MP 1,1-5,1 Mojave random kernel panic on Mac Pro 4.1 -> 5.1

A

Aidzer0

macrumors newbie
Original poster
Jun 29, 2021
26
7
Hello all, I have a 4.1 > 5.1 mac pro (2009), it has the 144.0.0.0 firmware on it, 4x 8TB HDD's, AMD 7950 GPU, 2x X5680 CPU's and 8x 8gb RAM (64GB). Mojave is running off of a 500GB Samsung SATA drive.

I have had this Mac Pro for 5 years now with absolutely no issues, up until a year ago one of my CPU's died (No boot unless the faulty CPU was taken out), I replaced both the CPU's with X5680 chips, the CPU that died came with the mac and I don't know what it experienced.

I have had no issues at all with the Mac up until 2 weeks ago, I have been experiencing Kernel panics on a daily basis, I have run AHT with no faults/alerts besides the videocontroller alert (which I read was normal for 4.1 -> 5.1 upgraded machines). I have just about done every test that I have read about on here and various other sites and nothing is giving me any hope for fixing this.

Something worrisome I have found is that one CPU heat sink is a lot hotter than the other (The one closest to the back runs hotter), maybe because its getting heat from the front one?

The main role for this machine is a Plex server. The Kernel Panics happen during plex transcoding.

The kernel panics are of the reboot flavour, they all point me to power delivery of some sort, but I dont have the Mac knowledge to pursue this further, any help is welcome, the panic is traced back to the AppleIntelCPUPowerManagement.kext, the affected Processors are all over the board, each panic event seems to have a different processor number.

I am currently trying to get ASD 3S130 to run, but its not going past the Loading screen of both OS and EFI, I am now downloading a different version (3S132).

I have done a lot more than I have listed, but I am flat lining at the moment after 3 weeks of troubleshooting...

Thank you!

A

Aidzer0

macrumors newbie
Original poster
Jun 29, 2021
26
7
I attached the .panic files but that got removed, here they are in plain text.
Code:
Anonymous UUID:       8E0358CA-108C-D1D3-D673-EF9EB9B03E1C

Wed Aug 18 01:32:23 2021

*** Panic Report ***
Machine-check capabilities: 0x0000000000001c09
family: 6 model: 44 stepping: 2 microcode: 31
signature: 0x206c2
Intel(R) Xeon(R) CPU           X5680  @ 3.33GHz
9 error-reporting banks
Processor 14: IA32_MCG_STATUS: 0x0000000000000004
IA32_MC5_STATUS(0x415): 0xbe00000000800400
IA32_MC5_ADDR(0x416):   0x00000001035bb629
IA32_MC5_MISC(0x417):   0x0000000000000000
Processor 15: IA32_MCG_STATUS: 0x0000000000000004
IA32_MC5_STATUS(0x415): 0xbe00000000800400
IA32_MC5_ADDR(0x416):   0x00000001035bb629
IA32_MC5_MISC(0x417):   0x0000000000000000
mp_kdp_enter() timed-out on cpu 12, NMI-ing
mp_kdp_enter() NMI pending on cpus: 0 1 2 3 4 5 6 7 8 9 10 11 13 14 15 16 17 18 19 20 21 22 23
mp_kdp_enter() timed-out during locked wait after NMI;expected 24 acks but received 1 after 17304138 loops in 1662499788 ticks
panic(cpu 12 caller 0xffffff8004edb5da): "Machine Check at 0xffffff7f883eb4f0, registers:\n" "CR0: 0x000000008001003b, CR2: 0x00000001044d91b8, CR3: 0x0000000009a9a000, CR4: 0x00000000000226e0\n" "RAX: 0x0000000000000020, RBX: 0xffffff809145c700, RCX: 0x0000000000000001, RDX: 0x0000000000000000\n" "RSP: 0xffffff872923bd50, RBP: 0xffffff872923bd80, RSI: 0x0000000000000006, RDI: 0xffffff8091a31d80\n" "R8:  0xffffff8091a7e700, R9:  0xffffff8099092c90, R10: 0xffffff800560dc38, R11: 0x0000000009a9a000\n" "R12: 0xffffff7f88407630, R13: 0xffffff809126e580, R14: 0x00000000000007b0, R15: 0x0000000000000006\n" "RFL: 0x0000000000000046, RIP: 0xffffff7f883eb4f0, CS:  0x0000000000000008, SS:  0x0000000000000010\n" "Error code: 0x0000000000000000\n"@/BuildRoot/Library/Caches/com.apple.xbs/Sources/xnu/xnu-4903.278.68/osfmk/i386/trap_native.c:168
Backtrace (CPU 12), Frame : Return Address
0xffffff8004b57330 : 0xffffff8004dad5cd
0xffffff8004b57380 : 0xffffff8004ee9245
0xffffff8004b573c0 : 0xffffff8004eda97a
0xffffff8004b57430 : 0xffffff8004d5a9d0
0xffffff8004b57450 : 0xffffff8004dacfe7
0xffffff8004b57570 : 0xffffff8004dace33
0xffffff8004b575e0 : 0xffffff8004edb5da
0xffffff8004b576d0 : 0xffffff8004d5b22f
0xffffff872923bd80 : 0xffffff7f883e3b89
0xffffff872923be60 : 0xffffff7f883e2dce
0xffffff872923bf10 : 0xffffff8004edc9ac
0xffffff872923bf30 : 0xffffff8004dcf207
0xffffff872923bf80 : 0xffffff8004dcf3f0
0xffffff872923bfa0 : 0xffffff8004d5a0ce
      Kernel Extensions in backtrace:
         com.apple.driver.AppleIntelCPUPowerManagement(220.0)[E7E2D5AB-C6D9-30E2-8CAA-2E526FD30CB8]@0xffffff7f883e1000->0xffffff7f88409fff

BSD process name corresponding to current thread: kernel_task

Mac OS version:
18G9216

Kernel version:
Darwin Kernel Version 18.7.0: Mon May  3 20:41:19 PDT 2021; root:xnu-4903.278.68~1/RELEASE_X86_64
Kernel UUID: 49D0FC60-2676-3913-8901-2E4C5603365D
Kernel slide:     0x0000000004a00000
Kernel text base: 0xffffff8004c00000
__HIB  text base: 0xffffff8004b00000
System model name: MacPro5,1 (Mac-F221BEC8)

System uptime in nanoseconds: 570474937322021
last loaded kext at 162702222806834: com.apple.driver.AppleUSBAudio    315.6 (addr 0xffffff7f8915e000, size 413696)
last unloaded kext at 162790026315789: com.apple.driver.usb.cdc    5.0.0 (addr 0xffffff7f89157000, size 28672)
loaded kexts:
com.apple.driver.AudioAUUC    1.70
com.apple.fileutil    20.036.15
com.apple.filesystems.autofs    3.0
com.apple.driver.AppleUpstreamUserClient    3.6.5
com.apple.driver.AppleMCCSControl    1.5.9
com.apple.kext.AMDFramebuffer    2.1.1
com.apple.driver.AGPM    110.25.11
com.apple.driver.AppleMikeyHIDDriver    131
com.apple.kext.AMDRadeonX4000    2.1.1
com.apple.driver.AppleHDA    282.54
com.apple.driver.AppleMikeyDriver    282.54
com.apple.driver.AppleGraphicsDevicePolicy    3.50.16
com.apple.AGDCPluginDisplayMetrics    3.50.16
com.apple.driver.AppleHV    1
com.apple.iokit.IOUserEthernet    1.0.1
com.apple.iokit.IOBluetoothSerialManager    6.0.14d12
com.apple.driver.pmtelemetry    1
com.apple.Dont_Steal_Mac_OS_X    7.0.0
com.apple.driver.AppleLPC    3.1
com.apple.kext.AMD7000Controller    2.1.1
com.apple.driver.AppleIntelSlowAdaptiveClocking    4.0.0
com.apple.driver.AppleOSXWatchdog    1
com.apple.driver.ACPI_SMC_PlatformPlugin    1.0.0
com.apple.driver.AppleVirtIO    2.1.3
com.apple.filesystems.hfs.kext    407.200.4
com.apple.AppleFSCompression.AppleFSCompressionTypeDataless    1.0.0d1
com.apple.BootCache    40
com.apple.AppleFSCompression.AppleFSCompressionTypeZlib    1.0.0
com.apple.AppleSystemPolicy    1.0
com.apple.filesystems.apfs    945.275.10
com.apple.driver.AppleFWOHCI    5.6.0
com.apple.driver.Intel82574LEthernet    2.7.2
com.apple.driver.AirPort.BrcmNIC    1400.1.1
com.apple.driver.AppleAHCIPort    329.260.5
com.apple.private.KextAudit    1.0
com.apple.driver.AppleHPET    1.8
com.apple.driver.AppleRTC    2.0
com.apple.driver.AppleACPIButtons    6.1
com.apple.driver.AppleSMBIOS    2.1
com.apple.driver.AppleACPIEC    6.1
com.apple.driver.AppleAPIC    1.7
com.apple.driver.AppleIntelCPUPowerManagementClient    220.0.0
com.apple.nke.applicationfirewall    202
com.apple.security.TMSafetyNet    8
com.apple.driver.AppleIntelCPUPowerManagement    220.0.0
com.apple.kext.triggers    1.0
com.apple.kext.AMDRadeonX4030HWLibs    1.0
com.apple.iokit.IOAcceleratorFamily2    404.15
com.apple.kext.AMDRadeonX4000HWServices    2.1.1
com.apple.driver.DspFuncLib    282.54
com.apple.kext.OSvKernDSPLib    528
com.apple.driver.AppleGraphicsControl    3.50.16
com.apple.iokit.IOAVBFamily    760.6
com.apple.plugin.IOgPTPPlugin    740.2
com.apple.iokit.IOEthernetAVBController    1.1.0
com.apple.iokit.IOSkywalkFamily    1
com.apple.driver.AppleSSE    1.0
com.apple.iokit.IOSurface    255.6.1
com.apple.iokit.IONDRVSupport    530.51
com.apple.driver.AppleSMBusController    1.0.18d1
com.apple.AppleGPUWrangler    3.50.16
com.apple.driver.AppleHDAController    282.54
com.apple.iokit.IOHDAFamily    282.54
com.apple.driver.AppleSMBusPCI    1.0.14d1
com.apple.kext.AMDSupport    2.1.1
com.apple.AppleGraphicsDeviceControl    3.50.16
com.apple.iokit.IOGraphicsFamily    530.68
com.apple.iokit.IOFireWireIP    2.3.0
com.apple.iokit.IOSlowAdaptiveClockingFamily    1.0.0
com.apple.driver.IOPlatformPluginLegacy    1.0.0
com.apple.driver.IOPlatformPluginFamily    6.0.0d8
com.apple.iokit.BroadcomBluetoothHostControllerUSBTransport    6.0.14d12
com.apple.iokit.IOBluetoothHostControllerUSBTransport    6.0.14d12
com.apple.iokit.IOBluetoothHostControllerTransport    6.0.14d12
com.apple.iokit.IOBluetoothFamily    6.0.14d12
com.apple.driver.usb.IOUSBHostHIDDevice    1.2
com.apple.iokit.IOAudioFamily    206.5
com.apple.vecLib.kext    1.2.0
com.apple.driver.usb.networking    5.0.0
com.apple.driver.usb.AppleUSBHostCompositeDevice    1.2
com.apple.driver.usb.AppleUSBHub    1.2
com.apple.iokit.IOSerialFamily    11
com.apple.filesystems.hfs.encodings.kext    1
com.apple.iokit.IOAHCIBlockStorage    301.270.1
com.apple.iokit.IOFireWireFamily    4.7.3
com.apple.iokit.IO80211Family    1200.12.2
com.apple.driver.mDNSOffloadUserClient    1.0.1b8
com.apple.driver.corecapture    1.0.4
com.apple.iokit.IOAHCIFamily    288
com.apple.driver.usb.AppleUSBEHCIPCI    1.2
com.apple.driver.usb.AppleUSBUHCIPCI    1.2
com.apple.driver.usb.AppleUSBUHCI    1.2
com.apple.driver.usb.AppleUSBEHCI    1.2
com.apple.driver.usb.AppleUSBHostPacketFilter    1.0
com.apple.iokit.IOUSBFamily    900.4.2
com.apple.driver.AppleUSBHostMergeProperties    1.2
com.apple.driver.AppleEFINVRAM    2.1
com.apple.driver.AppleEFIRuntime    2.1
com.apple.iokit.IOSMBusFamily    1.1
com.apple.iokit.IOHIDFamily    2.0.0
com.apple.security.quarantine    3
com.apple.security.sandbox    300.0
com.apple.kext.AppleMatch    1.0.0d1
com.apple.driver.DiskImages    493.0.0
com.apple.driver.AppleFDEKeyStore    28.30
com.apple.driver.AppleEffaceableStorage    1.0
com.apple.driver.AppleKeyStore    2
com.apple.driver.AppleUSBTDM    456.260.3
com.apple.driver.AppleMobileFileIntegrity    1.0.5
com.apple.iokit.IOUSBMassStorageDriver    145.200.2
com.apple.iokit.IOSCSIBlockCommandsDevice    408.250.3
com.apple.iokit.IOSCSIArchitectureModelFamily    408.250.3
com.apple.iokit.IOStorageFamily    2.1
com.apple.kext.CoreTrust    1
com.apple.driver.AppleCredentialManager    1.0
com.apple.driver.KernelRelayHost    1
com.apple.iokit.IOUSBHostFamily    1.2
com.apple.driver.usb.AppleUSBCommon    1.0
com.apple.driver.AppleBusPowerController    1.0
com.apple.driver.AppleSEPManager    1.0.1
com.apple.driver.IOSlaveProcessor    1
com.apple.iokit.IOReportFamily    47
com.apple.iokit.IOTimeSyncFamily    740.2
com.apple.iokit.IONetworkingFamily    3.4
com.apple.driver.AppleACPIPlatform    6.1
com.apple.driver.AppleSMC    3.1.9
com.apple.iokit.IOPCIFamily    2.9
com.apple.iokit.IOACPIFamily    1.4
com.apple.kec.pthread    1
com.apple.kec.Libm    1
com.apple.kec.corecrypto    1.0

