MP 1,1-5,1 testing TB3 AIC with MP 5,1

K

KevinClark

macrumors 6502
Feb 28, 2019
349
42
joevt said:
My script at https://gist.github.com/joevt/4f6d4d97b560efab9603ac509bf00122 will tell you the version numbers in a firmware file. I think I need to fix output for multi digit decimal versions though. Maybe later.

Code:
source /Volumes/Work/Programming/ThunderboltProjects/Scripts/ThunderboltUtil.sh

IFS=$'\n'
for thebin in $(find /Volumes/Work/Programming/ThunderboltProjects/Notes -type f -name '*.bin'); do
    loadfwfile "$thebin"
done 2>&1

listdroms

1)
thedrom=71000000000000ed00e0403498016900ed0008c0010108818002800000000882900180000000088380048001000008849003800100000585500000058650000002c70b88200100640000000000038980058a504000058b5040000b0147494741425954450011025a3339302044455349474e415245000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2062432/Gigabyte-Z390-Designare-TB3-ROM.bin:active:v33:nvm_v33.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/DESIGNARE-Z390-NVM33-Elias64Fr.bin:active:v33:nvm_v33.0:0x4200

2)
thedrom=6c0000000000100100d5cc6de801090001000d000100
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2062504/Mac-AA95B1DDAB278B95-C0_6.90.0-C1_47.1-R0.bin:active:v47:nvm_v47.1:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-1E7E29AD0135F9BC/Mac-1E7E29AD0135F9BC-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-226CB3C6A851A671/Mac-226CB3C6A851A671-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-53FDB3D8DB8CA971/Mac-53FDB3D8DB8CA971-B2_2.32.0.10-C1_51.1-R0.bin:active:v51:nvm_v51.1:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-63001698E7A34814/Mac-63001698E7A34814-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-827FAC58A8FDFA22/Mac-827FAC58A8FDFA22-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-827FB448E656EC26/Mac-827FB448E656EC26-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-937A206F2EE63C01/Mac-937A206F2EE63C01-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-AA95B1DDAB278B95/Mac-AA95B1DDAB278B95-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-E1008331FDC96864/Mac-E1008331FDC96864-B2_2.46.0.12-C1_55.3-R0.bin:active:v55:nvm_v55.3:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-E7203C0F68AA0004/Mac-E7203C0F68AA0004-B2_2.32.0.11-C1_51.2-R0.bin:active:v51:nvm_v51.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-1E7E29AD0135F9BC/Mac-1E7E29AD0135F9BC-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-226CB3C6A851A671/Mac-226CB3C6A851A671-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-53FDB3D8DB8CA971/Mac-53FDB3D8DB8CA971-B2_2.32.0.10-C1_51.1-R0.bin:active:v51:nvm_v51.1:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-63001698E7A34814/Mac-63001698E7A34814-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-827FAC58A8FDFA22/Mac-827FAC58A8FDFA22-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-827FB448E656EC26/Mac-827FB448E656EC26-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-937A206F2EE63C01/Mac-937A206F2EE63C01-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-A61BADE1FDAD7B05/Mac-A61BADE1FDAD7B05-B2_2.51.0.14-C1_56.1-R0.bin:active:v56:nvm_v56.1:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-AA95B1DDAB278B95/Mac-AA95B1DDAB278B95-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-E1008331FDC96864/Mac-E1008331FDC96864-B2_2.46.0.12-C1_55.3-R0.bin:active:v55:nvm_v55.3:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-E7203C0F68AA0004/Mac-E7203C0F68AA0004-B2_2.32.0.11-C1_51.2-R0.bin:active:v51:nvm_v51.2:0x4200

3)
thedrom=9a0000000000008680dc30485301650086803412010108818002800000000882900180000000088380048001000008849003800100000585500000058650000002c70b88200100640000000000038980058a500000058b50000009014153524f434b000f02583537302043726561746f72000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2065495/ASDRock-X570-Creator-MXIC-25L8006E-TB3.bin:active:v45:nvm_v45.0:0x4200

4)
thedrom=71000000000000ed00d9f6c7e2016900ed0007a2010108818002800000000882900180000000088380048001000008849003800100000585500000058650000002c70b88200100640000000000038980058a504000058b5040000b01474947414259544500110247432d544954414e205249444745000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2085204/TitanRidgeNVM23Original.bin:active:v23:nvm_v23.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2085293/TitanRidgeNVM43Patched.bin:inactive:v43:nvm_v43.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2085293/TitanRidgeNVM43Patched.bin:active:v43:nvm_v43.0:0x82200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/GC-TITAN-RIDGE-NVM23-Elias64Fr.bin:active:v23:nvm_v23.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/0-0GC-TITAN RIDGE#1.bin:linux:v23:nvm_v23.0:0x200
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/0-1GC-TITAN RIDGE#2.bin:linux:v23:nvm_v23.0:0x200

