Hi All,
I can not create the USB bootable pendrive for install macOS Sierra on Mac mini (Late 2009) - 2.26 GHz Intel Core 2 Duo processor - 2GB DDR3 1067 MHz memory - NVIDIA GeForce 9400 graphics 256MB - OS X 10.11.6 El Capitan (Build 15G1510) - System Integrity Protection: Disabled.
For the creation I use
macOS Sierra Patcher Tool version
4.2.7 and
install macOS Sierra.app 10.12.4 (Build 16E195) version
12.4.06 which includes:
Code:
"Install macOS Sierra.app/Contents/SharedSupport/InstallESD.dmg"
MD5: dbfc61de97e8ee9093ee965e6e969639
SHA1: 30b9245f7c7608c40bbdf4d4a74f3ab84dbac716
As a USB device I use a 16GB pendrive formatted in HFS+ (journaled) with GUID partition map, volume name "
install".
At the beginning of phase "
Patching files..." the USB pendrive is mounted on the desktop as "
OS X Base System" but, after a few seconds, the name returns to the one attributed in "
Disk Utility" and that is "
install" and remains even when the phase is completed (it takes about 40 minutes).
Also, verifying the format of pendrive at the end of the procedure is in HFS+ (not journaled).
Is this normal?
Trying to boot with the Alt/Option key presses displays a USB drive with the name "
OS X Base System" (although the pendrive has not changed the name in the Finder) but, selecting it, the Apple logo appears for a few seconds, immediately afterwards, the prohibition signal.
What can I do?
Finally, the following messages are logged in the Console during the creation phase, which may be related to the problem:
Code:
11:49:35 macOS Sierra Patcher[504]: NSDocumentController Info.plist warning: The values of CFBundleTypeRole entries must be 'Editor', 'Viewer', 'None', or 'Shell'.
11:49:35 appleeventsd[50]: SecTaskLoadEntitlements failed error=22
11:49:40 launchservicesd[77]: SecTaskLoadEntitlements failed error=22
11:49:40 launchservicesd[77]: SecTaskLoadEntitlements failed error=22
11:49:46 sharedfilelistd[267]: SecTaskLoadEntitlements failed error=22
11:49:48 pkd[273]: SecTaskLoadEntitlements failed error=22
11:49:48 tccd[255]: SecTaskLoadEntitlements failed error=22
11:49:48 tccd[255]: SecTaskLoadEntitlements failed error=22
11:49:48 tccd[255]: SecTaskLoadEntitlements failed error=22
11:49:49 WindowServer[172]: SecTaskLoadEntitlements failed error=22
11:49:49 tccd[268]: SecTaskLoadEntitlements failed error=22
11:49:50 macOS Sierra Patcher[504]: assertion failed: 15G1510: libxpc.dylib + 78286 [2819674A-621A-3ACB-9657-DF42353D6CFD]: 0x89
11:49:50 launchservicesd[77]: SecTaskLoadEntitlements failed error=22
11:50:10 launchservicesd[77]: SecTaskLoadEntitlements failed error=22
11:50:15 kernel[0]: hfs: mounted OS X Install ESD on device disk4s2
11:50:15 mds[61]: (Volume.Normal:2464) volume:0x7fefb8975e00 ********** Bootstrapped Creating a default store:1 SpotLoc:(null) SpotVerLoc:(null) occlude:0 /Volumes/OS X Install ESD
11:50:16 diskimages-helper[510]: *** -[NSMachPort handlePortMessage:]: dropping incoming DO message because the connection is invalid
11:50:20 SecurityAgent[522]: activateIgnoringOtherApps:1
11:50:21 SecurityAgent[522]: makeKeyAndOrderFront
11:50:21 SecurityAgent[522]: com.apple.SecurityAgent.consoleLogin.UIShown
11:50:25 authexec[525]: executing /usr/sbin/asr
11:50:26 mdworker[483]: (ImportBailout.Error:1331) Asked to exit for Diskarb
11:50:26 mdworker[484]: (ImportBailout.Error:1331) Asked to exit for Diskarb
11:50:37 diskarbitrationd[67]: macOS Sierra Patcher [504]:59139 not responding.
