Hi all, my Mac Pro 3.1 crash on sleep.
There is a know fix for this?
Thanks
Report:
There is a know fix for this?
Thanks
Report:
Code:
panic(cpu 2 caller 0xffffff8013aa1c6c): Sleep transition timed out after 180 seconds while calling power state change callbacks. Suspected bundle: __kernel__. Thread 0xa5be.
Failure code:: 0x00001000 00000014
Backtracing specified thread
Backtrace (CPU 2), Frame : Return Address
0xffffff823b8db900 : 0xffffff801345dc88
0xffffff823b983ab0 : 0xffffff801335b5b1
0xffffff823b983b20 : 0xffffff8013359daf
0xffffff823b983b70 : 0xffffff801331ba11
0xffffff823b983bb0 : 0xffffff80133406eb
0xffffff823b983c00 : 0xffffff8013a84627
0xffffff823b983c60 : 0xffffff8013a8423a
0xffffff823b983cb0 : 0xffffff80139f68b2
0xffffff823b983dc0 : 0xffffff8013a808cd
0xffffff823b983e00 : 0xffffff8013a26a6b
0xffffff823b983ea0 : 0xffffff8013a26464
0xffffff823b983ec0 : 0xffffff801337b625
0xffffff823b983f40 : 0xffffff801337b151
0xffffff823b983fa0 : 0xffffff80132e013e
BSD process name corresponding to current thread: kernel_task
Boot args: -no_compat_check
Mac OS version:
19B88
Kernel version:
Darwin Kernel Version 19.0.0: Thu Oct 17 16:17:15 PDT 2019; root:xnu-6153.41.3~29/RELEASE_X86_64
Kernel UUID: 7503CD47-851F-321E-8747-50DB4299165F
Kernel slide: 0x0000000013000000
Kernel text base: 0xffffff8013200000
__HIB text base: 0xffffff8013100000
System model name: MacPro3,1 (Mac-F42C88C8)
System shutdown begun: NO
Panic diags file available: YES (0x0)
System uptime in nanoseconds: 3976172730394
last loaded kext at 2930916977991: >usb.cdc 5.0.0 (addr 0xffffff7f96c10000, size 28672)
last unloaded kext at 324667129815: @filesystems.msdosfs 1.10 (addr 0xffffff7f96bde000, size 61440)
loaded kexts:
com.getdropbox.dropbox.kext 1.10.3
com.adguard.nfext 27
com.Ralink.driver.RT2870USBWirelessDriver 5.0.1
at.obdev.nke.LittleSnitch 5430
AAA.LoadEarly.MouSSE 0.38
com.parrotgeek.SIPManager 1
@filesystems.smbfs 3.4
@fileutil 20.036.15
@filesystems.autofs 3.0
>!AGraphicsDevicePolicy 4.5.9
@AGDCPluginDisplayMetrics 4.5.9
>!AHDA 281.52
>!AHV 1
>!AUpstreamUserClient 3.6.8
|IOUserEthernet 1.0.1
>!AMCCSControl 1.13
|IO!BSerialManager 7.0.1f1
@GeForce 14.0.0
>pmtelemetry 1
@Dont_Steal_Mac_OS_X 7.0.0
>!A!ISlowAdaptiveClocking 4.0.0
>ACPI_SMC_PlatformPlugin 1.0.0
|CSR!BHost!CUSBTransport 7.0.1f1
>AudioAUUC 1.70
>!ALPC 3.1
>!AFWOHCI 5.6.2
>!UDisplays 380
|SCSITaskUserClient 422.0.2
>!AVirtIO 1.0
@filesystems.hfs.kext 522.0.9
@!AFSCompression.!AFSCompressionTypeDataless 1.0.0d1
@BootCache 40
@!AFSCompression.!AFSCompressionTypeZlib 1.0.0
@filesystems.apfs 1412.41.1
>!AAHCIPort 341.0.2
>!A!IPIIXATA 2.5.1
>!A!I8254XEthernet 3.1.5
@private.KextAudit 1.0
>AirPort.Atheros40 700.74.5
>!AACPIButtons 6.1
>!ARTC 2.0
>!AHPET 1.8
>!ASMBIOS 2.1
>!AACPIEC 6.1
>!AAPIC 1.7
>!A!ICPUPowerManagementClient 222.0.0
$!AImage4 1
@nke.applicationfirewall 303
$TMSafetyNet 8
@!ASystemPolicy 2.0.0
>!A!ICPUPowerManagement 222.0.0
|EndpointSecurity 1
>usb.cdc 5.0.0
>!AHIDKeyboard 209
@kext.triggers 1.0
|IOFireWireIP 2.3.0
>!AGraphicsControl 4.5.9
>DspFuncLib 281.52
@kext.OSvKernDSPLib 529