5)
thedrom=7500000000000049185fa466a90149004918040066020881800280000000088280028000000002830b842001003c0000000000058550000009014153526f636b0015025a3337302047616d696e672d4954582f6163000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2085799/ASRock_z390_itx_new.bin:active:v14:nvm_v14.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/ASROCK_Z390_ITX_NVM20_MOD-Elias64Fr.bin:inactive:v14:nvm_v14.0:0x4200

6)
thedrom=7500000000000049187420312b0151004918040066040881800280000000088280028000000002830b842001003c0000000000058550000009014153526f636b001d025a333930205068616e746f6d2047616d696e672d4954582f6163000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/ASROCK_Z390_ITX_NVM20_MOD-Elias64Fr.bin:active:v20:nvm_v20.0:0x82200

7)
thedrom=370000000000003100cbd78eae025d00310011110101088180028000000008829001800000000883800480010000088490038001000002c50b8620010064000000000003878002c802c9058a50000002cb0701415355530012025448554e444552424f4c5445582033000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/ASUS-THUNDERBOLT-EX-3/AlpineRidgeEX3-NVM18-NATA.bin:active:v18:nvm_v18.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/ASUS-THUNDERBOLT-EX-3/AlpineRidgeEX3-NVM18-NATA.bin:inactive:v18:nvm_v18.0:0x82200

8)
thedrom=37000000000000310099debb9b0156003100555501010881800280000000088290018000000002c302c402c50b8620010064000000000003878005885040000589500000058a50000002cb0701415355530011025448554e444552424f4c54455833000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/ASUS-THUNDERBOLT-EX-3/AlpineRidgeEX3-NVM26-NATA.bin:active:v26:nvm_v26.412:0x4200

9)
thedrom=370000000000003100340ee524015e00310041600121088180028000000008829001800000000883800480010000088490038001000002c50b8620010064000000000003878005885000000589500000058a500000058b500000070141535553000a0255583535304744000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/ASUS-UX550-NVM33-Elias64Fr.bin:active:v33:nvm_v33.2404:0x4200

10)
thedrom=71000000000000ed001e00a616016a00ed0019c00201088180028000000008829001800000000883800480010000088490038001000002c50b8620010064000000000003878005885040000589500000058a500000058b5040000b01474947414259544500120247432d414c50494e45205249444745000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/GC-ALPINE RIDGE-NVM20-V1-Elias64Fr.bin:active:v20:nvm_v20.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/GC-ALPINE-RIDGE-NVM20-V2-Elias64Fr.bin:active:v20:nvm_v20.0:0x4200

11)
thedrom=71000000000000ed001a032aba026700ed0019800201088180028000000008829001800000000883800480010000088490038001000002c50b86200100640000000000038780058850400002c9058a500000058b5040000b01474947414259544500120247432d414c50494e45205249444745000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/GC-ALPINE RIDGE-NVM21-V3-NATA.bin:inactive:v21:nvm_v21.0:0x4200

12)
thedrom=9a0000000000008680870a975e016400868073200121088180028000000008829001800000000883800480010000088490038001000002c50b8620010064000000000003878005885000000589500000058a500000058b5000000801496e74656c000f0248616465732043616e796f6e000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/GC-ALPINE RIDGE-NVM21-V3-NATA.bin:active:v33:nvm_v33.0:0x82200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/NUC8i7HNK/NUC8i7HNKpatched.bin:active:v41:nvm_v41.3:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/NUC8i7HNK/NUC8i7HNKpatched.bin:inactive:v33:nvm_v33.0:0x82200

13)
thedrom=71000000000000ed009a1ec570016800ed000dc0010208818002800000000882900180000000088380048001000008849003800100000585500000058650000002c70b88200100640000000000038980058a504000058b5040000b0147494741425954450010025a34393020564953494f4e2044000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/Gigabyte-Vision-D-NVM-50-Elias64Fr-CaseySJ.bin:active:v50:nvm_v50.0:0x4200

14)
thedrom=71000000000000ed0032d4d58d016c00ed0007c0010108818002800000000882900180000000088380048001000008849003800100000585500000058650000002c70b88200100640000000000038980058a504000058b5040000b0147494741425954450014025a3339302041524f555320585452454d45000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/Z390-AORUS-XTREME-NVM33-Elias64Fr.bin:active:v33:nvm_v33.0:0x4200

15)
thedrom=9500000000000041008c6b38dd015c0041000d030101088180028000000008829001800000000883800480010000088490038001000002c50b86200180dc0000000000038780058850000002c902ca058b5000000901414b6954694f000c024e6f6465204c697465000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Node Lite [B1-25 15W]/AKiTiO T3 NodeLite Update Tool_v1.0.0.5_C1-35+4.51(16.2)/00/FwUpdateTool.FwBin.AKiTiO_T3_NodeLite_rev35_Ti_v451_20180820_SEC1_sign.bin:active:v35:nvm_v35.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Node Lite [B1-25 15W]/AKiTiO T3 NodeLite Update Tool_v1.0.0.5_C1-35+4.51(16.3)/00/FwUpdateTool.FwBin.AKiTiO_T3_NodeLite_rev35_Ti_v451_20180820_SEC1_sign.bin:active:v35:nvm_v35.0:0x4200