EOF

Code:
Anonymous UUID:       8E0358CA-108C-D1D3-D673-EF9EB9B03E1C

Wed Aug 18 22:10:36 2021

*** Panic Report ***
Machine-check capabilities: 0x0000000000001c09
family: 6 model: 44 stepping: 2 microcode: 31
signature: 0x206c2
Intel(R) Xeon(R) CPU           X5680  @ 3.33GHz
9 error-reporting banks
Processor 0: IA32_MCG_STATUS: 0x0000000000000004
IA32_MC5_STATUS(0x415): 0xbe00000000800400
IA32_MC5_ADDR(0x416):   0x00000001111fd629
IA32_MC5_MISC(0x417):   0x0000000000000000
Processor 1: IA32_MCG_STATUS: 0x0000000000000004
IA32_MC5_STATUS(0x415): 0xbe00000000800400
IA32_MC5_ADDR(0x416):   0x00000001111fd629
IA32_MC5_MISC(0x417):   0x0000000000000000
mp_kdp_enter() timed-out on cpu 0, NMI-ing
mp_kdp_enter() NMI pending on cpus: 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
mp_kdp_enter() timed-out during locked wait after NMI;expected 24 acks but received 1 after 17301607 loops in 1662499788 ticks
panic(cpu 0 caller 0xffffff80006db5da): "Machine Check at 0x00000001111fd629, registers:\n" "CR0: 0x0000000080010033, CR2: 0x00007fa2817ffdae, CR3: 0x0000000ef418a117, CR4: 0x00000000000226e0\n" "RAX: 0x0000000000000002, RBX: 0x0000000000000008, RCX: 0x0000000000000008, RDX: 0x0000000000000780\n" "RSP: 0x0000700009725a98, RBP: 0x00007fd308edd8f8, RSI: 0x00007fd308edd8f8, RDI: 0x00007fd33a360020\n" "R8:  0x0000000000000003, R9:  0x0000000000000000, R10: 0x00007fd33c49c201, R11: 0x0000000000000b08\n" "R12: 0x00007fd3390c8000, R13: 0x0000000000000003, R14: 0x0000000000000000, R15: 0x00007fd33c49c2e0\n" "RFL: 0x0000000000010206, RIP: 0x00000001111fd629, CS:  0x000000000000002b, SS:  0x0000000000000023\n" "Error code: 0x0000000000000000\n"@/BuildRoot/Library/Caches/com.apple.xbs/Sources/xnu/xnu-4903.278.68/osfmk/i386/trap_native.c:168
Backtrace (CPU 0), Frame : Return Address
0xffffff873ae8bc00 : 0xffffff80005ad5cd
0xffffff873ae8bc50 : 0xffffff80006e9245
0xffffff873ae8bc90 : 0xffffff80006da97a
0xffffff873ae8bd00 : 0xffffff800055a9d0
0xffffff873ae8bd20 : 0xffffff80005acfe7
0xffffff873ae8be40 : 0xffffff80005ace33
0xffffff873ae8beb0 : 0xffffff80006db5da
0xffffff873ae8bfa0 : 0xffffff800055b22f

BSD process name corresponding to current thread: Plex Transcoder

Mac OS version:
18G9216

Kernel version:
Darwin Kernel Version 18.7.0: Mon May  3 20:41:19 PDT 2021; root:xnu-4903.278.68~1/RELEASE_X86_64
Kernel UUID: 49D0FC60-2676-3913-8901-2E4C5603365D
Kernel slide:     0x0000000000200000
Kernel text base: 0xffffff8000400000
__HIB  text base: 0xffffff8000300000
System model name: MacPro5,1 (Mac-F221BEC8)

