The first post of this thread is a WikiPost and can be edited by anyone with the appropiate permissions. Your edits will be public.
@theorist9 , but it's not the PPI at fault. Using the pixel doubled mode on my 185 ppi display, text is as sharp as my 220 ppi iMac. This is a unique problem of fractional scaling on OS X being bad on any display regardless of ppi.

Or in other words, no you do not need 220 ppi for sharp text, you need 220 ppi for sharp text + a normal sized UI.

A user with 4K@27 could do the same trick I do and get razor sharp text, at the cost of rather large UI elements.
That's not my finding. I use a 5k@27" (218 ppi) and a 4k@27" (163 ppi) side-by-side, both at the default 2:1 integer scaling.

To my eyes, the difference is clear. Comparing the same absolute text size, I find the 5k is noticeably sharper. And the same if I don't re-size the text on the 4k to make it the same size as on the 5k. It's more blurry (softer) either way.

Then again, I have very good close vision (I used to be able to read the microprinting on US currency, and while I've lost a bit with aging, it's still quite good), and have always been very sensitive to text sharpness.

As I keep emphasizing, we're all different, and you can't extrapolate your experience to someone else. Yes, there is a pixel density beyond which no human could discern the difference, but the limited studies I've seen indicate we're not close to that with large displays.

Plus your 4k is 24" (185 ppi) rather than the usual 27" (163 ppi), so the difference may not be as noticeable.

Last edited:
@motrek, I also have a 285 ppi portable monitor. Even on that extreme pixel density, when I switch from 2x scaling to fractional scaling I notice everything is slightly blurry.

@theorist9, does your 4K have the same brightness, the same contrast, and most importantly, is it glossy? A matte coating immediately downgrades the sharpness.

What makes the Apple glossy displays for me is the quality of the AR coating. It gives you the sharpness of a glossy display, and at the same time does pretty good job managing reflections. [Not as good as a matte screen, but I don't need it to be.] So a key question about this one is: How good is the AR?

And it seems it's not easy to do, since even the LG Ultrafine, which uses the same panel as that on the Retina iMac, didn't have as good an AR coating (too many reflections).

And of course you want the other aspects of the display, like screen illumination uniformity and color accuracy/uniformity to be there as well. [Color uniformity was reportedly also an issue with the LG.]

So given that it seems difficult to get this right, if I wanted to save $$$ I'd be inclined to buy a used ASD rather than a new Kucyon or Aliexpress display (esp. if I could buy it locally and get it with AC+).

To be clear, this is also made by Kuycon. If they have the ability to fully laminate a 27 inch lcd panel (far from trivial) they are probably able to make the AR coating decent too. I mean some of these Aliexpress items are literally from the same factory, using the same equipment.

I believe the 27 and 21.5 Ultrafines were very reflective, and the 24 a bit better.

A used ASD where I am is $1500. This is $800.
Yeah, that's my situation. It looks like the Kuycon can still be had from ClickClack for cheaper (they're ~$1,000 from Kuycon directly vs ~$800 from ClickClack) but the cheapest ASD I've seen locally is about $1500, and that's like, "slight cosmetic wear item on Craigslist" pricing. That's also 3x the price of my Mac Mini and since I'm not a graphic, photo, or video professional it's very hard to justify.

@theorist9, does your 4K have the same brightness, the same contrast, and most importantly, is it glossy? A matte coating immediately downgrades the sharpness.
That's a good point—I can match brightness but not contrast, and the 4k is matte, which does affect sharpness.

But it really is fundamentally about the pixel density rather than those other factors.

I know this because I also used the 4k under High Sierra and earlier. Those provided subpixel text rendering, which significantly increases the effective horizontal resolution (naively it's a 3-fold increase,but in practice it's of course much less than that). And with those OS's, I was pleased with the sharpness of my 4k.

Thus, for the same monitor (and thus the same brightness, contrast, and coating), I observed a noticeable difference in sharpness between "plain" 4k (163 ppi) and something that was effectively significantly higher.

Hence you'll simply need to accept that others are able to see differences even if you cannot. There's nothing wrong with that--we're all different!