16)
thedrom=9500000000000041008263c8b101620041000e030101088180028000000008829001800000000883800480010000088490038001000002c50b86200100a00000000000038780058850400002c902ca058b5040000901414b6954694f0012025468756e6465723320517561642058000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Node Lite [B1-25 15W]/AKiTiO T3 NodeLite Update Tool_v1.0.0.5_C1-35+4.51(16.2)/01/FwUpdateTool.FwBin.AKiTiO_T3_QuadX_C0_23_w_TI_v4p43_SEC1_sign.bin:active:v23:nvm_v23.4304:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Node Lite [B1-25 15W]/AKiTiO T3 NodeLite Update Tool_v1.0.0.5_C1-35+4.51(16.3)/01/FwUpdateTool.FwBin.AKiTiO_T3_QuadX_C0_23_w_TI_v4p43_SEC1_sign.bin:active:v23:nvm_v23.4304:0x4200

17)
thedrom=950000000000004100bdd46443026b00410001030101088180028000000008829001800000000883800480010000088490038001000002c50b86200100500000000000038780058850400002c902ca058b5040000a01696e5874726f6e001a02414b6954694f205468756e646572332044756f2050726f000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.0.5_B1-25+4.33/00/FwUpdateTool.FwBin.AKiTiO_T3_Node_rev23_TI83_20170103_SEC1_sign.bin:active:v18:nvm_v18.7601:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.04_B1-25+4.33/00/FwUpdateTool.FwBin.AKiTiO_T3_Node_rev23_TI83_20170103_SEC1_sign.bin:active:v18:nvm_v18.7601:0x4200

18)
thedrom=9500000000000041005c207c3d024c004100080301010881800280000000088290018000000002c302c402c50b86200100dc000000000002c702c802c902ca02cb0a01696e5874726f6e000e02414b6954694f204e6f6465000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.0.5_B1-25+4.33/01/FwUpdateTool.FwBin.AKiTiO_T3_Node_rev25_Ti4_33_20170406_SEC1_sign.bin:active:v21:nvm_v21.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.04_B1-25+4.33/01/FwUpdateTool.FwBin.AKiTiO_T3_Node_rev25_Ti4_33_20170406_SEC1_sign.bin:active:v21:nvm_v21.0:0x4200

19)
thedrom=950000000000004100de0a8918014d004100080301010881800280000000088290018000000002c302c402c50b86200100dc000000000003878002c802c902ca02cb0a01696e5874726f6e000e02414b6954694f204e6f6465000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.0.5_B1-25+4.33/02/FwUpdateTool.FwBin.AKiTiO_T3_Node_rev21_10262016_SEC1_sign.bin:active:v23:nvm_v23.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.0.5_B1-25+4.33/03/FwUpdateTool.FwBin.AKiTiO_T3_PCIeBox_rev19_TI176_SEC1_sign.bin:active:v25:nvm_v25.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.04_B1-25+4.33/02/FwUpdateTool.FwBin.AKiTiO_T3_Node_rev21_10262016_SEC1_sign.bin:active:v23:nvm_v23.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.04_B1-25+4.33/04/FwUpdateTool.FwBin.AKiTiO_T3_DP_rev18_Ti176_SEC1_sign.bin:active:v25:nvm_v25.0:0x4200

20)
thedrom=9500000000000041001147c933026c00410005030101088180028000000008829001800000000883800480010000088490038001000002c50b86200100400100000000038780058850400002c902ca058b5040000a01696e5874726f6e001b02414b6954694f205468756e64657233205043496520426f78000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.0.5_B1-25+4.33/04/FwUpdateTool.FwBin.AKiTiO_T3_DP_rev18_Ti176_SEC1_sign.bin:active:v19:nvm_v19.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.04_B1-25+4.33/03/FwUpdateTool.FwBin.AKiTiO_T3_PCIeBox_rev19_TI176_SEC1_sign.bin:active:v19:nvm_v19.0:0x4200

21)
thedrom=370000000000003100b4c9bba70154003100056001010881800280000000088290018000000002c302c402c50b86200100dc000000000003878002c802c902ca02cb0701415355530018024153555320524f472058472053746174696f6e2032000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/ASUS/ROG XG Station 2 [v25 100W]/ASUS-ROG-XG-STATION-2_V25/ASUS_ROG_XG_Station_2_AR_EP_4C_B1_rev25_W_TI_4_3_3_NO_MOD_SEC1_sign_0419.bin:active:v25:nvm_v25.4300:0x4200