System uptime in nanoseconds: 21956124780720
last loaded kext at 843714221763: com.apple.driver.AppleXsanScheme    3 (addr 0xffffff7f84957000, size 32768)
last unloaded kext at 923874723415: com.apple.driver.AppleXsanScheme    3 (addr 0xffffff7f84957000, size 32768)
loaded kexts:
com.apple.driver.AudioAUUC    1.70
com.apple.fileutil    20.036.15
com.apple.filesystems.autofs    3.0
com.apple.driver.AppleUpstreamUserClient    3.6.5
com.apple.driver.AppleMCCSControl    1.5.9
com.apple.kext.AMDFramebuffer    2.1.1
com.apple.driver.AGPM    110.25.11
com.apple.driver.AppleMikeyHIDDriver    131
com.apple.kext.AMDRadeonX4000    2.1.1
com.apple.driver.AppleHDA    282.54
com.apple.driver.AppleMikeyDriver    282.54
com.apple.driver.AppleGraphicsDevicePolicy    3.50.16
com.apple.AGDCPluginDisplayMetrics    3.50.16
com.apple.driver.AppleHV    1
com.apple.iokit.IOUserEthernet    1.0.1
com.apple.iokit.IOBluetoothSerialManager    6.0.14d12
com.apple.driver.pmtelemetry    1
com.apple.Dont_Steal_Mac_OS_X    7.0.0
com.apple.driver.AppleLPC    3.1
com.apple.kext.AMD7000Controller    2.1.1
com.apple.driver.AppleIntelSlowAdaptiveClocking    4.0.0
com.apple.driver.ACPI_SMC_PlatformPlugin    1.0.0
com.apple.driver.AppleOSXWatchdog    1
com.apple.driver.AppleVirtIO    2.1.3
com.apple.filesystems.hfs.kext    407.200.4
com.apple.AppleFSCompression.AppleFSCompressionTypeDataless    1.0.0d1
com.apple.BootCache    40
com.apple.AppleFSCompression.AppleFSCompressionTypeZlib    1.0.0
com.apple.AppleSystemPolicy    1.0
com.apple.filesystems.apfs    945.275.10
com.apple.driver.AppleFWOHCI    5.6.0
com.apple.driver.Intel82574LEthernet    2.7.2
com.apple.driver.AirPort.BrcmNIC    1400.1.1
com.apple.driver.AppleAHCIPort    329.260.5
com.apple.private.KextAudit    1.0
com.apple.driver.AppleRTC    2.0
com.apple.driver.AppleHPET    1.8
com.apple.driver.AppleACPIButtons    6.1
com.apple.driver.AppleSMBIOS    2.1
com.apple.driver.AppleACPIEC    6.1
com.apple.driver.AppleAPIC    1.7
com.apple.driver.AppleIntelCPUPowerManagementClient    220.0.0
com.apple.nke.applicationfirewall    202
com.apple.security.TMSafetyNet    8
com.apple.driver.AppleIntelCPUPowerManagement    220.0.0
com.apple.kext.triggers    1.0
com.apple.kext.AMDRadeonX4030HWLibs    1.0
com.apple.iokit.IOAcceleratorFamily2    404.15
com.apple.driver.DspFuncLib    282.54
com.apple.kext.OSvKernDSPLib    528
com.apple.kext.AMDRadeonX4000HWServices    2.1.1
com.apple.driver.AppleGraphicsControl    3.50.16
com.apple.iokit.IOAVBFamily    760.6
com.apple.plugin.IOgPTPPlugin    740.2
com.apple.iokit.IOEthernetAVBController    1.1.0
com.apple.iokit.IOSkywalkFamily    1
com.apple.driver.AppleSSE    1.0
com.apple.iokit.IOSurface    255.6.1
com.apple.iokit.IONDRVSupport    530.51
com.apple.driver.AppleSMBusController    1.0.18d1
com.apple.AppleGPUWrangler    3.50.16
com.apple.driver.AppleHDAController    282.54
com.apple.iokit.IOHDAFamily    282.54
com.apple.driver.AppleSMBusPCI    1.0.14d1
com.apple.kext.AMDSupport    2.1.1
com.apple.AppleGraphicsDeviceControl    3.50.16
com.apple.iokit.IOGraphicsFamily    530.68
com.apple.iokit.IOSlowAdaptiveClockingFamily    1.0.0
com.apple.iokit.IOFireWireIP    2.3.0
com.apple.driver.IOPlatformPluginLegacy    1.0.0
com.apple.driver.IOPlatformPluginFamily    6.0.0d8
com.apple.iokit.BroadcomBluetoothHostControllerUSBTransport    6.0.14d12
com.apple.iokit.IOBluetoothHostControllerUSBTransport    6.0.14d12
com.apple.iokit.IOBluetoothHostControllerTransport    6.0.14d12
com.apple.iokit.IOBluetoothFamily    6.0.14d12
com.apple.driver.usb.IOUSBHostHIDDevice    1.2
com.apple.iokit.IOAudioFamily    206.5
com.apple.vecLib.kext    1.2.0
com.apple.driver.usb.networking    5.0.0
com.apple.driver.usb.AppleUSBHostCompositeDevice    1.2
com.apple.driver.usb.AppleUSBHub    1.2
com.apple.iokit.IOSerialFamily    11
com.apple.filesystems.hfs.encodings.kext    1
com.apple.iokit.IOAHCIBlockStorage    301.270.1
com.apple.iokit.IOFireWireFamily    4.7.3
com.apple.iokit.IO80211Family    1200.12.2
com.apple.driver.mDNSOffloadUserClient    1.0.1b8
com.apple.driver.corecapture    1.0.4
com.apple.iokit.IOAHCIFamily    288
com.apple.driver.usb.AppleUSBEHCIPCI    1.2
com.apple.driver.usb.AppleUSBUHCIPCI    1.2
com.apple.driver.usb.AppleUSBUHCI    1.2
com.apple.driver.usb.AppleUSBEHCI    1.2
com.apple.driver.usb.AppleUSBHostPacketFilter    1.0
com.apple.iokit.IOUSBFamily    900.4.2
com.apple.driver.AppleEFINVRAM    2.1
com.apple.driver.AppleUSBHostMergeProperties    1.2
com.apple.driver.AppleEFIRuntime    2.1
com.apple.iokit.IOSMBusFamily    1.1
com.apple.iokit.IOHIDFamily    2.0.0
com.apple.security.quarantine    3
com.apple.security.sandbox    300.0
com.apple.kext.AppleMatch    1.0.0d1
com.apple.driver.DiskImages    493.0.0
com.apple.driver.AppleFDEKeyStore    28.30
com.apple.driver.AppleEffaceableStorage    1.0
com.apple.driver.AppleKeyStore    2
com.apple.driver.AppleUSBTDM    456.260.3
com.apple.driver.AppleMobileFileIntegrity    1.0.5
com.apple.iokit.IOUSBMassStorageDriver    145.200.2
com.apple.iokit.IOSCSIBlockCommandsDevice    408.250.3
com.apple.iokit.IOSCSIArchitectureModelFamily    408.250.3
com.apple.iokit.IOStorageFamily    2.1
com.apple.kext.CoreTrust    1
com.apple.driver.AppleCredentialManager    1.0
com.apple.driver.KernelRelayHost    1
com.apple.iokit.IOUSBHostFamily    1.2
com.apple.driver.usb.AppleUSBCommon    1.0
com.apple.driver.AppleBusPowerController    1.0
com.apple.driver.AppleSEPManager    1.0.1
com.apple.driver.IOSlaveProcessor    1
com.apple.iokit.IOReportFamily    47
com.apple.iokit.IOTimeSyncFamily    740.2
com.apple.iokit.IONetworkingFamily    3.4
com.apple.driver.AppleACPIPlatform    6.1
com.apple.driver.AppleSMC    3.1.9
com.apple.iokit.IOPCIFamily    2.9
com.apple.iokit.IOACPIFamily    1.4
com.apple.kec.pthread    1
com.apple.kec.Libm    1
com.apple.kec.corecrypto    1.0

EOF

Code:
Anonymous UUID:       8E0358CA-108C-D1D3-D673-EF9EB9B03E1C

Wed Aug 18 23:56:29 2021

*** Panic Report ***
Machine-check capabilities: 0x0000000000001c09
family: 6 model: 44 stepping: 2 microcode: 31
signature: 0x206c2
Intel(R) Xeon(R) CPU           X5680  @ 3.33GHz
9 error-reporting banks
Processor 20: IA32_MCG_STATUS: 0x0000000000000004
IA32_MC5_STATUS(0x415): 0xbe00000000800400
IA32_MC5_ADDR(0x416):   0x00000001064bd629
IA32_MC5_MISC(0x417):   0x0000000000000000
Processor 21: IA32_MCG_STATUS: 0x0000000000000004
IA32_MC5_STATUS(0x415): 0xbe00000000800400
IA32_MC5_ADDR(0x416):   0x00000001064bd629
IA32_MC5_MISC(0x417):   0x0000000000000000
mp_kdp_enter() timed-out on cpu 21, NMI-ing
mp_kdp_enter() NMI pending on cpus: 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 22 23
mp_kdp_enter() timed-out during locked wait after NMI;expected 24 acks but received 1 after 17304047 loops in 1662499788 ticks
panic(cpu 21 caller 0xffffff800f6db5da): "Machine Check at 0xffffff7f92beb4f0, registers:\n" "CR0: 0x000000008001003b, CR2: 0x000000c00162e000, CR3: 0x000000001429a000, CR4: 0x00000000000226e0\n" "RAX: 0x0000000000000001, RBX: 0xffffff809bf9e380, RCX: 0x0000000000000001, RDX: 0x0000000000000000\n" "RSP: 0xffffff874a073d50, RBP: 0xffffff874a073d80, RSI: 0x0000000000000006, RDI: 0xffffff809c573a40\n" "R8:  0xffffff809bf22700, R9:  0x0000000000000000, R10: 0x0000000000000000, R11: 0xffffff87134d6000\n" "R12: 0xffffff7f92c07630, R13: 0xffffff809bb11200, R14: 0x0000000000000148, R15: 0x0000000000000001\n" "RFL: 0x0000000000000046, RIP: 0xffffff7f92beb4f0, CS:  0x0000000000000008, SS:  0x0000000000000000\n" "Error code: 0x0000000000000000\n"@/BuildRoot/Library/Caches/com.apple.xbs/Sources/xnu/xnu-4903.278.68/osfmk/i386/trap_native.c:168
Backtrace (CPU 21), Frame : Return Address
0xffffff800f35bb30 : 0xffffff800f5ad5cd
0xffffff800f35bb80 : 0xffffff800f6e9245
0xffffff800f35bbc0 : 0xffffff800f6da97a
0xffffff800f35bc30 : 0xffffff800f55a9d0
0xffffff800f35bc50 : 0xffffff800f5acfe7
0xffffff800f35bd70 : 0xffffff800f5ace33
0xffffff800f35bde0 : 0xffffff800f6db5da
0xffffff800f35bed0 : 0xffffff800f55b22f
0xffffff874a073d80 : 0xffffff7f92be3b89
0xffffff874a073e60 : 0xffffff7f92be2dce
0xffffff874a073f10 : 0xffffff800f6dc9ac
0xffffff874a073f30 : 0xffffff800f5cf207
0xffffff874a073f80 : 0xffffff800f5cf3f0
0xffffff874a073fa0 : 0xffffff800f55a0ce
      Kernel Extensions in backtrace:
         com.apple.driver.AppleIntelCPUPowerManagement(220.0)[E7E2D5AB-C6D9-30E2-8CAA-2E526FD30CB8]@0xffffff7f92be1000->0xffffff7f92c09fff

BSD process name corresponding to current thread: kernel_task

Mac OS version:
18G9216

Kernel version:
Darwin Kernel Version 18.7.0: Mon May  3 20:41:19 PDT 2021; root:xnu-4903.278.68~1/RELEASE_X86_64
Kernel UUID: 49D0FC60-2676-3913-8901-2E4C5603365D
Kernel slide:     0x000000000f200000
Kernel text base: 0xffffff800f400000
__HIB  text base: 0xffffff800f300000
System model name: MacPro5,1 (Mac-F221BEC8)