As an aside, I'll add that there are degrees of matte, and the reason I like this particular Dell is that it has a very light matte coating (this one of the things I researched extensively before I bought it), and thus has less effect on sharpness than most matte coatings (and certainly much less than Apple's nanotexture, which is very strong).

Last edited:
@motrek, I also have a 285 ppi portable monitor. Even on that extreme pixel density, when I switch from 2x scaling to fractional scaling I notice everything is slightly blurry.
...
I sometimes switch between 1440p and 1692p logical resolution on my 4K monitor. The latter looks noticeably blurrier to me, but not because of fractional scaling. Because they're both doing fractional scaling. Presumably it's because the same stuff is being rendered at a lower physical resolution.

Yeah, that's my situation. It looks like the Kuycon can still be had from ClickClack for cheaper (they're ~$1,000 from Kuycon directly vs ~$800 from ClickClack) but the cheapest ASD I've seen locally is about $1500, and that's like, "slight cosmetic wear item on Craigslist" pricing. That's also 3x the price of my Mac Mini and since I'm not a graphic, photo, or video professional it's very hard to justify.
Be prepared for QC issues with the Kuycon. No one outside Kuycon or its vendors has statistics on the the actual frequency, but there does appear to be cause for concern.

There's also some debate whether ClickClack is selling the same quality of product as you get when you buy directly from Kuycon. I'd email Kuycon to ask.


  • Like
Reactions: obesechess
I purchased a Kuycon G27X from ClickClack back in July 2023 and am pretty satisfied—it's still my daily driver. No dead pixels or backlight issues with mine. I don't doubt that it's a lottery though and am glad that I got lucky.

That said, I will be purchasing the successor to the Studio Display for the following reasons in order of priority:
  • True Tone
  • Auto-Brightness
  • Speakers
  • Camera
Miss having those built-in from when I was on an iMac 5K.

  • Like
Reactions: obesechess
@theorist9, but you haven't compared text on 163 ppi glossy nor 185 ppi glossy to 220 ppi glossy with 2x scaling, so it's unknown if your eyes would find either of those less sharp.

@theorist9, but you haven't compared text on 163 ppi glossy nor 185 ppi glossy to 220 ppi glossy with 2x scaling, so it's unknown if your eyes would find either of those less sharp.
But I have compared text on 163 ppi matte to >163 ppi matte (">" b/c of subpixel text rendering) and found that effective increase in pixel density was sufficient to create a noticeable improvement in sharpness.

And if I can see that sharpness difference on a matte screen, I could certainly also see it on a glossy screen, since it's easier to detect differences without the interfering matte layer.

@theorist9, except for the fact that sharpness differences plateau at some point. You don't know what that threshold is for you until you try the intermediate points. Both of the cases you describe are further down the scale.

I actually returned a 285 ppi matte monitor as it was worse than any of my glossies except in the pitch dark.

@theorist9, except for the fact that sharpness differences plateau at some point. You don't know what that threshold is for you until you try the intermediate points. Both of the cases you describe are further down the scale.

I actually returned a 285 ppi matte monitor as it was worse than any of my glossies except in the pitch dark.
True, I don't know the threshold, but that's an entirely different question from what we were discussing, which was whether I can see a difference between 163 ppi and a 218 ppi (see screenshot below), and whether this is due to pixel density rather than coating.

I established I could see a difference between a 163 ppi matte and > 163 ppi matte (">" due to subpixel rendering). Since that difference would be less perceptible than the difference between a 163 ppi glossy and a 218 ppi glossy, it follows logically that I could percieve the latter as well.

So before we move onto a entirely different question, how about you first have the grace to acknowledge that I am indeed able to see what I assert I'm able to see? I think I've been very patient up to this point an addressing all your challenges to my own experience, but my patience does have its limits.

I.e., please don't move the goalposts mid-discussion. I can accept honest disagreement, but moving the goalposts ain't it.



Last edited:
Since that difference would be less perceptible than the difference between a 163 ppi glossy and a 218 ppi glossy, it follows logically that I could percieve the latter as well.
Except for the fact that sharpness differences plateau at some point, as I have already pointed out.