22)
thedrom=3700000000000031007123b8480150003100076001010881800280000000088290018000000002c302c402c50b86200100dc000000000003878002c802c902ca02cb0a014153555354656b00110258472053544154494f4e2050524f000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/ASUS/XG Station Pro [29.1 15W]/TBT FW V1.6/ASUS_XGPro_AR_EP_4C_C1_rev29_W_Ti_rev4_45_SEC1_sign.bin:active:v29:nvm_v29.4504:0x4200

23)
thedrom=8f0000000000000400a0067618016d00040053a1010408818002800000000882900180000000088380048001000008849003800100000585090100058609010002c70b8820010064000000000003898002ca02cb02cc02cd1401426c61636b6d616769632044657369676e000b02654750552050726f000308080000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Blackmagic/Blackmagic eGPU Firmware Updater Folder/Blackmagic_eGPU_Firmware Folder/Library/ThunderboltAccessoryFirmwareUpdates/BlackmagicDesign/Blackmagic_eGPU_Pro_Thunderbolt.bin:active:v50:nvm_v50.0:0x4200

24)
thedrom=8f0000000000000400fbce3264016e000400ffa1010308818002800000000882900180000000088380048001000008849003800100000585090100058609010002c70b8820010064000000000003898002ca02cb02cc02cd1401426c61636b6d616769632044657369676e000f026547505520525835383000030000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Blackmagic/Blackmagic eGPU Firmware Updater Folder/Blackmagic_eGPU_Firmware Folder/Library/ThunderboltAccessoryFirmwareUpdates/BlackmagicDesign/Blackmagic_eGPU_Thunderbolt.bin:active:v50:nvm_v50.0:0x4200

25)
thedrom=71000000000000ed00cf231640014d00ed0009b0011b0881800280000000088290018000000002c302c402c50b86200100dc000000000003878002c802c902ca02cb0b014749474142595445000d0247414d494e4720424f58000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Gigabyte/1st gen Gaming Box [F1.0 H2D 100W]/[Thunderbolt firmware] Default version. Achieve great balance between USB bandwidth and graphics performance/Gigabyte_RX580IXEB_8GD_Ver1.0/Gigabyte_RX580IXEB_8GD_Ver1.0.bin:active:v27:nvm_v27.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Gigabyte/1st gen Gaming Box [F1.0 H2D 100W]/[Thunderbolt firmware] Improve Host to Device bandwidth/Gigabyte_RX580IXEB_8GD_Ver1.0 H2D/Gigabyte_RX580IXEB_8GD_Ver1.0 H2D.bin:active:v27:nvm_v27.0:0x4200

26)
thedrom=cf000000000000f000aa8ceaad014f00f000660a01190881800280000000088290018000000002c302c402c50b86200100dc000000000003878002c802c902ca02cb050148500015024741312d31302d416363656c657261746f72000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/HP/OMEN Accelerator [25.25 60W]/SP86866/TB3FW/HP_GA1_10_Accelerator_Shiva_AR_EP_A68_B1_rev25_W_TI83B_020_25_SEC1_sign.bin:active:v25:nvm_v25.2000:0x4200

27)
thedrom=740000000000000801367d82f901520008010417011a0881800280000000088290018000000002c302c402c50b8620010064000000000003878002c80589500000058a50000002cb09014c656e6f766f000e02373230732d3133494b4252000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Lenovo/TB3 Graphics Dock [v003 65W]/thunderbolt_firmware_201712/720SIKBRTBTFWUpdateV03/Debug/Lenovo_720s13_KBLR_AR_HR_2C_C0_rev26_Native_SEC1_sign.bin:active:v26:nvm_v26.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Lenovo/TB3 Graphics Dock [v003 65W]/thunderbolt_firmware_201712/Thunderbolt Firmware Update/Debug/Lenovo_720s13_KBLR_AR_HR_2C_C0_rev26_Native_SEC1_sign.bin:active:v26:nvm_v26.0:0x4200

28)
thedrom=a40000000000002e0178b736130160002e0158e314290881800280000000088290018000000002c302c402c50b86200100dc000000000003878002c802c902ca02cb1e01534150504849524520544543484e4f4c4f4759204c494d49544544000a0247656172426f78000307010000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Sapphire/Gearbox [41.41 60W]/SAPPHIRE_GearBox_H2D_v2/SAPPHIRE_GearBox_H2D.bin:active:v41:nvm_v41.5504:0x4200

29)
thedrom=8100000000000068015fd5786d01470068010550010102c102c20883800480010000088490038001000002c50b86200100dc000000000003878002c802c902ca02cb060154554c000c025442582d3535304341000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/Mantiz Venus [25.1 87W]/Mantiz-H2D87W.bin:active:v25:nvm_v25.3304:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/04/FwUpdateTool.FwBin.TUL_TBX_550CA_AR_EP_A68_B1_rev25_W_TI83_4p33_SEC1_sign_NO_MOD_20170710_sign.bin:active:v25:nvm_v25.3304:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/05/FwUpdateTool.FwBin.TUL_DEVIL_BOX_V10_AR_EP_A68_B1_rev25_TI_361_20171003_101_SEC1_sign.bin:active:v25:nvm_v25.3304:0x4200