System uptime in nanoseconds: 4021656199065
last loaded kext at 262511975430: com.apple.filesystems.msdosfs    1.10 (addr 0xffffff7f93957000, size 69632)
last unloaded kext at 323654909325: com.apple.driver.AppleUSBMergeNub    900.4.2 (addr 0xffffff7f91c63000, size 12288)
loaded kexts:
com.apple.driver.AudioAUUC    1.70
com.apple.fileutil    20.036.15
com.apple.filesystems.autofs    3.0
com.apple.driver.AppleUpstreamUserClient    3.6.5
com.apple.driver.AppleMCCSControl    1.5.9
com.apple.kext.AMDFramebuffer    2.1.1
com.apple.driver.AGPM    110.25.11
com.apple.driver.AppleMikeyHIDDriver    131
com.apple.driver.AppleHDA    282.54
com.apple.driver.AppleMikeyDriver    282.54
com.apple.kext.AMDRadeonX4000    2.1.1
com.apple.driver.AppleGraphicsDevicePolicy    3.50.16
com.apple.AGDCPluginDisplayMetrics    3.50.16
com.apple.driver.AppleHV    1
com.apple.iokit.IOUserEthernet    1.0.1
com.apple.iokit.IOBluetoothSerialManager    6.0.14d12
com.apple.driver.pmtelemetry    1
com.apple.Dont_Steal_Mac_OS_X    7.0.0
com.apple.driver.AppleLPC    3.1
com.apple.kext.AMD7000Controller    2.1.1
com.apple.driver.AppleOSXWatchdog    1
com.apple.driver.AppleIntelSlowAdaptiveClocking    4.0.0
com.apple.driver.ACPI_SMC_PlatformPlugin    1.0.0
com.apple.driver.AppleVirtIO    2.1.3
com.apple.filesystems.hfs.kext    407.200.4
com.apple.AppleFSCompression.AppleFSCompressionTypeDataless    1.0.0d1
com.apple.BootCache    40
com.apple.AppleFSCompression.AppleFSCompressionTypeZlib    1.0.0
com.apple.AppleSystemPolicy    1.0
com.apple.filesystems.apfs    945.275.10
com.apple.driver.AppleFWOHCI    5.6.0
com.apple.driver.Intel82574LEthernet    2.7.2
com.apple.driver.AirPort.BrcmNIC    1400.1.1
com.apple.driver.AppleAHCIPort    329.260.5
com.apple.private.KextAudit    1.0
com.apple.driver.AppleRTC    2.0
com.apple.driver.AppleHPET    1.8
com.apple.driver.AppleACPIButtons    6.1
com.apple.driver.AppleSMBIOS    2.1
com.apple.driver.AppleACPIEC    6.1
com.apple.driver.AppleAPIC    1.7
com.apple.driver.AppleIntelCPUPowerManagementClient    220.0.0
com.apple.nke.applicationfirewall    202
com.apple.security.TMSafetyNet    8
com.apple.driver.AppleIntelCPUPowerManagement    220.0.0
com.apple.kext.triggers    1.0
com.apple.kext.AMDRadeonX4030HWLibs    1.0
com.apple.driver.DspFuncLib    282.54
com.apple.kext.OSvKernDSPLib    528
com.apple.iokit.IOAcceleratorFamily2    404.15
com.apple.kext.AMDRadeonX4000HWServices    2.1.1
com.apple.driver.AppleGraphicsControl    3.50.16
com.apple.iokit.IOAVBFamily    760.6
com.apple.plugin.IOgPTPPlugin    740.2
com.apple.iokit.IOEthernetAVBController    1.1.0
com.apple.iokit.IOSkywalkFamily    1
com.apple.driver.AppleSSE    1.0
com.apple.iokit.IOSurface    255.6.1
com.apple.iokit.IONDRVSupport    530.51
com.apple.driver.AppleSMBusController    1.0.18d1
com.apple.AppleGPUWrangler    3.50.16
com.apple.driver.AppleHDAController    282.54
com.apple.iokit.IOHDAFamily    282.54
com.apple.driver.AppleSMBusPCI    1.0.14d1
com.apple.kext.AMDSupport    2.1.1
com.apple.AppleGraphicsDeviceControl    3.50.16
com.apple.iokit.IOGraphicsFamily    530.68
com.apple.iokit.IOSlowAdaptiveClockingFamily    1.0.0
com.apple.iokit.IOFireWireIP    2.3.0
com.apple.driver.IOPlatformPluginLegacy    1.0.0
com.apple.driver.IOPlatformPluginFamily    6.0.0d8
com.apple.iokit.BroadcomBluetoothHostControllerUSBTransport    6.0.14d12
com.apple.iokit.IOBluetoothHostControllerUSBTransport    6.0.14d12
com.apple.iokit.IOBluetoothHostControllerTransport    6.0.14d12
com.apple.iokit.IOBluetoothFamily    6.0.14d12
com.apple.driver.usb.IOUSBHostHIDDevice    1.2
com.apple.iokit.IOAudioFamily    206.5
com.apple.vecLib.kext    1.2.0
com.apple.driver.usb.networking    5.0.0
com.apple.driver.usb.AppleUSBHostCompositeDevice    1.2
com.apple.driver.usb.AppleUSBHub    1.2
com.apple.iokit.IOSerialFamily    11
com.apple.filesystems.hfs.encodings.kext    1
com.apple.iokit.IOAHCIBlockStorage    301.270.1
com.apple.iokit.IOFireWireFamily    4.7.3
com.apple.iokit.IO80211Family    1200.12.2
com.apple.driver.mDNSOffloadUserClient    1.0.1b8
com.apple.driver.corecapture    1.0.4
com.apple.iokit.IOAHCIFamily    288
com.apple.driver.usb.AppleUSBEHCIPCI    1.2
com.apple.driver.usb.AppleUSBUHCIPCI    1.2
com.apple.driver.usb.AppleUSBUHCI    1.2
com.apple.driver.usb.AppleUSBEHCI    1.2
com.apple.driver.usb.AppleUSBHostPacketFilter    1.0
com.apple.iokit.IOUSBFamily    900.4.2
com.apple.driver.AppleUSBHostMergeProperties    1.2
com.apple.driver.AppleEFINVRAM    2.1
com.apple.driver.AppleEFIRuntime    2.1
com.apple.iokit.IOSMBusFamily    1.1
com.apple.iokit.IOHIDFamily    2.0.0
com.apple.security.quarantine    3
com.apple.security.sandbox    300.0
com.apple.kext.AppleMatch    1.0.0d1
com.apple.driver.DiskImages    493.0.0
com.apple.driver.AppleFDEKeyStore    28.30
com.apple.driver.AppleEffaceableStorage    1.0
com.apple.driver.AppleKeyStore    2
com.apple.driver.AppleUSBTDM    456.260.3
com.apple.driver.AppleMobileFileIntegrity    1.0.5
com.apple.iokit.IOUSBMassStorageDriver    145.200.2
com.apple.iokit.IOSCSIBlockCommandsDevice    408.250.3
com.apple.iokit.IOSCSIArchitectureModelFamily    408.250.3
com.apple.iokit.IOStorageFamily    2.1
com.apple.kext.CoreTrust    1
com.apple.driver.AppleCredentialManager    1.0
com.apple.driver.KernelRelayHost    1
com.apple.iokit.IOUSBHostFamily    1.2
com.apple.driver.usb.AppleUSBCommon    1.0
com.apple.driver.AppleBusPowerController    1.0
com.apple.driver.AppleSEPManager    1.0.1
com.apple.driver.IOSlaveProcessor    1
com.apple.iokit.IOReportFamily    47
com.apple.iokit.IOTimeSyncFamily    740.2
com.apple.iokit.IONetworkingFamily    3.4
com.apple.driver.AppleACPIPlatform    6.1
com.apple.driver.AppleSMC    3.1.9
com.apple.iokit.IOPCIFamily    2.9
com.apple.iokit.IOACPIFamily    1.4
com.apple.kec.pthread    1
com.apple.kec.Libm    1
com.apple.kec.corecrypto    1.0

EOF

jscipione

jscipione

macrumors 6502
Mar 27, 2017
429
243
It is a common problem that the thermal paste dries up and/or the plastic clips disintegrate on the Northbridge chip especially on dual socket Mac Pros causing random kernel panics and freezes. You’ll need to remove the Northbridge heatsink, repaste it, and then the hard part is that you’ll need to find replacement clips. There are some plastic ones on Amazon you can buy or you can get creative with bolts and washers or zip ties.

PM me and I’ll send you some clips in the mail.

A

Aidzer0

macrumors newbie
Original poster
Jun 29, 2021
26
7
Good suggestion, I’ll try that as soon as the ASD finishes downloading.

Last night I repasted the CPU’s and reseated the ram, I looked at the NB heatsink, there doesn’t seem to be a way to get to the underside of the board to safely remove those clips without either breaking them or removing the board from the tray, correct?

Thanks!

jscipione

jscipione

macrumors 6502
Mar 27, 2017
429
243
Aidzer0 said:
Good suggestion, I’ll try that as soon as the ASD finishes downloading.

Last night I repasted the CPU’s and reseated the ram, I looked at the NB heatsink, there doesn’t seem to be a way to get to the underside of the board to safely remove those clips without either breaking them or removing the board from the tray, correct?

Thanks!
Click to expand...

You need to remove the board from the tray to get to the northbridge heatsink, which means you need to take the CPU heatsinks off again. There are screws around the outside edge of the board that you remove to take the board off the tray. I don't recommend breaking the clips off but you probably will anyway when you try to remove them since they are quite fragile.

A

Aidzer0

macrumors newbie
Original poster
Jun 29, 2021
26
7
jscipione said:
You need to remove the board from the tray to get to the northbridge heatsink, which means you need to take the CPU heatsinks off again. There are screws around the outside edge of the board that you remove to take the board off the tray. I don't recommend breaking the clips off but you probably will anyway when you try to remove them since they are quite fragile.
Click to expand...
Gotcha, thank you! I will report back once that is completed. Hopefully that will be the solution!

KeesMacPro

KeesMacPro

macrumors 65816
Nov 7, 2019
1,453
596
@Aidzer0 :
There's a very simple way to check if the rivets are broken or not.
If you installed some fan control app e.g. MacsFanControl or iStats menus , you can see all Temps.
If the difference between NB diode and NB heatsink is more than ~ 12 Celsius, a NB repaste and replacement of the rivets (if old) is necessary.

  • Like
Reactions: Aidzer0
A

Aidzer0

macrumors newbie
Original poster
Jun 29, 2021
26
7
KeesMacPro said:
@Aidzer0 :
There's a very simple way to check if the rivets are broken or not.
If you installed some fan control app e.g. MacsFanControl or iStats menus , you can see all Temps.
If the difference between NB diode and NB heatsink is more than ~ 12 Celsius, a NB repaste and replacement of the rivets (if old) is necessary.
Click to expand...
Screen Shot 2021-08-20 at 13.55.23.png

Seems like we have a repaste in order..

tsialex

tsialex

Contributor
Jun 13, 2016
13,454
13,601
Aidzer0 said:
I attached the .panic files but that got removed, here they are in plain text.
Code:
Anonymous UUID:       8E0358CA-108C-D1D3-D673-EF9EB9B03E1C