Also, I think ppi is not a great metric to discuss monitors, as it ignores the fact that we sit further away as the device gets larger. The central vision of the human eye is most comfortable at a 30 degree FOV. But of course you can turn your head whilst working. Too much turning, and you might as well be watching a tennis match.



Using this calculator, and my real viewing distance of 50cm from my 24" 4K I get 56 degrees FOV, and 69 PPD. Maintaining that FOV for a 27" screen, and using 35cm viewing distance for a laptop I get the following:
  • 13.3" MBP - 58 PPD
  • 21.5" 4K iMac - 73 PPD
  • 23.8" 4K - 69 PPD
  • 27" 4K - 68 PPD (don't own e.g. Dough Spectrum)
  • 27" 5K - 91 PPD (don't own but a colleague at work owns one e.g. ASD)
and for my glossy portable monitors
  • PM 1 - 74 PPD
  • PM 2 - 61 PPD
  • PM 3 - 53 PPD
Out of the above, the only monitor I could see pixels was the PM 3, and possibly the MBP/PM 2 if I pushed myself. For me 69,73,74, and 91 PPD are equally sharp. So my real visual acuity is between 58 - 69 PPD. Tallies nicely with the benchmark that human vision is "60 PPD".

Adding in matte monitors introduces a significant degradation in sharpness. I returned a 285 ppi monitor with a light matte finish as it was blurry in normal daylight conditions, which is higher than 163 ppi with subpixel antialiasing.

Of course, some people will have higher visual acuity, but very few will need 91 PPD. I don't see anyone complaining their Macbook Pros are pixelated.

Last edited:
I purchased a Kuycon G27X from ClickClack back in July 2023 and am pretty satisfied—it's still my daily driver. No dead pixels or backlight issues with mine. I don't doubt that it's a lottery though and am glad that I got lucky.

That said, I will be purchasing the successor to the Studio Display for the following reasons in order of priority:
  • True Tone
  • Auto-Brightness
  • Speakers
  • Camera
Miss having those built-in from when I was on an iMac 5K.
I have 2 that were purchased around the same time (April 2023) and am still happy with them as well. Considered moving to the PD2730s for the thunderbolt daisy chaining but their shipping keeps getting delayed so am going to wait and see what the next Studio Display brings as well

  • Like
Reactions: Stable Entropy
I've lost faith that apple will update the studio display this year.

I've gone ahead and ordered both the
ViewSonic VP2788-5K and Dell U2725QE. I'll report back my findings
I've received both and tested them.

Dell U2725QE
I went into this thinking I would like this more. Specs 'seem' better (higher refresh, better brightness and contrast). However, color was worse, 120Hz refresh is barely noticable in regular usage (I don't game), and the colors are worse.

More notes:

I thought the 120Hz would be more noticible. Very strangely it is not as noticble as snappy feeling as the MBP 16's promotion display. Very surprised that I didn't feel the higher refresh rate to be as significant. It could be because the viewsonic has a 75Hz display and thus, while you do see the difference, it is a marginal one.


The viewsonic is 75 Hz, and even though the difference between 5k and 4k is very marginal. The viewsonic display is brighter and has better colors out of the box.

Odly enough the Dell has higher peak brightness 600 cd/m2 and better contrast 3000:1, compared to 500 cd/m2 (I'm guessing this is not peak brightness) and 2000:1 on the viewsonic


One super super important point, the viewsonic has PHENOMEAL matte anti-glare screen. This cannot be overstated enough. I got the MBP with nano-texture and I love it. However the anti-glare coating on the viewsonic is so good. It makes using my monitor during the daylight and even at night with overhead ceiling lighting way more comfortable (better 'pratical' contrast and color). The dell is actually not bad, however the viewsonic is far, far superior.


Coming from a 32" black IPS 4k dell monitor. The updated dell IPS, is marginally better (sure 120Hz is better than 60Hz), but they haven't improved much else.