11:50:37 kernel[0]: hfs: unmount initiated on install on device disk2s2
11:50:37 deleted[301]: normalizeUserMountpoint:791 volRoot failed for /Volumes/install
11:50:37 deleted[301]: _validateVolume:813 unable to normalize volume: "/Volumes/install", vol: (null)
11:52:02 kernel[0]: process macOS Sierra Pat[504] thread 13002 caught burning CPU! It used more than 50% CPU (Actual recent usage: 82%) over 180 seconds. thread lifetime cpu usage 90.000509 seconds, (28.005351 user, 61.995158 system) ledger info: balance: 90000050328 credit: 90000050328 debit: 0 limit: 90000000000 (50%) period: 180000000000 time since last refill (ns): 109565682186
11:52:02 com.apple.xpc.launchd[1]: Endpoint has been activated through legacy launch(3) APIs. Please switch to XPC or bootstrap_check_in(): com.apple.ReportCrash
11:52:02 ReportCrash[529]: Invoking spindump for pid=504 thread=13002 percent_cpu=82 duration=110 because of excessive cpu utilization
11:52:19 spindump[395]: Saved cpu_resource.diag report for macOS Sierra Patcher version 4.2.7 (???) to /Library/Logs/DiagnosticReports/macOS Sierra Patcher_2017-06-27-115219_Mac-mini.cpu_resource.diag
11:55:18 syslogd[42]: ASL Sender Statistics
12:02:11 kernel[0]: hfs: mounted OS X Base System on device disk2s2
12:02:13 mds[61]: (Volume.Normal:2464) volume:0x7fefb9226000 ********** Bootstrapped Creating a default store:3 SpotLoc:/Volumes/OS X Base System/.Spotlight-V100 SpotVerLoc:/Volumes/OS X Base System/.Spotlight-V100/Store-V1 occlude:0 /Volumes/OS X Base System
12:02:13 fseventsd[46]: could not open <</Volumes/OS X Base System/.fseventsd/fseventsd-uuid>> (No such file or directory)
12:02:13 fseventsd[46]: Failed to load UUID. Removing all old log files in /Volumes/OS X Base System/.fseventsd
12:02:13 fseventsd[46]: log dir: /Volumes/OS X Base System/.fseventsd getting new uuid: BA49DB96-FF94-4819-AEF1-7EF5862FE5E2
12:02:15 com.apple.kextd[45]: Note: /Volumes/OS X Base System/System/Library/Kernels/kernel: No such file or directory
12:02:17 com.apple.kextd[45]: Note: /Volumes/install/System/Library/Kernels/kernel: No such file or directory
12:02:18 mds[61]: (Server.Error:221) Failed to register path "/Volumes/install" to store <MDSStoreToken: 0x7fefbaf70f00>{storeID:0x6b0000c0 registered:YES private:NO age:<1ms uuid:0BD97B97-7B07-4618-960E-5A5AA5C91211}
12:02:18 deleted[301]: normalizeUserMountpoint:791 volRoot failed for /Volumes/OS X Base System
12:02:18 deleted[301]: _validateVolume:813 unable to normalize volume: "/Volumes/OS X Base System", vol: (null)
12:02:20 lsd[239]: LaunchServices: Could not store lsd-identifiers file at /private/var/db/lsd/com.apple.lsdschemes.plist
12:02:28 mds[61]: (DiskStore.Normal:644) SDB consistency check starting
12:02:28 mds[61]: (DiskStore.Normal:2407) _importFilesWithUTIs maxCount:0 regularImport:1 queued:0
12:02:28 mds[61]: (DiskStore.Normal:2407) _importFilesWithUTIs maxCount:0 regularImport:1 queued:0
12:02:28 mds[61]: (DiskStore.Normal:2407) _importFilesWithUTIs maxCount:0 regularImport:1 queued:0
12:02:28 mds[61]: (DiskStore.Normal:2407) _importFilesWithUTIs maxCount:0 regularImport:1 queued:0
12:02:28 mds[61]: (DiskStore.Normal:2407) _importFilesWithUTIs maxCount:10000 regularImport:0 queued:0
12:02:28 mds[61]: (DiskStore.Normal:2407) _importFilesWithUTIs maxCount:0 regularImport:1 queued:0
12:02:28 mds[61]: (DiskStore.Normal:659) SDB consistency check complete for 0 items
12:05:19 syslogd[42]: ASL Sender Statistics
12:15:20 syslogd[42]: ASL Sender Statistics
12:17:50 lsd[239]: LaunchServices: Could not store lsd-identifiers file at /private/var/db/lsd/com.apple.lsdschemes.plist
