Is this a fifth card? The picture does not mean much.Its got 3x DisplayPort.
Is this a fifth card? The picture does not mean much.Its got 3x DisplayPort.
Is this a fifth card? The picture does not mean much.
Clean interior. I like that a lot. No doubt the mMP folks have seen this.Its got 3x DisplayPort.
Which will be the GOTO consumer cards for about a year.Meanwhile ATI fans are waiting for news of the new Vega.
At least for those who prefer low price for modest performance over modest price for good performance.Which will be the GOTO consumer cards for about a year.
Looking at the pictures, it does look like these are generic PCIe form factor cards, probably with NVlink bridges above the cards. Three Tesla GV100 (no video ports) and one Quadro GV100 (with video ports).Display could come from one of the GV100 cards just like it did for the PCIe version of GP100.
Winners:At least for those who prefer low price for modest performance over modest price for good performance.
Links? Especially since Vega hasn't been released.Winners:
GTX 1030 vs RX 550: possibly RX
GTX 1050 vs RX 560: possibly RX
GTX 1050 Ti vs RX 560 4GiB: ?
GTX 1060 3GiB vs RX 570: RX (not enough VRAM)
GTX 1060 6GiB vs RX 570: GTX
GTX 1070 vs RX 580: GTX
Vega:
GTX 1070 vs RX Vega 1: apparently Vega
GTX 1080 vs RX Vega 2: apparently Vega
GTX 1080 Ti vs RX Vega 3: apparently Vega
GTX Titan Xp vs RX Vega 3: probably GTX
FP64 ignored.
1030 vs 550:Links? Especially since Vega hasn't been released.
Winners:
GTX 1030 vs RX 550: possibly RX
GTX 1050 vs RX 560: possibly RX
GTX 1050 Ti vs RX 560 4GiB: ?
GTX 1060 3GiB vs RX 570: RX (not enough VRAM)
GTX 1060 6GiB vs RX 570: GTX
GTX 1070 vs RX 580: GTX
Vega:
GTX 1070 vs RX Vega 1: apparently Vega
GTX 1080 vs RX Vega 2: apparently Vega
GTX 1080 Ti vs RX Vega 3: apparently Vega
GTX Titan Xp vs RX Vega 3: probably GTX
FP64 ignored.
I would be more confident in:Yeah, at least wait until Vega is announced before making any claims on relative performance.
I fixed your post. I added Volta.I would be more confident in:
1070
Vega2
1080
Vega3
Ti
Volta
from the development benchmarks.
Next year for Vega?Next year?
You make it sound like a bad thing.Aiden it appears you do have not done any analysis of the architecture.
Nvidia focused on Deep Learning capabilities of Volta, for very good reason. FP32 performance will be the same as with GP100 chip, clock for clock, core for core.
But FP32 is the workload that is most important to Apple, right now. In FP32 maybe there is after all a point in AMD's marketing gimmick: "Poor Volta" .
This is just what you have read in my posts.You make it sound like a bad thing.
GV100 has almost 50% better FP32 than GP100. Significantly higher than the Vega leaks. Isn't that important for Apple?
And it's interesting that you're so dismissive of machine learning (while recognizing that Volta is a fantastic ML engine). If Apple wants to get into virtual reality (or self-driving cars), ML is an important part of that.
Adding Tensor cores to CUDA cores changes the game. Unless all you care about is making cat videos.
You make it sound like a bad thing.
GV100 has almost 50% better FP32 than GP100. Significantly higher than the Vega leaks. Isn't that important for Apple?
And it's interesting that you're so dismissive of machine learning (while recognizing that Volta is a fantastic ML engine). If Apple wants to get into virtual reality (or self-driving cars), ML is an important part of that.
Adding Tensor cores to CUDA cores changes the game. Unless all you care about is making cat videos.
50% more FP32 in the same power envelope - isn't that somewhat revolutionary?Yes, it has almost 50% higher FP32 performance. But it is achieved through massively increased die size of the GPU, also. We are talking about biggest GPU that has ever been made.
It is not that revolutionary. 12 nm FFN is delivering 25% increased performance in the same thermal envelope, however, if you will look closely at the characteristics of the GPU, we are talking about 300W TDP 5120 CUDA core chip that has 835 mm2 die size. If we will directly compare it to GP100, the efficiency size/size, clock/clock, core/core increased by 15%.50% more FP32 in the same power envelope - isn't that somewhat revolutionary?
What happened to the Koyoot who for a while framed everything as "performance per watt"?
That's about as believable as an interview with Kellyanne Conway.Believe me, I am not spinning this anyway.
Truly one of the more ludicrous comments lately.... Since you're trying to discredit Volta.It Average increase of performance around 45% over GP100 with 45% higher compute performance.
If I will say to you: "You are either blinded or stupid to not see what I am writing", will it be true?That's about as believable as an interview with Kellyanne Conway.
You are belittling Volta because its per core performance matches Pascal - while ignoring the fact that its FP32 performance and performance per watt is 50% better than the top Pascal.
All of your "Pascal is just Maxwell" and similar lines now that "Volta is just Pascal" are trying to spin Nvidia's advances as nothing. It's transparent that you're spinning this stuff.
Completely transparent spinning.
It's like a Trump press conference.
So you deliberately ignore the point which is made in that post, through that graph, and spin the situation to what you want it to be?Truly one of the more ludicrous comments lately.... Since you're trying to discredit Volta.
Is there a merit in my first question, from this post?
You can ignore everything what I write about Volta, but it will not change anything about the architecture. Core for core it is Pascal GP100 architecture, with heavily increased core count, die size, and incredibly advanced Deep Learning capabilities. But FP32 performance does not bring anything new. I want only to get the power consumption results, because I do not 100% believe Nvidia marketing numbers. The power consumption of 835mm2 GPU will be extremely high, regardless of everything(if for anyone 300W power consumption is actually high...).
Before we kick things off, one thing to make clear here - and this is something that I'll get into much greater detail when NVIDIA releases enough material for a proper deep dive - is that Volta is a brand new architecture for NVIDIA in almost every sense of the word. While the internal organization is the same much of the time, it's not Pascal at 12nm with new cores (Tensor Cores). Rather it's a significantly different architecture in terms of thread execution, thread scheduling, core layout, memory controllers, ISA, and more. And these are just the things NVIDIA is willing to talk about, never mind the ample secrets they still keep. So while I can only scratch the surface for today's reveal and will be focusing on basic throughput, Volta has a great deal going on under the hood to get to in the coming weeks.
But starting with the raw specficiations, the GV100 is something I can honestly say is a audacious GPU, an adjective I’ve never had a need to attach to any other GPU in the last 10 years. In terms of die size and transistor count, NVIDIA is genuinely building the biggest GPU they can get away with: 21.1 billion transistors, at a massive 815mm2, built on TSMC’s still green 12nm “FFN” process (the ‘n’ stands for NVIDIA; it’s a customized higher perf version of 12nm for NVIDIA).
