20010001 : 0x20010001 : 0xc0026900 : 0x00000003 : 0x00000000 : 0x00000080 : 0xc0036900 : 0x00000201
: 0x00301101 : 0x00cc0010 : 0x00000010 : 0xc0016900 : 0x00000207 : 0x00000000 : 0xc0016900 : 0x000002f8
: 0x00000000 : 0xc0016900 : 0x000001b1 : 0x00000002 : 0xc0046900 : 0x000001b3 : 0x00000002 : 0x00000002
: 0x0000246a : 0x00000002 : 0xc0016900 : 0x000001b8 : 0x01000000 : 0xc0036900 : 0x000001c3 : 0x00000004
: 0x00000000 : 0x00000004 : 0xc0026900 : 0x00000191 : 0x00000000 : 0x00000001 : 0xc0005300 : 0x00000000
: 0xc0047600 : 0x00000008 : 0x04032864 : 0x00000000 : 0x002c0082 : 0x00000014 : 0xc0047600 : 0x00000048
: 0x040064cb : 0x00000000 : 0x002c00c3 : 0x0000000c : 0xc00a7600 : 0x0000000c : 0x036f01f0 : 0x00000004
: 0x036f0000 : 0x00000004 : 0x00660230 : 0x00000004 : 0x036f01d0 : 0x00000004 : 0x036f0210 : 0x00000004
: 0xc0047600 : 0x0000004c : 0x00000000 : 0x00000000 : 0x036f0220 : 0x00000004 : 0xc0027600 : 0x0000004c
: 0x00000000 : 0x00000000 : 0xc0016800 : 0x00000256 : 0x00000004 : 0xc0002f00 : 0x00000001 : 0xc0012700
: 0x00000006 : 0x00000000 : 0xc0004600 : 0x00000410 : 0xc0004200 : 0x00000000 : 0xc0004600 : 0x00000016
: 0xc0005200 : 0x00000000 : 0xc0034300 : 0x82804000 : 0xffffffff : 0x00000000 : 0x00000004 : 0xc0034300
: 0x80800000 : 0xffffffff : 0x00000000 : 0x00000004 : 0xc0001700 : 0x00000001 : 0xc0044700 : 0x00000528
: 0x800a04a8 : 0x60000000 : 0x00000000 : 0x00000000 : 0xc0044700 : 0x00000514 : 0x80000000 : 0x22000000
: 0x00026bcb : 0x00000000 : 0x0000040f : 0xc0004600 : 0x00000410 : 0xc0016900 : 0x000001ba : 0x00000000
: 0xc0036900 : 0x000001c3 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000 : 0x00000000
: 0x00000000 : 0x00000000
: ** GPU Debug Info End **
Hardware could not be reset. Further submissions will not be accepted.
[ 2637.214676]:
[ 2637.214692]: Trying to restart GPU (AMD FirePro D300)...
[ 2637.217112]: AMD FAIL: >>> Recover Display: 1 \M-b\M^@\M^S LB stuck
[ 2637.217135]: AMD FAIL: >>> Disable DPM
[ 2637.217296]: AMD FAIL: <<< Disable DPM
[ 2637.217301]: AMD FAIL: <<< Recover Display: 1 - LB stuck
[ 2637.218465]: AMD FAIL: >>> Recover Display: 2 \M-b\M^@\M^S LB stuck
[ 2637.219521]: AMD FAIL: >>> Recover Display: 3 \M-b\M^@\M^S LB stuck
[ 2637.220617]: AMD FAIL: >>> Recover Display: 4 \M-b\M^@\M^S LB stuck
[ 2637.221779]: AMD FAIL: >>> Recover Display: 5 \M-b\M^@\M^S LB stuck
[ 2637.221805]: AMD FAIL: >>> Enable DPM
[ 2637.221808]: AMD FAIL: <<< Enable DPM
[ 2637.221871]: GPU restart previously failed and will not be attempted again.