Wed Aug 18 01:32:23 2021

*** Panic Report ***
Machine-check capabilities: 0x0000000000001c09
family: 6 model: 44 stepping: 2 microcode: 31
signature: 0x206c2
Intel(R) Xeon(R) CPU           X5680  @ 3.33GHz
9 error-reporting banks
Processor 14: IA32_MCG_STATUS: 0x0000000000000004
IA32_MC5_STATUS(0x415): 0xbe00000000800400
IA32_MC5_ADDR(0x416):   0x00000001035bb629
IA32_MC5_MISC(0x417):   0x0000000000000000
Processor 15: IA32_MCG_STATUS: 0x0000000000000004
IA32_MC5_STATUS(0x415): 0xbe00000000800400
IA32_MC5_ADDR(0x416):   0x00000001035bb629
IA32_MC5_MISC(0x417):   0x0000000000000000
mp_kdp_enter() timed-out on cpu 12, NMI-ing
mp_kdp_enter() NMI pending on cpus: 0 1 2 3 4 5 6 7 8 9 10 11 13 14 15 16 17 18 19 20 21 22 23
mp_kdp_enter() timed-out during locked wait after NMI;expected 24 acks but received 1 after 17304138 loops in 1662499788 ticks
panic(cpu 12 caller 0xffffff8004edb5da): "Machine Check at 0xffffff7f883eb4f0, registers:\n" "CR0: 0x000000008001003b, CR2: 0x00000001044d91b8, CR3: 0x0000000009a9a000, CR4: 0x00000000000226e0\n" "RAX: 0x0000000000000020, RBX: 0xffffff809145c700, RCX: 0x0000000000000001, RDX: 0x0000000000000000\n" "RSP: 0xffffff872923bd50, RBP: 0xffffff872923bd80, RSI: 0x0000000000000006, RDI: 0xffffff8091a31d80\n" "R8:  0xffffff8091a7e700, R9:  0xffffff8099092c90, R10: 0xffffff800560dc38, R11: 0x0000000009a9a000\n" "R12: 0xffffff7f88407630, R13: 0xffffff809126e580, R14: 0x00000000000007b0, R15: 0x0000000000000006\n" "RFL: 0x0000000000000046, RIP: 0xffffff7f883eb4f0, CS:  0x0000000000000008, SS:  0x0000000000000010\n" "Error code: 0x0000000000000000\n"@/BuildRoot/Library/Caches/com.apple.xbs/Sources/xnu/xnu-4903.278.68/osfmk/i386/trap_native.c:168
Backtrace (CPU 12), Frame : Return Address
0xffffff8004b57330 : 0xffffff8004dad5cd
0xffffff8004b57380 : 0xffffff8004ee9245
0xffffff8004b573c0 : 0xffffff8004eda97a
0xffffff8004b57430 : 0xffffff8004d5a9d0
0xffffff8004b57450 : 0xffffff8004dacfe7
0xffffff8004b57570 : 0xffffff8004dace33
0xffffff8004b575e0 : 0xffffff8004edb5da
0xffffff8004b576d0 : 0xffffff8004d5b22f
0xffffff872923bd80 : 0xffffff7f883e3b89
0xffffff872923be60 : 0xffffff7f883e2dce
0xffffff872923bf10 : 0xffffff8004edc9ac
0xffffff872923bf30 : 0xffffff8004dcf207
0xffffff872923bf80 : 0xffffff8004dcf3f0
0xffffff872923bfa0 : 0xffffff8004d5a0ce
      Kernel Extensions in backtrace:
         com.apple.driver.AppleIntelCPUPowerManagement(220.0)[E7E2D5AB-C6D9-30E2-8CAA-2E526FD30CB8]@0xffffff7f883e1000->0xffffff7f88409fff

BSD process name corresponding to current thread: kernel_task

Mac OS version:
18G9216

Kernel version:
Darwin Kernel Version 18.7.0: Mon May  3 20:41:19 PDT 2021; root:xnu-4903.278.68~1/RELEASE_X86_64
Kernel UUID: 49D0FC60-2676-3913-8901-2E4C5603365D
Kernel slide:     0x0000000004a00000
Kernel text base: 0xffffff8004c00000
__HIB  text base: 0xffffff8004b00000
System model name: MacPro5,1 (Mac-F221BEC8)

System uptime in nanoseconds: 570474937322021
last loaded kext at 162702222806834: com.apple.driver.AppleUSBAudio    315.6 (addr 0xffffff7f8915e000, size 413696)
last unloaded kext at 162790026315789: com.apple.driver.usb.cdc    5.0.0 (addr 0xffffff7f89157000, size 28672)
loaded kexts:
com.apple.driver.AudioAUUC    1.70
com.apple.fileutil    20.036.15
com.apple.filesystems.autofs    3.0
com.apple.driver.AppleUpstreamUserClient    3.6.5
com.apple.driver.AppleMCCSControl    1.5.9
com.apple.kext.AMDFramebuffer    2.1.1
com.apple.driver.AGPM    110.25.11
com.apple.driver.AppleMikeyHIDDriver    131
com.apple.kext.AMDRadeonX4000    2.1.1
com.apple.driver.AppleHDA    282.54
com.apple.driver.AppleMikeyDriver    282.54
com.apple.driver.AppleGraphicsDevicePolicy    3.50.16
com.apple.AGDCPluginDisplayMetrics    3.50.16
com.apple.driver.AppleHV    1
com.apple.iokit.IOUserEthernet    1.0.1
com.apple.iokit.IOBluetoothSerialManager    6.0.14d12
com.apple.driver.pmtelemetry    1
com.apple.Dont_Steal_Mac_OS_X    7.0.0
com.apple.driver.AppleLPC    3.1
com.apple.kext.AMD7000Controller    2.1.1
com.apple.driver.AppleIntelSlowAdaptiveClocking    4.0.0
com.apple.driver.AppleOSXWatchdog    1
com.apple.driver.ACPI_SMC_PlatformPlugin    1.0.0
com.apple.driver.AppleVirtIO    2.1.3
com.apple.filesystems.hfs.kext    407.200.4
com.apple.AppleFSCompression.AppleFSCompressionTypeDataless    1.0.0d1
com.apple.BootCache    40
com.apple.AppleFSCompression.AppleFSCompressionTypeZlib    1.0.0
com.apple.AppleSystemPolicy    1.0
com.apple.filesystems.apfs    945.275.10
com.apple.driver.AppleFWOHCI    5.6.0
com.apple.driver.Intel82574LEthernet    2.7.2
com.apple.driver.AirPort.BrcmNIC    1400.1.1
com.apple.driver.AppleAHCIPort    329.260.5
com.apple.private.KextAudit    1.0
com.apple.driver.AppleHPET    1.8
com.apple.driver.AppleRTC    2.0
com.apple.driver.AppleACPIButtons    6.1
com.apple.driver.AppleSMBIOS    2.1
com.apple.driver.AppleACPIEC    6.1
com.apple.driver.AppleAPIC    1.7
com.apple.driver.AppleIntelCPUPowerManagementClient    220.0.0
com.apple.nke.applicationfirewall    202
com.apple.security.TMSafetyNet    8
com.apple.driver.AppleIntelCPUPowerManagement    220.0.0
com.apple.kext.triggers    1.0
com.apple.kext.AMDRadeonX4030HWLibs    1.0
com.apple.iokit.IOAcceleratorFamily2    404.15
com.apple.kext.AMDRadeonX4000HWServices    2.1.1
com.apple.driver.DspFuncLib    282.54
com.apple.kext.OSvKernDSPLib    528
com.apple.driver.AppleGraphicsControl    3.50.16
com.apple.iokit.IOAVBFamily    760.6
com.apple.plugin.IOgPTPPlugin    740.2
com.apple.iokit.IOEthernetAVBController    1.1.0
com.apple.iokit.IOSkywalkFamily    1
com.apple.driver.AppleSSE    1.0
com.apple.iokit.IOSurface    255.6.1
com.apple.iokit.IONDRVSupport    530.51
com.apple.driver.AppleSMBusController    1.0.18d1
com.apple.AppleGPUWrangler    3.50.16
com.apple.driver.AppleHDAController    282.54
com.apple.iokit.IOHDAFamily    282.54
com.apple.driver.AppleSMBusPCI    1.0.14d1
com.apple.kext.AMDSupport    2.1.1
com.apple.AppleGraphicsDeviceControl    3.50.16
com.apple.iokit.IOGraphicsFamily    530.68
com.apple.iokit.IOFireWireIP    2.3.0
com.apple.iokit.IOSlowAdaptiveClockingFamily    1.0.0
com.apple.driver.IOPlatformPluginLegacy    1.0.0
com.apple.driver.IOPlatformPluginFamily    6.0.0d8
com.apple.iokit.BroadcomBluetoothHostControllerUSBTransport    6.0.14d12
com.apple.iokit.IOBluetoothHostControllerUSBTransport    6.0.14d12
com.apple.iokit.IOBluetoothHostControllerTransport    6.0.14d12
com.apple.iokit.IOBluetoothFamily    6.0.14d12
com.apple.driver.usb.IOUSBHostHIDDevice    1.2
com.apple.iokit.IOAudioFamily    206.5
com.apple.vecLib.kext    1.2.0
com.apple.driver.usb.networking    5.0.0
com.apple.driver.usb.AppleUSBHostCompositeDevice    1.2
com.apple.driver.usb.AppleUSBHub    1.2
com.apple.iokit.IOSerialFamily    11
com.apple.filesystems.hfs.encodings.kext    1
com.apple.iokit.IOAHCIBlockStorage    301.270.1
com.apple.iokit.IOFireWireFamily    4.7.3
com.apple.iokit.IO80211Family    1200.12.2
com.apple.driver.mDNSOffloadUserClient    1.0.1b8
com.apple.driver.corecapture    1.0.4
com.apple.iokit.IOAHCIFamily    288
com.apple.driver.usb.AppleUSBEHCIPCI    1.2
com.apple.driver.usb.AppleUSBUHCIPCI    1.2
com.apple.driver.usb.AppleUSBUHCI    1.2
com.apple.driver.usb.AppleUSBEHCI    1.2
com.apple.driver.usb.AppleUSBHostPacketFilter    1.0
com.apple.iokit.IOUSBFamily    900.4.2
com.apple.driver.AppleUSBHostMergeProperties    1.2
com.apple.driver.AppleEFINVRAM    2.1
com.apple.driver.AppleEFIRuntime    2.1
com.apple.iokit.IOSMBusFamily    1.1
com.apple.iokit.IOHIDFamily    2.0.0
com.apple.security.quarantine    3
com.apple.security.sandbox    300.0
com.apple.kext.AppleMatch    1.0.0d1
com.apple.driver.DiskImages    493.0.0
com.apple.driver.AppleFDEKeyStore    28.30
com.apple.driver.AppleEffaceableStorage    1.0
com.apple.driver.AppleKeyStore    2
com.apple.driver.AppleUSBTDM    456.260.3
com.apple.driver.AppleMobileFileIntegrity    1.0.5
com.apple.iokit.IOUSBMassStorageDriver    145.200.2
com.apple.iokit.IOSCSIBlockCommandsDevice    408.250.3
com.apple.iokit.IOSCSIArchitectureModelFamily    408.250.3
com.apple.iokit.IOStorageFamily    2.1
com.apple.kext.CoreTrust    1
com.apple.driver.AppleCredentialManager    1.0
com.apple.driver.KernelRelayHost    1
com.apple.iokit.IOUSBHostFamily    1.2
com.apple.driver.usb.AppleUSBCommon    1.0
com.apple.driver.AppleBusPowerController    1.0
com.apple.driver.AppleSEPManager    1.0.1
com.apple.driver.IOSlaveProcessor    1
com.apple.iokit.IOReportFamily    47
com.apple.iokit.IOTimeSyncFamily    740.2
com.apple.iokit.IONetworkingFamily    3.4
com.apple.driver.AppleACPIPlatform    6.1
com.apple.driver.AppleSMC    3.1.9
com.apple.iokit.IOPCIFamily    2.9
com.apple.iokit.IOACPIFamily    1.4
com.apple.kec.pthread    1
com.apple.kec.Libm    1
com.apple.kec.corecrypto    1.0