|IOAVB!F 800.17
>!ASMBus!C 1.0.18d1
>!ASSE 1.0
@nvidia.driver.NVDAGK100Hal 14.0.0
|IOAccelerator!F2 438.2.7
@nvidia.driver.NVDAResman 14.0.0
|IONDRVSupport 568
@!AGPUWrangler 4.5.9
@!AGraphicsDeviceControl 4.5.9
|IOSlowAdaptiveClocking!F 1.0.0
>IOPlatformPluginLegacy 1.0.0
>!AHDA!C 281.52
|IOHDA!F 281.52
|IO!BHost!CUSBTransport 7.0.1f1
|IO!BHost!CTransport 7.0.1f1
|IO!B!F 7.0.1f1
|IO!BPacketLogger 7.0.1f1
|IOGraphics!F 568
>IOPlatformPlugin!F 6.0.0d8
|IOFireWire!F 4.7.5
@plugin.IOgPTPPlugin 810.1
|IOEthernetAVB!C 1.1.0
|IOSkywalk!F 1
>!UHIDMouse 192
>!AHIDMouse 192
|IOUSBHIDDriver 900.4.2
>usb.IOUSBHostHIDDevice 1.2
>!UAudio 320.49
|IOAudio!F 300.2
@vecLib.kext 1.2.0
>usb.networking 5.0.0
>usb.!UHostCompositeDevice 1.2
>usb.!UHub 1.2
|IOSCSIMultimediaCommandsDevice 422.0.2
|IOBD!S!F 1.8
|IODVD!S!F 1.8
|IOCD!S!F 1.8
|IOSerial!F 11
@filesystems.hfs.encodings.kext 1
|IOSurface 269.6
|IOATAPIProtocolTransport 3.5.0
|IOAHCIBlock!S 316.40.3
|IOAHCI!F 290.0.1
|IOATA!F 2.5.3
|IO80211!F 1200.12.2
>corecapture 1.0.4
>usb.!UEHCIPCI 1.2
>usb.!UUHCIPCI 1.2
>usb.!UUHCI 1.2
>usb.!UEHCI 1.2
>usb.!UHostPacketFilter 1.0
|IOUSB!F 900.4.2
>!AEFINVRAM 2.1
>!AEFIRuntime 2.1
|IOSMBus!F 1.1
|IOHID!F 2.0.0
$quarantine 4
$sandbox 300.0
@kext.!AMatch 1.0.0d1
>DiskImages 493.0.0
>!AFDEKeyStore 28.30
>!AEffaceable!S 1.0
>!AKeyStore 2
>!UTDM 489.41.1
|IOSCSIBlockCommandsDevice 422.0.2
>!ACredentialManager 1.0
>KernelRelayHost 1
>!ASEPManager 1.0.1
>IOSlaveProcessor 1
|IOUSBMass!SDriver 157.40.7
|IOSCSIArchitectureModel!F 422.0.2
|IO!S!F 2.1
|IOUSBHost!F 1.2
>!UHostMergeProperties 1.2
>usb.!UCommon 1.0
>!ABusPower!C 1.0
|CoreAnalytics!F 1
>!AMobileFileIntegrity 1.0.5
@kext.CoreTrust 1
|IOTimeSync!F 810.1
|IONetworking!F 3.4
|IOReport!F 47
>!AACPIPlatform 6.1
>!ASMC 3.1.9
>watchdog 1
|IOPCI!F 2.9
|IOACPI!F 1.4
@kec.pthread 1
@kec.Libm 1
@kec.corecrypto 1.0
The usb BT 4.0 dongle is good, then follow these steps:
- From Catalina Desktop, plug the BT 4.0 to any usb port, and check that it automatically starts blinking with the blue-led (without installing any additional driver)
- From Catalina Terminal copy/paste this:
sudo mount -uw / ; killall Finderand this:
ioreg -l | grep "board-id"then from Terminal you have to copy/paste in one line this:
sudo /usr/libexec/PlistBuddy -c "Set:Mac-YOURBOARDIDNUMBERS:ContinuitySupport true" "/System/Library/Frameworks/IOBluetooth.framework/Versions/A/Resources/SystemParameters.plist"
After you enter those commands reboot, if you still don't have Continuity features, try from System Preferences iCloud prefpane to sign-out and sign-in again from the unsupported Catalina Mac.
edit: I made a script to automatically fix continuity on Catalina, attached here: catalinacontinuityfix.command.zip
edit2: To fix continuity with a third party usb bluetooth 4.0 dongle: Catalina IOBluetoothFamily pre-patched for usb Bluetooth 4.0 dongles
Last edited:
I would suspect the RT2870 driver as the culprit as they have had sleep issues in the past. Is the installed RT2870 driver explicitly certified as Catalina compatible?