30)
thedrom=810000000000006801a020894101470068016923010202c102c20883800480010000088490038001000002c50b86200100dc000000000003878002c802c902ca02cb060154554c000c02444556494c20424f58000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/00/FwUpdateTool.FwBin.TUL_DSL6540B_V02_A68_C0_V15_tps65983_Intel_Apex_Creek_CH_2_12_P45W_20170103_001.bin:active:v23:nvm_v23.6103:0x4200

31)
thedrom=810000000000006801a65fcc69014c006801035001010881800280000000088290018000000002c302c402c50b86200100640000000000038780058850400002c902ca058b504000060154554c000b0244534c3635343042000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/01/FwUpdateTool.FwBin.TUL_DSL6540B_V02_A68_C0_V14_tps65983_Intel_Apex_Creek_CH_2_12_PD45W_20161213_001.bin:active:v14:nvm_v14.6103:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/02/FwUpdateTool.FwBin.TUL_DSL6540_V10_A68_B1_V23_tps65983_Intel_Apex_Creek_2_10_PD60W_20170125_101.bin:active:v15:nvm_v15.6103:0x4200

32)
thedrom=8100000000000068019eb04ec901470068016923010102c102c20883800480010000088490038001000002c50b86200100dc000000000003878002c802c902ca02cb060154554c000c02444556494c20424f58000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/03/FwUpdateTool.FwBin.TUL_TBX_550CA_AR_EP_A68_B1_rev25_W_TI83_4p33_SEC1_sign_20170605.bin:active:v23:nvm_v23.6103:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/06/FwUpdateTool.FwBin.TUL_DEVIL_BOX_V10_AR_EP_A68_B1_rev23_TI_361_SEC1_relaxing_eGFX_sign.bin:active:v25:nvm_v25.6103:0x4200

33)
thedrom=73000000000000080041b846f401760008003700010102c102c20883800480010000088490038001000002c50b86200100dc000000000003878002c802c902ca058b5000001c01536f6e6e657420546563686e6f6c6f676965732c20496e632e002202427265616b6177617920426f7820446576656c6f7065722045646974696f6e000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/Sonnet Breakaway Box [25.1 DE 60W]/Sonnet_Breakaway_Box_Developer_Edition_AR_EP_A68_B1_rev25_W_TI83_3p61_SEC1_sign.bin:active:v25:nvm_v25.6103:0x4200

34)
thedrom=71000000000000ed00c4311795025400ed000b8002010881800280000000088290018000000002c302c402c50b8620010064000000000003878002c802c9058a50000002cb0b01474947414259544500110247412d5a3137302d47414d494e47000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuGigaMac/0-0 GIGABYTE GA-Z170-GAMING.bin:linux:v21:nvm_v21.0:0x200

35)
thedrom=550000000000005a00bbc044b90162005a0016de0101088180028000000008829001800000000883800480010000088490038001000002c50b86200100dc0000000000038780058850400002c902ca058b50400006014f57430015025468756e646572626f6c74203320446f636b000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuGigaMac/0-1_OWC Thunderbolt 3 Dock.bin:linux:v20:nvm_v20.9342:0x200

36)
thedrom=cf000000000000f000bee33fc7016d00f00067040102088180028000000008829001800000000883800480010000088490038001000002c502c602c70b88200100640000000000038980058a504000058b5040000a01485020496e632e0019024850205468756e646572626f6c7420446f636b204732000308080000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuGigaMac/0-301_HP Thunderbolt Dock G2.bin:linux:v19:nvm_v19.ec03:0x200

37)
thedrom=550000000000005a00eed74ba8016c005a0013de0101088180028000000008829001800000000883800480010000088490038001000002c50b86200100dc0000000000038780058850400002c902ca058b50400018014f7468657220576f726c6420436f6d707574696e67000d0248656c696f7320544233000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacBookPro/0-101_active1 OWC Heliios 3.bin:linux:v25:nvm_v25.6103:0x200

38)
thedrom=7300000000000008000a99c267017a00080043000101088180028000000008829001800000000883800480010000088490038001000002c50b86200100dc0000000000038780058850000002c902ca058b5000001c01536f6e6e657420546563686e6f6c6f676965732c20496e632e0017024563686f20457870726573732053454c20544233000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacBookPro/0-1_active0 Sonnet Echo Express SEL.bin:linux:v34:nvm_v34.100:0x200

39)
thedrom=730000000000000800bf0d0e6e027b00080024000101088180028000000008829001800000000883800480010000088490038001000002c50b86200100dc0000000000038780058850000002c902ca058b5000001c01536f6e6e657420546563686e6f6c6f676965732c20496e632e0018024563686f20457870726573732053452d4920544233000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacBookPro/30101_active2 Sonnet Echo Express SE-I.bin:linux:v21:nvm_v21.6103:0x200