EOF

Code:
Anonymous UUID:       8E0358CA-108C-D1D3-D673-EF9EB9B03E1C

Wed Aug 18 22:10:36 2021

*** Panic Report ***
Machine-check capabilities: 0x0000000000001c09
family: 6 model: 44 stepping: 2 microcode: 31
signature: 0x206c2
Intel(R) Xeon(R) CPU           X5680  @ 3.33GHz
9 error-reporting banks
Processor 0: IA32_MCG_STATUS: 0x0000000000000004
IA32_MC5_STATUS(0x415): 0xbe00000000800400
IA32_MC5_ADDR(0x416):   0x00000001111fd629
IA32_MC5_MISC(0x417):   0x0000000000000000
Processor 1: IA32_MCG_STATUS: 0x0000000000000004
IA32_MC5_STATUS(0x415): 0xbe00000000800400
IA32_MC5_ADDR(0x416):   0x00000001111fd629
IA32_MC5_MISC(0x417):   0x0000000000000000
mp_kdp_enter() timed-out on cpu 0, NMI-ing
mp_kdp_enter() NMI pending on cpus: 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
mp_kdp_enter() timed-out during locked wait after NMI;expected 24 acks but received 1 after 17301607 loops in 1662499788 ticks
panic(cpu 0 caller 0xffffff80006db5da): "Machine Check at 0x00000001111fd629, registers:\n" "CR0: 0x0000000080010033, CR2: 0x00007fa2817ffdae, CR3: 0x0000000ef418a117, CR4: 0x00000000000226e0\n" "RAX: 0x0000000000000002, RBX: 0x0000000000000008, RCX: 0x0000000000000008, RDX: 0x0000000000000780\n" "RSP: 0x0000700009725a98, RBP: 0x00007fd308edd8f8, RSI: 0x00007fd308edd8f8, RDI: 0x00007fd33a360020\n" "R8:  0x0000000000000003, R9:  0x0000000000000000, R10: 0x00007fd33c49c201, R11: 0x0000000000000b08\n" "R12: 0x00007fd3390c8000, R13: 0x0000000000000003, R14: 0x0000000000000000, R15: 0x00007fd33c49c2e0\n" "RFL: 0x0000000000010206, RIP: 0x00000001111fd629, CS:  0x000000000000002b, SS:  0x0000000000000023\n" "Error code: 0x0000000000000000\n"@/BuildRoot/Library/Caches/com.apple.xbs/Sources/xnu/xnu-4903.278.68/osfmk/i386/trap_native.c:168
Backtrace (CPU 0), Frame : Return Address
0xffffff873ae8bc00 : 0xffffff80005ad5cd
0xffffff873ae8bc50 : 0xffffff80006e9245
0xffffff873ae8bc90 : 0xffffff80006da97a
0xffffff873ae8bd00 : 0xffffff800055a9d0
0xffffff873ae8bd20 : 0xffffff80005acfe7
0xffffff873ae8be40 : 0xffffff80005ace33
0xffffff873ae8beb0 : 0xffffff80006db5da
0xffffff873ae8bfa0 : 0xffffff800055b22f

BSD process name corresponding to current thread: Plex Transcoder

Mac OS version:
18G9216

Kernel version:
Darwin Kernel Version 18.7.0: Mon May  3 20:41:19 PDT 2021; root:xnu-4903.278.68~1/RELEASE_X86_64
Kernel UUID: 49D0FC60-2676-3913-8901-2E4C5603365D
Kernel slide:     0x0000000000200000
Kernel text base: 0xffffff8000400000
__HIB  text base: 0xffffff8000300000
System model name: MacPro5,1 (Mac-F221BEC8)

System uptime in nanoseconds: 21956124780720
last loaded kext at 843714221763: com.apple.driver.AppleXsanScheme    3 (addr 0xffffff7f84957000, size 32768)
last unloaded kext at 923874723415: com.apple.driver.AppleXsanScheme    3 (addr 0xffffff7f84957000, size 32768)
loaded kexts:
com.apple.driver.AudioAUUC    1.70
com.apple.fileutil    20.036.15
com.apple.filesystems.autofs    3.0
com.apple.driver.AppleUpstreamUserClient    3.6.5
com.apple.driver.AppleMCCSControl    1.5.9
com.apple.kext.AMDFramebuffer    2.1.1
com.apple.driver.AGPM    110.25.11
com.apple.driver.AppleMikeyHIDDriver    131
com.apple.kext.AMDRadeonX4000    2.1.1
com.apple.driver.AppleHDA    282.54
com.apple.driver.AppleMikeyDriver    282.54
com.apple.driver.AppleGraphicsDevicePolicy    3.50.16
com.apple.AGDCPluginDisplayMetrics    3.50.16
com.apple.driver.AppleHV    1
com.apple.iokit.IOUserEthernet    1.0.1
com.apple.iokit.IOBluetoothSerialManager    6.0.14d12
com.apple.driver.pmtelemetry    1
com.apple.Dont_Steal_Mac_OS_X    7.0.0
com.apple.driver.AppleLPC    3.1
com.apple.kext.AMD7000Controller    2.1.1
com.apple.driver.AppleIntelSlowAdaptiveClocking    4.0.0
com.apple.driver.ACPI_SMC_PlatformPlugin    1.0.0
com.apple.driver.AppleOSXWatchdog    1
com.apple.driver.AppleVirtIO    2.1.3
com.apple.filesystems.hfs.kext    407.200.4
com.apple.AppleFSCompression.AppleFSCompressionTypeDataless    1.0.0d1
com.apple.BootCache    40
com.apple.AppleFSCompression.AppleFSCompressionTypeZlib    1.0.0
com.apple.AppleSystemPolicy    1.0
com.apple.filesystems.apfs    945.275.10
com.apple.driver.AppleFWOHCI    5.6.0
com.apple.driver.Intel82574LEthernet    2.7.2
com.apple.driver.AirPort.BrcmNIC    1400.1.1
com.apple.driver.AppleAHCIPort    329.260.5
com.apple.private.KextAudit    1.0
com.apple.driver.AppleRTC    2.0
com.apple.driver.AppleHPET    1.8
com.apple.driver.AppleACPIButtons    6.1
com.apple.driver.AppleSMBIOS    2.1
com.apple.driver.AppleACPIEC    6.1
com.apple.driver.AppleAPIC    1.7
com.apple.driver.AppleIntelCPUPowerManagementClient    220.0.0
com.apple.nke.applicationfirewall    202
com.apple.security.TMSafetyNet    8
com.apple.driver.AppleIntelCPUPowerManagement    220.0.0
com.apple.kext.triggers    1.0
com.apple.kext.AMDRadeonX4030HWLibs    1.0
com.apple.iokit.IOAcceleratorFamily2    404.15
com.apple.driver.DspFuncLib    282.54
com.apple.kext.OSvKernDSPLib    528
com.apple.kext.AMDRadeonX4000HWServices    2.1.1
com.apple.driver.AppleGraphicsControl    3.50.16
com.apple.iokit.IOAVBFamily    760.6
com.apple.plugin.IOgPTPPlugin    740.2
com.apple.iokit.IOEthernetAVBController    1.1.0
com.apple.iokit.IOSkywalkFamily    1
com.apple.driver.AppleSSE    1.0
com.apple.iokit.IOSurface    255.6.1
com.apple.iokit.IONDRVSupport    530.51
com.apple.driver.AppleSMBusController    1.0.18d1
com.apple.AppleGPUWrangler    3.50.16
com.apple.driver.AppleHDAController    282.54
com.apple.iokit.IOHDAFamily    282.54
com.apple.driver.AppleSMBusPCI    1.0.14d1
com.apple.kext.AMDSupport    2.1.1
com.apple.AppleGraphicsDeviceControl    3.50.16
com.apple.iokit.IOGraphicsFamily    530.68
com.apple.iokit.IOSlowAdaptiveClockingFamily    1.0.0
com.apple.iokit.IOFireWireIP    2.3.0
com.apple.driver.IOPlatformPluginLegacy    1.0.0
com.apple.driver.IOPlatformPluginFamily    6.0.0d8
com.apple.iokit.BroadcomBluetoothHostControllerUSBTransport    6.0.14d12
com.apple.iokit.IOBluetoothHostControllerUSBTransport    6.0.14d12
com.apple.iokit.IOBluetoothHostControllerTransport    6.0.14d12
com.apple.iokit.IOBluetoothFamily    6.0.14d12
com.apple.driver.usb.IOUSBHostHIDDevice    1.2
com.apple.iokit.IOAudioFamily    206.5
com.apple.vecLib.kext    1.2.0
com.apple.driver.usb.networking    5.0.0
com.apple.driver.usb.AppleUSBHostCompositeDevice    1.2
com.apple.driver.usb.AppleUSBHub    1.2
com.apple.iokit.IOSerialFamily    11
com.apple.filesystems.hfs.encodings.kext    1
com.apple.iokit.IOAHCIBlockStorage    301.270.1
com.apple.iokit.IOFireWireFamily    4.7.3
com.apple.iokit.IO80211Family    1200.12.2
com.apple.driver.mDNSOffloadUserClient    1.0.1b8
com.apple.driver.corecapture    1.0.4
com.apple.iokit.IOAHCIFamily    288
com.apple.driver.usb.AppleUSBEHCIPCI    1.2
com.apple.driver.usb.AppleUSBUHCIPCI    1.2
com.apple.driver.usb.AppleUSBUHCI    1.2
com.apple.driver.usb.AppleUSBEHCI    1.2
com.apple.driver.usb.AppleUSBHostPacketFilter    1.0
com.apple.iokit.IOUSBFamily    900.4.2
com.apple.driver.AppleEFINVRAM    2.1
com.apple.driver.AppleUSBHostMergeProperties    1.2
com.apple.driver.AppleEFIRuntime    2.1
com.apple.iokit.IOSMBusFamily    1.1
com.apple.iokit.IOHIDFamily    2.0.0
com.apple.security.quarantine    3
com.apple.security.sandbox    300.0
com.apple.kext.AppleMatch    1.0.0d1
com.apple.driver.DiskImages    493.0.0
com.apple.driver.AppleFDEKeyStore    28.30
com.apple.driver.AppleEffaceableStorage    1.0
com.apple.driver.AppleKeyStore    2
com.apple.driver.AppleUSBTDM    456.260.3
com.apple.driver.AppleMobileFileIntegrity    1.0.5
com.apple.iokit.IOUSBMassStorageDriver    145.200.2
com.apple.iokit.IOSCSIBlockCommandsDevice    408.250.3
com.apple.iokit.IOSCSIArchitectureModelFamily    408.250.3
com.apple.iokit.IOStorageFamily    2.1
com.apple.kext.CoreTrust    1
com.apple.driver.AppleCredentialManager    1.0
com.apple.driver.KernelRelayHost    1
com.apple.iokit.IOUSBHostFamily    1.2
com.apple.driver.usb.AppleUSBCommon    1.0
com.apple.driver.AppleBusPowerController    1.0
com.apple.driver.AppleSEPManager    1.0.1
com.apple.driver.IOSlaveProcessor    1
com.apple.iokit.IOReportFamily    47
com.apple.iokit.IOTimeSyncFamily    740.2
com.apple.iokit.IONetworkingFamily    3.4
com.apple.driver.AppleACPIPlatform    6.1
com.apple.driver.AppleSMC    3.1.9
com.apple.iokit.IOPCIFamily    2.9
com.apple.iokit.IOACPIFamily    1.4
com.apple.kec.pthread    1
com.apple.kec.Libm    1
com.apple.kec.corecrypto    1.0