Do we have to go through all that kext , sh patching again for hands-off, continuity to work[automerge]1574533436[/automerge]
Got macOS Catalina 10.15.2 Dev 3 installed iPhoto,Photos,Music,iTunes,Maps and they even fixed Airplay
I don't know, I made a fresh installation with dosdude tool.
How can I verify the driver version?
Thanks
About Catalina OTA updates using the @dosdude1 Sierra's swupatch.sh and @Czo's SUVMMFaker.dylib and @Pinarek method of whitelisting the OTA .dist file, I've tested them right now "OTA upgrading" from 10.15.0 to 10.15.1 (about 4,5 gb download) and from 10.15.1 to 10.15.2 beta 3 (about 3 gb download) and they worked without issues and without triggering any unwanted firmware updates.
- Download this script: Sierra's swupatch.sh for Catalina
- Open a Catalina Terminal and copy/paste this:
- drag the swupatch.sh onto the Terminal window and press enter
now you can even download an update from Terminal, but I'd advise to do that from Catalina Software Update prefpane
before OTA update download and install, I advise to put the Software Update settings in this way without selecting any automatic Catalina update (maybe leave checked only "Check for updates"):
After the OTA update is detected, click the "Update Now" button and I advise to click "Not Now", because after the OTA is downloaded you need some extra-minutes to edit a simple text file
After the OTA is downloaded go to this folder: /Library/Updates/XXX-XXXXX/
and edit this file XXX-XXXXX.languageID.dist (if it is locked, copy it temporary on Desktop to edit and then replace again the one there)
Now from Catalina Terminal get your board-id and model identifier:
Opening with a Plain-text editor the OTA .dist file scrolling till the part showed in the example, add inside your board-id here:
remove'MacExample7,1', your machine model here:
save/close and replace this edited file with the one inside /Library/Updates/XXX-XXXXX/
Return to the Sofware Update prefpane, and click "Update Now" button.
After the update installation completes, if you have a Core2Duo you'll encounter a bootloop (due to the telemetry plugin), then simply hold alt-option key at power-on, boot with the USB Patcher, apply the post-install patches to the Catalina Volume, and you'll have a working OTA updated system.
Another useful part is that the OTA update will also auto-fix the APFS Recovery putting back the stock Catalina BaseSystem.dmg (CMD+R should work provided that you have -no_compat_check in nvram).
- Download this script: Sierra's swupatch.sh for Catalina
- Open a Catalina Terminal and copy/paste this:
sudo mount -uw / ; killall Finder- drag the swupatch.sh onto the Terminal window and press enter
now you can even download an update from Terminal, but I'd advise to do that from Catalina Software Update prefpane
before OTA update download and install, I advise to put the Software Update settings in this way without selecting any automatic Catalina update (maybe leave checked only "Check for updates"):
After the OTA update is detected, click the "Update Now" button and I advise to click "Not Now", because after the OTA is downloaded you need some extra-minutes to edit a simple text file
After the OTA is downloaded go to this folder: /Library/Updates/XXX-XXXXX/
and edit this file XXX-XXXXX.languageID.dist (if it is locked, copy it temporary on Desktop to edit and then replace again the one there)
Now from Catalina Terminal get your board-id and model identifier:
ioreg -l | grep "board-id" ; sysctl -n hw.modelOpening with a Plain-text editor the OTA .dist file scrolling till the part showed in the example, add inside your board-id here:
Code:
function InstallationCheck(prefix) {
var boardIds = ['Mac-yourboardnumber','Mac-9AE82516C7C6B903', etcremove
Code:
var nonSupportedModels = ['MacBookPro4,1','MacExample7,1', etcsave/close and replace this edited file with the one inside /Library/Updates/XXX-XXXXX/
Return to the Sofware Update prefpane, and click "Update Now" button.