ALSO, I am liking 27" 4k/5k more than 32" 4k. Even though I scale them to have the same 'effective' UI elements, which makes the elements bigger on the 32". It's easier on the neck on the 27" monitor and I can actually get another 27" monitor for dual screen, where as dual 32" is too much desk and head moving.

The only annoyance on the viewsonic is the port layout of the thunderbolt display and the 'look' of the monitor compared to the ASD and the Dell (looks more sleek)

  • Like
Reactions: drrich2
Interesting to know the viewsonic has good antireflective coating. My main issue with matte is that contrast gets reduced in bright light making the display appear "washed out". But I guess if you start off with 2000:1 then it will still be acceptable in all conditions.

Worth pointing out that all these companies (Asus/BenQ/Viewsonic/Kuycon/Japannext) are using the same BOE panel, but with different backlights. That's why the brightness varies between models.

The Kuycon is the only other glossy 5K apart from the ASD. It has anti-fingerprint and anti-reflective coating. But I believe Apple apply the coating using plasma deposition so it is ultra-thin, whereas Kuycon use electroplating. In reality I don't think there's a huge difference, just that the ASD may more effectively cope with extreme reflections.

You can buy it from https://kuycon.us. You can also get it cheaper from clickclack.io or Aliexpress (https://www.aliexpress.com/item/1005008585092401.html)

Last edited:
  • Like
Reactions: colodane
Interesting to know the viewsonic has good antireflective coating. My main issue with matte is that contrast gets reduced in bright light making the display appear "washed out". But I guess if you start off with 2000:1 then it will still be acceptable in all conditions.

Worth pointing out that all these companies (Asus/BenQ/Viewsonic/Kuycon/Japannext) are using the same BOE panel, but with different backlights. That's why the brightness varies between models.

The Kuycon is the only other glossy 5K apart from the ASD. It has anti-fingerprint and anti-reflective coating. But I believe Apple apply the coating using plasma deposition so it is ultra-thin, whereas Kuycon use electroplating. In reality I don't think there's a huge difference, just that the ASD may more effectively cope with extreme reflections.

You can buy it from https://kuycon.us. You can also get it cheaper from clickclack.io or Aliexpress (https://www.aliexpress.com/item/1005008585092401.html)
The ALogic Clarity 5K is the other glossy 5K screen…

Interesting to know the viewsonic has good antireflective coating. My main issue with matte is that contrast gets reduced in bright light making the display appear "washed out". But I guess if you start off with 2000:1 then it will still be acceptable in all conditions.

Worth pointing out that all these companies (Asus/BenQ/Viewsonic/Kuycon/Japannext) are using the same BOE panel, but with different backlights. That's why the brightness varies between models.

The Kuycon is the only other glossy 5K apart from the ASD. It has anti-fingerprint and anti-reflective coating. But I believe Apple apply the coating using plasma deposition so it is ultra-thin, whereas Kuycon use electroplating. In reality I don't think there's a huge difference, just that the ASD may more effectively cope with extreme reflections.

You can buy it from https://kuycon.us. You can also get it cheaper from clickclack.io or Aliexpress (https://www.aliexpress.com/item/1005008585092401.html)
I'm not sure who is buying these, but the price is within 100-200$ compared to the ASD.....

I'm not sure who is buying these, but the price is within 100-200$ compared to the ASD.....
For reference:

That $999 Kuycon model is 4698RMB on Taobao, so like 645USD.

The ViewSonic also happens to be selling at similar price, at 4599RMB. But is has VG2781-5K as model number instead.

Also the Kuycon 5K monitors appear to be using a similar design and chipset to the video driver board (R1811) that is sold for the DIY 5K iMac conversions mentioned in the first entry in this thread.
That retails for $285/$325 or a bit less on AliExpress, corresponding to the $999/$1099 Kuycon models.
It is the port options that indicate the driver board design similarities.
Also the G27 firmware identity is very similar to the $285 board.

Where I live the ASD is $1950 new, $1600 secondhand, and the Kuycon is $950 (Aliexpress). I imagine the USA has a better market for the ASD with more units being sold.

My understanding is that the BOE panel itself is quite expensive, even the Japannext model where they cut every corner possible (cheap case, not very bright backlight) is $775.