EOF

Code:
Anonymous UUID:       8E0358CA-108C-D1D3-D673-EF9EB9B03E1C

Wed Aug 18 23:56:29 2021

*** Panic Report ***
Machine-check capabilities: 0x0000000000001c09
family: 6 model: 44 stepping: 2 microcode: 31
signature: 0x206c2
Intel(R) Xeon(R) CPU           X5680  @ 3.33GHz
9 error-reporting banks
Processor 20: IA32_MCG_STATUS: 0x0000000000000004
IA32_MC5_STATUS(0x415): 0xbe00000000800400
IA32_MC5_ADDR(0x416):   0x00000001064bd629
IA32_MC5_MISC(0x417):   0x0000000000000000
Processor 21: IA32_MCG_STATUS: 0x0000000000000004
IA32_MC5_STATUS(0x415): 0xbe00000000800400
IA32_MC5_ADDR(0x416):   0x00000001064bd629
IA32_MC5_MISC(0x417):   0x0000000000000000
mp_kdp_enter() timed-out on cpu 21, NMI-ing
mp_kdp_enter() NMI pending on cpus: 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 22 23
mp_kdp_enter() timed-out during locked wait after NMI;expected 24 acks but received 1 after 17304047 loops in 1662499788 ticks
panic(cpu 21 caller 0xffffff800f6db5da): "Machine Check at 0xffffff7f92beb4f0, registers:\n" "CR0: 0x000000008001003b, CR2: 0x000000c00162e000, CR3: 0x000000001429a000, CR4: 0x00000000000226e0\n" "RAX: 0x0000000000000001, RBX: 0xffffff809bf9e380, RCX: 0x0000000000000001, RDX: 0x0000000000000000\n" "RSP: 0xffffff874a073d50, RBP: 0xffffff874a073d80, RSI: 0x0000000000000006, RDI: 0xffffff809c573a40\n" "R8:  0xffffff809bf22700, R9:  0x0000000000000000, R10: 0x0000000000000000, R11: 0xffffff87134d6000\n" "R12: 0xffffff7f92c07630, R13: 0xffffff809bb11200, R14: 0x0000000000000148, R15: 0x0000000000000001\n" "RFL: 0x0000000000000046, RIP: 0xffffff7f92beb4f0, CS:  0x0000000000000008, SS:  0x0000000000000000\n" "Error code: 0x0000000000000000\n"@/BuildRoot/Library/Caches/com.apple.xbs/Sources/xnu/xnu-4903.278.68/osfmk/i386/trap_native.c:168
Backtrace (CPU 21), Frame : Return Address
0xffffff800f35bb30 : 0xffffff800f5ad5cd
0xffffff800f35bb80 : 0xffffff800f6e9245
0xffffff800f35bbc0 : 0xffffff800f6da97a
0xffffff800f35bc30 : 0xffffff800f55a9d0
0xffffff800f35bc50 : 0xffffff800f5acfe7
0xffffff800f35bd70 : 0xffffff800f5ace33
0xffffff800f35bde0 : 0xffffff800f6db5da
0xffffff800f35bed0 : 0xffffff800f55b22f
0xffffff874a073d80 : 0xffffff7f92be3b89
0xffffff874a073e60 : 0xffffff7f92be2dce
0xffffff874a073f10 : 0xffffff800f6dc9ac
0xffffff874a073f30 : 0xffffff800f5cf207
0xffffff874a073f80 : 0xffffff800f5cf3f0
0xffffff874a073fa0 : 0xffffff800f55a0ce
      Kernel Extensions in backtrace:
         com.apple.driver.AppleIntelCPUPowerManagement(220.0)[E7E2D5AB-C6D9-30E2-8CAA-2E526FD30CB8]@0xffffff7f92be1000->0xffffff7f92c09fff

BSD process name corresponding to current thread: kernel_task

Mac OS version:
18G9216

Kernel version:
Darwin Kernel Version 18.7.0: Mon May  3 20:41:19 PDT 2021; root:xnu-4903.278.68~1/RELEASE_X86_64
Kernel UUID: 49D0FC60-2676-3913-8901-2E4C5603365D
Kernel slide:     0x000000000f200000
Kernel text base: 0xffffff800f400000
__HIB  text base: 0xffffff800f300000
System model name: MacPro5,1 (Mac-F221BEC8)

System uptime in nanoseconds: 4021656199065
last loaded kext at 262511975430: com.apple.filesystems.msdosfs    1.10 (addr 0xffffff7f93957000, size 69632)
last unloaded kext at 323654909325: com.apple.driver.AppleUSBMergeNub    900.4.2 (addr 0xffffff7f91c63000, size 12288)
loaded kexts:
com.apple.driver.AudioAUUC    1.70
com.apple.fileutil    20.036.15
com.apple.filesystems.autofs    3.0
com.apple.driver.AppleUpstreamUserClient    3.6.5
com.apple.driver.AppleMCCSControl    1.5.9
com.apple.kext.AMDFramebuffer    2.1.1
com.apple.driver.AGPM    110.25.11
com.apple.driver.AppleMikeyHIDDriver    131
com.apple.driver.AppleHDA    282.54
com.apple.driver.AppleMikeyDriver    282.54
com.apple.kext.AMDRadeonX4000    2.1.1
com.apple.driver.AppleGraphicsDevicePolicy    3.50.16
com.apple.AGDCPluginDisplayMetrics    3.50.16
com.apple.driver.AppleHV    1
com.apple.iokit.IOUserEthernet    1.0.1
com.apple.iokit.IOBluetoothSerialManager    6.0.14d12
com.apple.driver.pmtelemetry    1
com.apple.Dont_Steal_Mac_OS_X    7.0.0
com.apple.driver.AppleLPC    3.1
com.apple.kext.AMD7000Controller    2.1.1
com.apple.driver.AppleOSXWatchdog    1
com.apple.driver.AppleIntelSlowAdaptiveClocking    4.0.0
com.apple.driver.ACPI_SMC_PlatformPlugin    1.0.0
com.apple.driver.AppleVirtIO    2.1.3
com.apple.filesystems.hfs.kext    407.200.4
com.apple.AppleFSCompression.AppleFSCompressionTypeDataless    1.0.0d1
com.apple.BootCache    40
com.apple.AppleFSCompression.AppleFSCompressionTypeZlib    1.0.0
com.apple.AppleSystemPolicy    1.0
com.apple.filesystems.apfs    945.275.10
com.apple.driver.AppleFWOHCI    5.6.0
com.apple.driver.Intel82574LEthernet    2.7.2
com.apple.driver.AirPort.BrcmNIC    1400.1.1
com.apple.driver.AppleAHCIPort    329.260.5
com.apple.private.KextAudit    1.0
com.apple.driver.AppleRTC    2.0
com.apple.driver.AppleHPET    1.8
com.apple.driver.AppleACPIButtons    6.1
com.apple.driver.AppleSMBIOS    2.1
com.apple.driver.AppleACPIEC    6.1
com.apple.driver.AppleAPIC    1.7
com.apple.driver.AppleIntelCPUPowerManagementClient    220.0.0
com.apple.nke.applicationfirewall    202
com.apple.security.TMSafetyNet    8
com.apple.driver.AppleIntelCPUPowerManagement    220.0.0
com.apple.kext.triggers    1.0
com.apple.kext.AMDRadeonX4030HWLibs    1.0
com.apple.driver.DspFuncLib    282.54
com.apple.kext.OSvKernDSPLib    528
com.apple.iokit.IOAcceleratorFamily2    404.15
com.apple.kext.AMDRadeonX4000HWServices    2.1.1
com.apple.driver.AppleGraphicsControl    3.50.16
com.apple.iokit.IOAVBFamily    760.6
com.apple.plugin.IOgPTPPlugin    740.2
com.apple.iokit.IOEthernetAVBController    1.1.0
com.apple.iokit.IOSkywalkFamily    1
com.apple.driver.AppleSSE    1.0
com.apple.iokit.IOSurface    255.6.1
com.apple.iokit.IONDRVSupport    530.51
com.apple.driver.AppleSMBusController    1.0.18d1
com.apple.AppleGPUWrangler    3.50.16
com.apple.driver.AppleHDAController    282.54
com.apple.iokit.IOHDAFamily    282.54
com.apple.driver.AppleSMBusPCI    1.0.14d1
com.apple.kext.AMDSupport    2.1.1
com.apple.AppleGraphicsDeviceControl    3.50.16
com.apple.iokit.IOGraphicsFamily    530.68
com.apple.iokit.IOSlowAdaptiveClockingFamily    1.0.0
com.apple.iokit.IOFireWireIP    2.3.0
com.apple.driver.IOPlatformPluginLegacy    1.0.0
com.apple.driver.IOPlatformPluginFamily    6.0.0d8
com.apple.iokit.BroadcomBluetoothHostControllerUSBTransport    6.0.14d12
com.apple.iokit.IOBluetoothHostControllerUSBTransport    6.0.14d12
com.apple.iokit.IOBluetoothHostControllerTransport    6.0.14d12
com.apple.iokit.IOBluetoothFamily    6.0.14d12
com.apple.driver.usb.IOUSBHostHIDDevice    1.2
com.apple.iokit.IOAudioFamily    206.5
com.apple.vecLib.kext    1.2.0
com.apple.driver.usb.networking    5.0.0
com.apple.driver.usb.AppleUSBHostCompositeDevice    1.2
com.apple.driver.usb.AppleUSBHub    1.2
com.apple.iokit.IOSerialFamily    11
com.apple.filesystems.hfs.encodings.kext    1
com.apple.iokit.IOAHCIBlockStorage    301.270.1
com.apple.iokit.IOFireWireFamily    4.7.3
com.apple.iokit.IO80211Family    1200.12.2
com.apple.driver.mDNSOffloadUserClient    1.0.1b8
com.apple.driver.corecapture    1.0.4
com.apple.iokit.IOAHCIFamily    288
com.apple.driver.usb.AppleUSBEHCIPCI    1.2
com.apple.driver.usb.AppleUSBUHCIPCI    1.2
com.apple.driver.usb.AppleUSBUHCI    1.2
com.apple.driver.usb.AppleUSBEHCI    1.2
com.apple.driver.usb.AppleUSBHostPacketFilter    1.0
com.apple.iokit.IOUSBFamily    900.4.2
com.apple.driver.AppleUSBHostMergeProperties    1.2
com.apple.driver.AppleEFINVRAM    2.1
com.apple.driver.AppleEFIRuntime    2.1
com.apple.iokit.IOSMBusFamily    1.1
com.apple.iokit.IOHIDFamily    2.0.0
com.apple.security.quarantine    3
com.apple.security.sandbox    300.0
com.apple.kext.AppleMatch    1.0.0d1
com.apple.driver.DiskImages    493.0.0
com.apple.driver.AppleFDEKeyStore    28.30
com.apple.driver.AppleEffaceableStorage    1.0
com.apple.driver.AppleKeyStore    2
com.apple.driver.AppleUSBTDM    456.260.3
com.apple.driver.AppleMobileFileIntegrity    1.0.5
com.apple.iokit.IOUSBMassStorageDriver    145.200.2
com.apple.iokit.IOSCSIBlockCommandsDevice    408.250.3
com.apple.iokit.IOSCSIArchitectureModelFamily    408.250.3
com.apple.iokit.IOStorageFamily    2.1
com.apple.kext.CoreTrust    1
com.apple.driver.AppleCredentialManager    1.0
com.apple.driver.KernelRelayHost    1
com.apple.iokit.IOUSBHostFamily    1.2
com.apple.driver.usb.AppleUSBCommon    1.0
com.apple.driver.AppleBusPowerController    1.0
com.apple.driver.AppleSEPManager    1.0.1
com.apple.driver.IOSlaveProcessor    1
com.apple.iokit.IOReportFamily    47
com.apple.iokit.IOTimeSyncFamily    740.2
com.apple.iokit.IONetworkingFamily    3.4
com.apple.driver.AppleACPIPlatform    6.1
com.apple.driver.AppleSMC    3.1.9
com.apple.iokit.IOPCIFamily    2.9
com.apple.iokit.IOACPIFamily    1.4
com.apple.kec.pthread    1
com.apple.kec.Libm    1
com.apple.kec.corecrypto    1.0