[ 2637.224139]: AMD FAIL: >>> Recover Display: 1 \M-b\M^@\M^S LB stuck
[ 2637.224158]: AMD FAIL: >>> Disable DPM
[ 2637.224282]: AMD FAIL: <<< Disable DPM
[ 2637.224285]: AMD FAIL: <<< Recover Display: 1 - LB stuck
[ 2637.225426]: AMD FAIL: >>> Recover Display: 2 \M-b\M^@\M^S LB stuck
[ 2637.226468]: AMD FAIL: >>> Recover Display: 3 \M-b\M^@\M^S LB stuck
[ 2637.227565]: AMD FAIL: >>> Recover Display: 4 \M-b\M^@\M^S LB stuck
[ 2637.228664]: AMD FAIL: >>> Recover Display: 5 \M-b\M^@\M^S LB stuck
[ 2637.228687]: AMD FAIL: >>> Enable DPM
[ 2637.228690]: AMD FAIL: <<< Enable DPM
[ 2637.228695]: void IOAccelEventMachine2::restart_channel(): GPURestartEnd stampIdx=0 type=2
[ 2637.228709]: void IOAccelEventMachine2::hardwareErrorEvent(): setting restart type to 2 (channel 3)
[ 2637.228712]: void IOAccelEventMachine2::hardwareErrorEvent(): GPURestartDeferred stampIdx=3 type=2
[ 2637.228727]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228732]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228734]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228736]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228750]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228752]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228754]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228756]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228760]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228766]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228769]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228771]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228774]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228778]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228780]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228784]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.228786]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.239061]: void IOAccelEventMachine2::hardwareErrorEvent(): GPURestartDeferred stampIdx=3 type=2
[ 2637.239080]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.239083]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.239085]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.239089]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.239092]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.239094]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.239103]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.239105]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.239107]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.239111]: void IOAccelEventMachine2::handleFinishChannelRestart(IOReturn, int32_t, uint32_t): GPURestartDequeued stampIdx=3 type=2 fromWhere=2 waitingOnIdx=0
[ 2637.239115]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.239117]: virtual IOReturn IOAccelEventMachine2::waitForStamp(int32_t, stamp_t, stamp_t *): a graphics error occurred, exitting..
[ 2637.239119]: [6:0:0]: channel 3 event timeoutWhat is driving me crazy right now is that google search for "amd gpu driver macos recover display enable dpm" turns up nothing even remotely interesting. Same for "macpro amd fail DPM LB stuck". wtaf 😂
I must be lucky here, the pre-loved 6,1 I have seems to be stable on Big Sur 11.6.
I originally was a 2.4ghz 12 core with 1TB SSD, 64GB ram and twin-D700 graphics cards. I since upgraded the CPU to the 2.7ghz 12 core Xeon myself.
About the only issue I have is a flicker on the 4K display while connected with a mini-display port to display-port cable. It doesn't do this if I connect it using a HDMI cable or if I connect the computer to my Cinema Displays (27" and 30").
I suspect it's the cable. It doesn't run particularly hot either. The only thing I found when doing the CPU upgrade was the previous owner must have had it apart to do something inside it and lost one of the T5 screws for the power supply grill.
I will find a replacement.
I originally was a 2.4ghz 12 core with 1TB SSD, 64GB ram and twin-D700 graphics cards. I since upgraded the CPU to the 2.7ghz 12 core Xeon myself.
About the only issue I have is a flicker on the 4K display while connected with a mini-display port to display-port cable. It doesn't do this if I connect it using a HDMI cable or if I connect the computer to my Cinema Displays (27" and 30").
I suspect it's the cable. It doesn't run particularly hot either. The only thing I found when doing the CPU upgrade was the previous owner must have had it apart to do something inside it and lost one of the T5 screws for the power supply grill.
I will find a replacement.just for info: my MP d300 is running Mojave since years now without gpu crash! With any other OS before Mojave it crashed from time to time. i still hope Monterey final version will be stable because i want to use universal control. Any experiences wit Monterey are welcome!