40)
thedrom=6c00000000001001006d66283501090001000c000100
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacMini/active_Trebleet.bin:linux:v47:nvm_v47.4:0x200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-473D31EABEB93F9B/Mac-473D31EABEB93F9B-B0_13.38.0-C0_41.2-R0.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-4B682C642B45593E/Mac-4B682C642B45593E-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-551B86E5744E2388/Mac-551B86E5744E2388-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-66E35819EE2D0D05/Mac-66E35819EE2D0D05-B0_13.38.0-C0_41.2-R0.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-77F17D7DA9285301/Mac-77F17D7DA9285301-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-7BA5B2D9E42DDD94/Mac-7BA5B2D9E42DDD94-C0_16.0.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-7BA5B2DFE22DDD8C/Mac-7BA5B2DFE22DDD8C-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-A5C67F76ED83108C/Mac-A5C67F76ED83108C-B0_13.38.0-C0_41.2-R0.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-B4831CEBD52A0C4C/Mac-B4831CEBD52A0C4C-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-BE088AF8C5EB4FA2/Mac-BE088AF8C5EB4FA2-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-CAD6701F7CEA0921/Mac-CAD6701F7CEA0921-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-473D31EABEB93F9B/Mac-473D31EABEB93F9B-B0_13.38.0-C0_41.2-R0.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-4B682C642B45593E/Mac-4B682C642B45593E-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-551B86E5744E2388/Mac-551B86E5744E2388-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-66E35819EE2D0D05/Mac-66E35819EE2D0D05-B0_13.38.0-C0_41.2-R0.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-77F17D7DA9285301/Mac-77F17D7DA9285301-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-7BA5B2D9E42DDD94/Mac-7BA5B2D9E42DDD94-C0_16.0.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-7BA5B2DFE22DDD8C/Mac-7BA5B2DFE22DDD8C-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-A5C67F76ED83108C/Mac-A5C67F76ED83108C-B0_13.38.0-C0_41.2-R0.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-B4831CEBD52A0C4C/Mac-B4831CEBD52A0C4C-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-BE088AF8C5EB4FA2/Mac-BE088AF8C5EB4FA2-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-CAD6701F7CEA0921/Mac-CAD6701F7CEA0921-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200

41)
thedrom=ed0000000000006f00a0536d500256006f0001020101088180028000000008829001800000000883800480010000088490038001000002c502c602c7058850400002c902ca058b5040000f0153746172746563682e636f6d000a0254423332445032000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/0-1TB32DP2.bin:linux:v18:nvm_v18.0:0x200

42)
thedrom=ed0000000000006f0081850c9d0256006f0000020101088180028000000008829001800000000883800480010000088490038001000002c502c602c7058850400002c902ca058b5040000f0153746172746563682e636f6d000a0254423332484432000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/0-1TB32HD2.bin:linux:v18:nvm_v18.0:0x200

43)
thedrom=7a000000000000bd01be9c3676016500bd01210a01010881800280000000088290018000000002c302c402c502c602c70b88200100640000000000038980058a504000058b5040001e0157696e737461727320546563686e6f676f6c79204c696d69746564000902555441323144000308080000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/1-1 Winstar UTA21D.bin:linux:v36:nvm_v36.4306:0x200

44)
thedrom=7300000000000008009f25f48f017a00080031000101088180028000000008829001800000000883800480010000088490038001000002c50b86200100dc0000000000038780058850000002c902ca058b5000001c01536f6e6e657420546563686e6f6c6f676965732c20496e632e0017024563686f20457870726573732049494920544233000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/1-103Sonnet Echo Express III D.bin:linux:v25:nvm_v25.100:0x200

45)
thedrom=ad100000000000868064963b59006b00410001030101088180028000000008829001800000000883800480010000088490038001000002c50b86600100500000000000038780058850000002c902ca058b5000000a01696e5874726f6e001a02414b6954694f205468756e646572332044756f2050726f000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/1-3AKiTiO_Thunder3 Duo Pro.bin:linux:v16:nvm_v1.0:0x200

46)
thedrom=7f0100000000100100d5cc6de801090001000d000100
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-1E7E29AD0135F9BC/Mac-1E7E29AD0135F9BC-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-827FB448E656EC26/Mac-827FB448E656EC26-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-937A206F2EE63C01/Mac-937A206F2EE63C01-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-E1008331FDC96864/Mac-E1008331FDC96864-B2_2.46.0.12-C1_55.3-R1.bin:active:v55:nvm_v55.3:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-1E7E29AD0135F9BC/Mac-1E7E29AD0135F9BC-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-827FB448E656EC26/Mac-827FB448E656EC26-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-937A206F2EE63C01/Mac-937A206F2EE63C01-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-A61BADE1FDAD7B05/Mac-A61BADE1FDAD7B05-B2_2.51.0.14-C1_56.1-R1.bin:active:v56:nvm_v56.1:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-E1008331FDC96864/Mac-E1008331FDC96864-B2_2.46.0.12-C1_55.3-R1.bin:active:v55:nvm_v55.3:0x4200