EOF
Click to expand...
NMI KPs are a classic symptom of northbridge overheating.

First check the push-pins and before repasting the northbridge check if the die is not concave or convex, very common when it overheats, also do the same for the heatsink.

A

Aidzer0

macrumors newbie
Original poster
Jun 29, 2021
26
7
tsialex said:
NMI KPs are a classic symptom of northbridge overheating.

First check the push-pins and before repasting the northbridge check if the die is not concave or convex, very common when it overheats, also do the same for the heatsink.
Click to expand...
Concave/vex die?? I really hope that didn't happen... Thanks for the info, will be checking all of this soon, I'll leave the Mac off for now.

I just ordered new push pins along with more thermal paste. So I will need to wait for that before checking this.

Thank you!

tsialex

tsialex

Contributor
Jun 13, 2016
13,454
13,601
Aidzer0 said:
Concave/vex die?? I really hope that didn't happen...
Click to expand...
The die and the heatsink itself will distort when overheated for a long time, specially when just one of the push-pin pair is broken.

A distorted heatsink can usually be lapped and it's an easy fix, while a distorted northbridge die will make the CPU tray useless since it's not cost effective to replace it and every time you heavily use the CPU the kernel panics happen.

CPU trays with delta bigger than 12ºC after correct maintenance is done are usually northbridge die distorted.

A

Aidzer0

macrumors newbie
Original poster
Jun 29, 2021
26
7
Okay, after hearing the die could be warped... I made a plan, I found an old MB that has those clips, I changed out the thermal paste (which was rock hard). Now these are the results:
Screen Shot 2021-08-20 at 14.51.38.png


Its not 12C. But it is really close to 12C difference...

Also, it seems as though I did not mount one of the CPU's correctly so one bank of RAM slots is not showing... The whole no cage on the socket is really heart wrenching...

Thanks again for all of the help!

tsialex

tsialex

Contributor
Jun 13, 2016
13,454
13,601
Aidzer0 said:
Okay, after hearing the die could be warped... I made a plan, I found an old MB that has those clips, I changed out the thermal paste (which was rock hard). Now these are the results:
View attachment 1821150

Its not 12C. But it is really close to 12C difference...

Also, it seems as though I did not mount one of the CPU's correctly so one bank of RAM slots is not showing... The whole no cage on the socket is really heart wrenching...

Thanks again for all of the help!
Click to expand...
10 to 12ºC are the expected delta for anyone in a hot climate. If it's over 12ºC, then you have stop and investigate what's wrong.

tsialex

tsialex

Contributor
Jun 13, 2016
13,454
13,601
Aidzer0 said:
Gotcha, thank you very much!
Click to expand...
After you do the northbridge maintenance, check if you have a healthy NVRAM volume. The KPs are saved inside the NVRAM stores and make a real mess that overtime can become a corrupt volume/brick.

forums.macrumors.com

OpenCore on the Mac Pro

Thank you @tsialex as always! Your knowledge overwhelms me! I have fixed my problem just reflashing BootROM using the reconstructed one that you made it for me. Now everything is ok again
forums.macrumors.com forums.macrumors.com

A

Aidzer0

macrumors newbie
Original poster
Jun 29, 2021
26
7
Fixed the issue with RAM, just reseated CPU B, absolutely traumatising having to torque that heat sink down...

tsialex said:
After you do the northbridge maintenance, check if you have a healthy NVRAM volume. The KPs are saved inside the NVRAM stores and make a real mess that overtime can become a corrupt volume/brick.

forums.macrumors.com

OpenCore on the Mac Pro

Thank you @tsialex as always! Your knowledge overwhelms me! I have fixed my problem just reflashing BootROM using the reconstructed one that you made it for me. Now everything is ok again
forums.macrumors.com forums.macrumors.com
Click to expand...
You do that every 3 months? Wow. Okay, time to mark some dates in my cal too.
Thanks for the heads up. I will be doing that asap.

Regarding opencore, since I have a AMD 7950 (planning to get a RX 580 when prices are normalized), should I use opencore now? Or just wait until I get a 580?
(I did have Martins opencore installed, but I removed it thinking that might have caused the kernel panics)

Thanks!

tsialex

tsialex

Contributor
Jun 13, 2016
13,454
13,601
Aidzer0 said:
Fixed the issue with RAM, just reseated CPU B, absolutely traumatising having to torque that heat sink down...


You do that every 3 months? Wow. Okay, time to mark some dates in my cal too.
Thanks for the heads up. I will be doing that asap.

Regarding opencore, since I have a AMD 7950 (planning to get a RX 580 when prices are normalized), should I use opencore now? Or just wait until I get a 580?
(I did have Martins opencore installed, but I removed it thinking that might have caused the kernel panics)

Thanks!
Click to expand...
What's your real intent with OpenCore?
  • If your intent is VideoToolBox hardware assisted video compression/decompression/conversion (what is commonly called AMD hardware acceleration) is only supported with Ellesmere/Polaris and newer AMD GPUs, your HD7950 is 4+ years older than the the first GPU ever supported. So, it's completely useless for your GPU.
  • If it's to run macOS releases after Mojave, keep it. If it's not and you are running Mojave, remove it.

A

Aidzer0

macrumors newbie
Original poster
Jun 29, 2021
26
7
tsialex said:
What's your real intent with OpenCore?
  • If your intent is VideoToolBox hardware assisted video compression/decompression/conversion (what is commonly called AMD hardware acceleration) is only supported with Ellesmere/Polaris and newer AMD GPUs, your HD7950 is 4+ years older than the the first GPU ever supported. So, it's completely useless for your GPU.
  • If it's to run macOS releases after Mojave, keep it. If it's not and you are running Mojave, remove it.
Click to expand...

Sounds good, I reckon I’ll keep Mojave for a little longer. Ironically opencore fixed a Bluetooth issue I was having where handoff wasn’t working, it’s still working after I removed opencore.

Any how’s. Thanks again for all of the guidance, I’ll report back with the results of the fix in a day or two.

A

Aidzer0

macrumors newbie
Original poster
Jun 29, 2021
26
7
tsialex said:
After you do the northbridge maintenance, check if you have a healthy NVRAM volume. The KPs are saved inside the NVRAM stores and make a real mess that overtime can become a corrupt volume/brick.

forums.macrumors.com

OpenCore on the Mac Pro

Thank you @tsialex as always! Your knowledge overwhelms me! I have fixed my problem just reflashing BootROM using the reconstructed one that you made it for me. Now everything is ok again
forums.macrumors.com forums.macrumors.com
Click to expand...
So... according to what you wrote in the thread you attached... I'm in big $h!%:

Screen Shot 2021-08-20 at 15.51.49.png



Well under the recommended 30k - 35k, in this circumstance, should I do the 5 chime NVRAM reset? I read that doesn't work that well...

tsialex

tsialex

Contributor
Jun 13, 2016
13,454
13,601
Aidzer0 said:
So... according to what you wrote in the thread you attached... I'm in big $h!%:

View attachment 1821171


Well under the recommended 30k - 35k, in this circumstance, should I do the 5 chime NVRAM reset? I read that doesn't work that well...
Click to expand...
I've sent you a PM with instructions, get everything done to the letter and I'll check your dump.

A

Aidzer0

macrumors newbie
Original poster
Jun 29, 2021
26
7
tsialex said:
Your Mac Pro is an early-2009 cross flashed to MP5,1 firmware.
Click to expand...
Gotcha, sorry, I am still getting used to the Mac jargon. I've been a windows person my whole life, only recently started troubleshooting/fixing and modding Mac. Whole different can of worms.

You must log in or register to reply here.
Register on MacRumors! This sidebar will go away, and you'll see fewer ads.
Top Bottom