You aren't lucky, you have hardware that doesn't use the same driver as the D300s. There was even a hardware replacement program for yours to address a thermal problem for 500s and 700s. The D300s are a different platform and use a different extension.
Well, you may be lucky, but not in this case
The title of this thread should reference D300 so people don’t get confused, but of course the Tahiti GPUs have had issues too. I think Apple just let them get too hot in the name of silence (low fan setting), but they actually did admit that indirectly when they said the thermal design was a failure. I don’t know if the Tahiti GPUs can overheat if you up the fan speed to maximum. It probably depends how hard you push them. I don’t think the fan will ever hit maximum with Apple’s settings and definitely not worth testing that hypothesis.
I think the 4K flicker over DP might indicate a thermal damaged GPU. My D700 does not flicker at 4K over DP. It could also be the cable or the monitor settings. A poor quality cable might not be providing the proper bandwidth.
I think the 4K flicker over DP might indicate a thermal damaged GPU. My D700 does not flicker at 4K over DP. It could also be the cable or the monitor settings. A poor quality cable might not be providing the proper bandwidth.
I am a relatively new user with these 6,1 Mac Pros, so not so many months or years of experience yet, maybe one year at max with tcMP 6c D300. I have had bad experiences with it from the beginning, with RAM putting out ECC errors frequently, and with sudden panics/restarts at sleep or at when working too (can't remember exactly the most frequent cases), but also just sitting there idle it could restart itself.
Yet, my D300 has lately been a lot more reliable if I don't let it sleep at all. I am not sure if I have had any kernel panics in normal use for quite a long time. I do remember working and getting a 10 day uptime at least, and then I rebooted myself. Of course the OS have updated too in between, so maybe Apple has done something with the drivers, I really don't know. I have fiddled with eGPU and such, and have been forced to do some forced shutdown though. I think that is because of non-supported eGPU on these 6,1s.
My D500 seems to be a more reliable machine from the sart, but extensive real world workload testing is yet to be performed on that. An eGPU will be present in this build too, so that might make a difference in my tests I think.
Yet, my D300 has lately been a lot more reliable if I don't let it sleep at all. I am not sure if I have had any kernel panics in normal use for quite a long time. I do remember working and getting a 10 day uptime at least, and then I rebooted myself. Of course the OS have updated too in between, so maybe Apple has done something with the drivers, I really don't know. I have fiddled with eGPU and such, and have been forced to do some forced shutdown though. I think that is because of non-supported eGPU on these 6,1s.
My D500 seems to be a more reliable machine from the sart, but extensive real world workload testing is yet to be performed on that. An eGPU will be present in this build too, so that might make a difference in my tests I think.
Actually no, because I had the same issues back in the day with 6c D500s model as well. After years of exploration and meeting people with the same issues all over the world (i found 3 machines on IBC fair 2018 on stand with the same error logs) I am 99% sure that this is hardware issue.
Just for the record, I bought new hardware and replaced my 6,1. I put the original Apple SSD back in and launched bootcamp and it hasn't crashed in weeks running Windows 10. I needed a Windows machine around anyway, and the 6,1 hauls ass. Won't run Windows 11 which is a shame cuz I rather like the changes introduced by 11, but that computer stopped ***** with me once I stopped running macOS. I'll try Monterey on it, I left macOS 128GB and gave the rest to Windows so I probably won't do any long-term testing or anything, but before you throw your trashcan6,1 into a dumpster considering running an OS that doesn't have a defective driver for the D300.
lol, AMD's software even immediately said "yo dawg i heard u like GPUs" and they're running in Crossfire now lolol something tells me I could probably install macOS via hypervisor and it'd be more reliable than installing macOS on the bare metal. it's embarassing but i'm glad i didn't have to put it on the shelf next to my Mac 512KE.