47)
thedrom=db0000000000000000392fa490015800010010000100088180028000000008829001800000000883800480010000088490038001000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0010-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0010-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

48)
thedrom=db0000000000000000656f6bb4015800010011000100088180028000000008829001800000000883800480010000088490038001000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0011-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0011-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

49)
thedrom=db000000000000000081af3ad9015800010012000100088180028000000008829001800000000883800480010000088490038001000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0012-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0012-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

50)
thedrom=db0000000000000000156e5627015800010015000100088180028000000008829001800000000883800480010000088490038001000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0015-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0015-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

51)
thedrom=c801000000000000007b4cd55c015800010016000100088181028100000008829101810000000883810481010000088491038101000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0016-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0016-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

52)
thedrom=db0000000000000000adeec86e015800010017000100088180028000000008829001800000000883800480010000088490038001000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0017-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0017-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

53)
thedrom=c80100000000000000a2b9e0a5015800010018000100088181028100000008829101810000000883810481010000088491038101000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0018-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0018-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

54)
thedrom=db0000000000000000741bfd97015800010019000100088180028000000008829001800000000883800480010000088490038001000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0019-B2_2.46.0.16-C1_55.2.bin:active:v55:nvm_v55.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0019-B2_2.46.0.16-C1_55.2.bin:active:v55:nvm_v55.2:0x4200

55)
thedrom=c801000000000000001a397eec01580001001a000100088181028100000008829101810000000883810481010000088491038101000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x001A-B2_2.46.0.16-C1_55.2.bin:active:v55:nvm_v55.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x001A-B2_2.46.0.16-C1_55.2.bin:active:v55:nvm_v55.2:0x4200

56)
thedrom=7f01000000001001006d66283501090001000c000100
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-551B86E5744E2388/Mac-551B86E5744E2388-C0_5.90.0-C0_41.4-R1.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-66E35819EE2D0D05/Mac-66E35819EE2D0D05-B0_13.38.0-C0_41.2-R1.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-7BA5B2D9E42DDD94/Mac-7BA5B2D9E42DDD94-C0_16.0.0-C0_41.4-R1.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-7BA5B2DFE22DDD8C/Mac-7BA5B2DFE22DDD8C-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-A5C67F76ED83108C/Mac-A5C67F76ED83108C-B0_13.38.0-C0_41.2-R1.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-CAD6701F7CEA0921/Mac-CAD6701F7CEA0921-C0_5.90.0-C0_41.4-R1.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-551B86E5744E2388/Mac-551B86E5744E2388-C0_5.90.0-C0_41.4-R1.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-66E35819EE2D0D05/Mac-66E35819EE2D0D05-B0_13.38.0-C0_41.2-R1.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-7BA5B2D9E42DDD94/Mac-7BA5B2D9E42DDD94-C0_16.0.0-C0_41.4-R1.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-7BA5B2DFE22DDD8C/Mac-7BA5B2DFE22DDD8C-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-A5C67F76ED83108C/Mac-A5C67F76ED83108C-B0_13.38.0-C0_41.2-R1.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-CAD6701F7CEA0921/Mac-CAD6701F7CEA0921-C0_5.90.0-C0_41.4-R1.bin:active:v41:nvm_v41.4:0x4200
Click to expand...
[automerge]1593955482[/automerge]
Try to Flash your titan with my original one I have backup in case of It was a 23 original firmware for the blue and green

I have flashed mine on the blue chip with the DSM V2 firmware


Attachments

  • Original Firmware.zip
    378.2 KB · Views: 175
Executor

Executor

macrumors regular
Mar 1, 2008
158
167
NYC
c0c0p0ps said:
Version 1 and 4 are the same - the original DSM2 firmwares.
2, 3, 5, 6 are all patched by Elias64 and CaseySJ from the tonymac hackintosh site (search for thunderbolt DROM micro-guide)

2 is similar to the DSM2 firmware based on firmware NVM23 which was what also worked with the windows warm boot for the titan ridge AIC. This firmware works best of the AIC versions.

5 is a patched version of the later NVM43 firmware that was released on newer titan ridge cards. It is not nearly as functional as the NVM23 release. There is also a patched version of the newest NVM50 firmware for testing but not working as well as others still.

3, 6 are both patched versions of NVM33 taken from the onboard titan ridge controller in a gigabyte designaire motherboard. Having tested all firmwares on my titan ridge AIC this is the best of them all by a long way. Both thunderbolt ports work with hot plug (complex devices that requires macOS to load drivers will still require a warm reboot) and others have reported that the display passthrough works best on this version as well.