12:18:06 lsd[239]: LaunchServices: Could not store lsd-identifiers file at /private/var/db/lsd/com.apple.lsdschemes.plist
12:18:06 lsd[239]: LaunchServices: Could not store lsd-identifiers file at /private/var/db/lsd/com.apple.lsdschemes.plist
12:19:14 lsd[239]: LaunchServices: Could not store lsd-identifiers file at /private/var/db/lsd/com.apple.lsdschemes.plist
12:19:56 lsd[239]: LaunchServices: Could not store lsd-identifiers file at /private/var/db/lsd/com.apple.lsdschemes.plist
12:21:22 mds[61]: (DiskStore.Normal:2382) 9001 1.129801
12:21:29 lsd[239]: LaunchServices: Could not store lsd-identifiers file at /private/var/db/lsd/com.apple.lsdschemes.plist
12:21:50 lsd[239]: LaunchServices: Could not store lsd-identifiers file at /private/var/db/lsd/com.apple.lsdschemes.plist
12:25:21 syslogd[42]: ASL Sender Statistics
12:33:20 com.apple.xpc.launchd[1]: Service exited due to signal: Killed: 9
12:33:22 com.apple.xpc.launchd[1]: Endpoint has been activated through legacy launch(3) APIs. Please switch to XPC or bootstrap_check_in(): com.apple.quicklook
12:35:21 syslogd[42]: ASL Sender Statistics
12:35:53 com.apple.kextd[45]: Note: /Volumes/install/System/Library/Kernels/kernel: No such file or directory
12:36:06 cp[577]: setting security information: Operation not permitted
12:36:06 kernel[0]: memorystatus_thread: idle exiting pid 66 [iconservicesagen]
12:36:07 sandboxd[145]: cp(577) System Policy: allow file-write-mode /System/Library/PrelinkedKernels/prelinkedkernel
12:36:07 kernel[0]: memorystatus_thread: idle exiting pid 71 [wdhelper]
12:36:08 kernel[0]: memorystatus_thread: idle exiting pid 142 [com.apple.audio.]
12:36:09 kernel[0]: memorystatus_thread: idle exiting pid 164 [secinitd]
12:36:10 kernel[0]: memorystatus_thread: idle exiting pid 154 [ctkd]
12:36:11 kernel[0]: memorystatus_thread: idle exiting pid 99 [amfid]
12:36:11 com.apple.kextd[45]: Note: /Volumes/install/System/Library/Kernels/kernel: No such file or directory
12:36:12 kernel[0]: memorystatus_thread: idle exiting pid 211 [com.apple.Ambien]
12:36:13 kernel[0]: memorystatus_thread: idle exiting pid 201 [nsurlsessiond]
12:36:14 kernel[0]: memorystatus_thread: idle exiting pid 288 [findmydeviced]
12:36:15 kernel[0]: memorystatus_thread: idle exiting pid 289 [CloudKeychainPro]
12:36:16 kernel[0]: memorystatus_thread: idle exiting pid 248 [nsurlsessiond]
12:36:17 kernel[0]: memorystatus_thread: idle exiting pid 324 [CallHistoryPlugi]
12:36:18 nsurlsessiond[585]: No directory for bundleID: com.apple.cloudd
12:36:18 kernel[0]: memorystatus_thread: idle exiting pid 320 [akd]
12:36:20 kernel[0]: memorystatus_thread: idle exiting pid 337 [com.apple.InputM]
12:36:20 mdworker[565]: (ImportBailout.Error:1331) Asked to exit for Diskarb
12:36:20 mdworker[569]: (ImportBailout.Error:1331) Asked to exit for Diskarb
12:36:21 kernel[0]: hfs: unmount initiated on OS X Install ESD on device disk4s2
12:36:24 com.apple.kextd[45]: Note: /Volumes/install/System/Library/Kernels/kernel: No such file or directory
12:36:46 lsd[239]: LaunchServices: Could not store lsd-identifiers file at /private/var/db/lsd/com.apple.lsdschemes.plist
12:36:47 lsd[239]: LaunchServices: Could not store lsd-identifiers file at /private/var/db/lsd/com.apple.lsdschemes.plist
12:36:49 lsd[239]: LaunchServices: Could not store lsd-identifiers file at /private/var/db/lsd/com.apple.lsdschemes.plist
12:37:32 mds[61]: (DiskStore.Normal:2382) b002 1.000029
12:38:02 mds[61]: (DiskStore.Normal:2382) b002 1.000052
Thank you all!