After the update installation completes, if you have a Core2Duo you'll encounter a bootloop (due to the telemetry plugin), then simply hold alt-option key at power-on, boot with the USB Patcher, apply the post-install patches to the Catalina Volume, and you'll have a working OTA updated system.
Another useful part is that the OTA update will also auto-fix the APFS Recovery putting back the stock Catalina BaseSystem.dmg (CMD+R should work provided that you have -no_compat_check in nvram).
Attachments
Last edited:
Hi,
I'm gonna try to upgrade a 13" Macbook Pro from early 2011 to Catalina.
The problem is that the L-SHIFT key is damaged and always on. On a daily basis, it is deactivated with Karabiner and I start the laptop with some random keys pressed to prevent a start in safe mode (Karabiner only works after start).
That prevents me from doing operations like booting on another drive (with the ALT key being cancelled by L-SHIFT) or even installing any upgrade that would require a few reboots.
That's why I'm planning to perform the upgrade by putting my SSD into another computer (a 13" Macbook Pro from 2010) and putting it back afterwards.
My questions are: Will there be any problem with that operation? Are there any differences between the way Catalina is patched for a MBP 2011 from MBP 2010? Is the installation also performing a firmware upgrade on any other component?
Has anyone done something similar?
Thanks in advance!
I'm gonna try to upgrade a 13" Macbook Pro from early 2011 to Catalina.
The problem is that the L-SHIFT key is damaged and always on. On a daily basis, it is deactivated with Karabiner and I start the laptop with some random keys pressed to prevent a start in safe mode (Karabiner only works after start).
That prevents me from doing operations like booting on another drive (with the ALT key being cancelled by L-SHIFT) or even installing any upgrade that would require a few reboots.
That's why I'm planning to perform the upgrade by putting my SSD into another computer (a 13" Macbook Pro from 2010) and putting it back afterwards.
My questions are: Will there be any problem with that operation? Are there any differences between the way Catalina is patched for a MBP 2011 from MBP 2010? Is the installation also performing a firmware upgrade on any other component?
Has anyone done something similar?
Thanks in advance!
Why don´t you disconnect the internal keyboard and use an USB one?
Sehr geehrter [USER = 1133911] @jackluke [/ USER] .. das ist eigentlich, außer ich hatte es bereits getan, mit der alten High Sierra swupdate.sh-Datei.
.
.
I also have the same issue with Catalina, iMac11,1with radeon 4850.issue is definitely with the color depth. dropping it fixes the photo issue. Also I notice iMovies will only play the sound but, no preview of the video.
videos will play fine on photos, QuickTime, vlc or any video player for that matter but iMovies or Final Cut will not show you the preview (just a black preview window).
reinstall this version of iMovie and the newest release requires metal which our unsupported Macs don't have
https://forums.macrumors.com/thread....2183772/page-251?post=27935151#post-27935151
Isn’t the power button part of the keyboard on the macbooks without optical drive? (Not sure of the exact config of said laptop)
Yes, that's a good idea! I haven't tried yet because disconnecting the keyboard is cumbersome but I might try that first. I have an official Apple USB keyboard from about the same time as the MacBook.
The two MacBook Pros I'm talking about have an optical drive and the power button is separated from the keyboard.
But apart from this method (which might very well be the best, you are right!), is there anything I need to understand regarding the patches? Are there specific to every model? To every graphic card, processor?
Bonus question: Is it possible to use the latest versions of Keynote and Pages after upgrading a 2011 MBP to Catalina? One of the only reasons to upgrade is that I want to be able to edit shared iCloud documents, which requires them.
anyone help? I cannot do any installation or upgrade right now. no matter which version...
I can only boot to Mojave in my external SSD.
Boot to Catalina patch USB, Mojave USB installation disk, Recovery partition all are in same situation.
Is it any problem with the EFI or Boot partition?
NVRAM reset, SIP enable, SMC reset all tried...
SIP needs to be disabled at all times
hi, replace with what ? I see frameworks directory, but what to replace with ?
If Catalina that I can understand but even i put Mojave USB installation disk which 5,1 is support. I still cannot install. I can only restore the system from time machine. It will show the installation application is damaged
Tried all of those instructions, but still not working. I did upgrade it from Mojave, so not a clean install. I can do a clean install unless there is something else I can do.
Hope you downloaded latest version of Mojave from apple site. They have been revoking certain certificates of mac OS Installers. So download again and try. Also ensure SIP is disabled of your computer.