I've used virtualization for years to run software for oddball radios/scanners and some tools I have been meaning to try out relevant to my work. Windows' subsystem for linux is quite good btw, and these 6,1s are great docker hosts due to having ECC memory and a fast enough bus for storage. I've got an old OWC JBOD via thunderbolt hooked up now and I'm going to check out Storage Spaces because it looked like a cool technology. Lifelong learning for life over here.
lol, AMD's software even immediately said "yo dawg i heard u like GPUs" and they're running in Crossfire now lolol something tells me I could probably install macOS via hypervisor and it'd be more reliable than installing macOS on the bare metal. it's embarassing but i'm glad i didn't have to put it on the shelf next to my Mac 512KE.
I've used virtualization for years to run software for oddball radios/scanners and some tools I have been meaning to try out relevant to my work. Windows' subsystem for linux is quite good btw, and these 6,1s are great docker hosts due to having ECC memory and a fast enough bus for storage. I've got an old OWC JBOD via thunderbolt hooked up now and I'm going to check out Storage Spaces because it looked like a cool technology. Lifelong learning for life over here.
i upgraded my trashcan6,1 with D300s to Monterey on the macOS side of the workstation. i haven't installed much software or anything, just OpenZFS and a bootstrap'ed Homebrew environment. i am curious if the updated extension for the D300s addressed any instability issues. No watchdog kernel panics yet but it's only been running for 20 hours while i do a large migration between pools.
not a single gpu crash dump in `DiagnosticReports` either, though like i said not much going on with it right now, so maybe someone in software engineering at Apple has done us a solid and fixed a bug? g-d knows they've gotten plenty of crashdumps and panics submitted. how many of us are out there still running 6,1s with D300 and tracking current release of macOS? couple thousand? i wasn't expecting anything to ever be done about it but who knows.
kextstat on Monterey:
not a single gpu crash dump in `DiagnosticReports` either, though like i said not much going on with it right now, so maybe someone in software engineering at Apple has done us a solid and fixed a bug? g-d knows they've gotten plenty of crashdumps and panics submitted. how many of us are out there still running 6,1s with D300 and tracking current release of macOS? couple thousand? i wasn't expecting anything to ever be done about it but who knows.
kextstat on Monterey:
Code:
emory@DreamOn ~ % kextstat |grep AMD
Executing: /usr/bin/kmutil showloaded
No variant specified, falling back to release
129 2 0xffffff7f96c0d000 0xcb000 0xcb000 com.apple.kext.AMDSupport (4.0.7) 61E40B4A-8B3E-3569-85EB-250CD91E8EB1 <109 108 16 15 9 7 6 3 1>
130 0 0xffffff7f80e5c000 0x56000 0x56000 com.apple.kext.AMD7000Controller (4.0.7) 7F1162EC-D382-3EF1-AC58-8F873717C45C <129 109 108 16 15 7 6 3 1>
156 0 0xffffff7f814fc000 0x4000 0x4000 com.apple.kext.AMDRadeonX4000HWServices (4.0.7) B3551921-FA0C-35D7-9B75-65B82699A59F <108 16 15 9 7 6 3 1>
161 0 0xffffff7f81044000 0x461000 0x461000 com.apple.kext.AMDRadeonX4000 (4.0.7) 45CB4427-5148-335B-8FA2-D5A2002CB6BC <160 108 90 16 9 7 6 3 1>
163 0 0xffffff7f8103e000 0x3000 0x3000 com.apple.kext.AMDRadeonServiceManager (4.0.7) 6E068EEE-90BD-32C8-82B3-984C59B706D6 <16 6 3 1>
164 0 0xffffff7f82670000 0xf5000 0xf5000 com.apple.kext.AMDRadeonX4030HWLibs (1.0) 42AF6296-47C2-3FE3-9EFB-D35DFDCBBC6E <16 7 6 3 1>
165 0 0xffffff7f81013000 0x26000 0x26000 com.apple.kext.AMDFramebuffer (4.0.7) 0E573FD7-F1EF-3237-86D1-12C11C80C1FA <129 108 16 15 9 7 6 3 1>