Right now I have left my titan ridge card on this patched NVM33 firmware (3 on your list) and would recommend it over the others. USB C drives correctly work and I have no header or power cables plugged into the card either and these didn't for me on NVM23.

Properly configuring the SSDT is extremely important as well, and with a customised DROM added will enable full Thunderbolt network bridge.
Click to expand...

Thank you for the explanation of the different firmware. What SSDT file do you use in conjunction with your firmware?

F

Fred4

macrumors newbie
Feb 21, 2020
16
0
joevt said:
My script at https://gist.github.com/joevt/4f6d4d97b560efab9603ac509bf00122 will tell you the version numbers in a firmware file. I think I need to fix output for multi digit decimal versions though. Maybe later.

Code:
source /Volumes/Work/Programming/ThunderboltProjects/Scripts/ThunderboltUtil.sh

IFS=$'\n'
for thebin in $(find /Volumes/Work/Programming/ThunderboltProjects/Notes -type f -name '*.bin'); do
    loadfwfile "$thebin"
done 2>&1

listdroms

1)
thedrom=71000000000000ed00e0403498016900ed0008c0010108818002800000000882900180000000088380048001000008849003800100000585500000058650000002c70b88200100640000000000038980058a504000058b5040000b0147494741425954450011025a3339302044455349474e415245000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2062432/Gigabyte-Z390-Designare-TB3-ROM.bin:active:v33:nvm_v33.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/DESIGNARE-Z390-NVM33-Elias64Fr.bin:active:v33:nvm_v33.0:0x4200

2)
thedrom=6c0000000000100100d5cc6de801090001000d000100
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2062504/Mac-AA95B1DDAB278B95-C0_6.90.0-C1_47.1-R0.bin:active:v47:nvm_v47.1:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-1E7E29AD0135F9BC/Mac-1E7E29AD0135F9BC-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-226CB3C6A851A671/Mac-226CB3C6A851A671-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-53FDB3D8DB8CA971/Mac-53FDB3D8DB8CA971-B2_2.32.0.10-C1_51.1-R0.bin:active:v51:nvm_v51.1:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-63001698E7A34814/Mac-63001698E7A34814-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-827FAC58A8FDFA22/Mac-827FAC58A8FDFA22-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-827FB448E656EC26/Mac-827FB448E656EC26-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-937A206F2EE63C01/Mac-937A206F2EE63C01-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-AA95B1DDAB278B95/Mac-AA95B1DDAB278B95-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-E1008331FDC96864/Mac-E1008331FDC96864-B2_2.46.0.12-C1_55.3-R0.bin:active:v55:nvm_v55.3:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-E7203C0F68AA0004/Mac-E7203C0F68AA0004-B2_2.32.0.11-C1_51.2-R0.bin:active:v51:nvm_v51.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-1E7E29AD0135F9BC/Mac-1E7E29AD0135F9BC-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-226CB3C6A851A671/Mac-226CB3C6A851A671-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-53FDB3D8DB8CA971/Mac-53FDB3D8DB8CA971-B2_2.32.0.10-C1_51.1-R0.bin:active:v51:nvm_v51.1:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-63001698E7A34814/Mac-63001698E7A34814-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-827FAC58A8FDFA22/Mac-827FAC58A8FDFA22-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-827FB448E656EC26/Mac-827FB448E656EC26-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-937A206F2EE63C01/Mac-937A206F2EE63C01-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-A61BADE1FDAD7B05/Mac-A61BADE1FDAD7B05-B2_2.51.0.14-C1_56.1-R0.bin:active:v56:nvm_v56.1:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-AA95B1DDAB278B95/Mac-AA95B1DDAB278B95-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-E1008331FDC96864/Mac-E1008331FDC96864-B2_2.46.0.12-C1_55.3-R0.bin:active:v55:nvm_v55.3:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-E7203C0F68AA0004/Mac-E7203C0F68AA0004-B2_2.32.0.11-C1_51.2-R0.bin:active:v51:nvm_v51.2:0x4200

3)
thedrom=9a0000000000008680dc30485301650086803412010108818002800000000882900180000000088380048001000008849003800100000585500000058650000002c70b88200100640000000000038980058a500000058b50000009014153524f434b000f02583537302043726561746f72000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2065495/ASDRock-X570-Creator-MXIC-25L8006E-TB3.bin:active:v45:nvm_v45.0:0x4200

4)
thedrom=71000000000000ed00d9f6c7e2016900ed0007a2010108818002800000000882900180000000088380048001000008849003800100000585500000058650000002c70b88200100640000000000038980058a504000058b5040000b01474947414259544500110247432d544954414e205249444745000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2085204/TitanRidgeNVM23Original.bin:active:v23:nvm_v23.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2085293/TitanRidgeNVM43Patched.bin:inactive:v43:nvm_v43.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2085293/TitanRidgeNVM43Patched.bin:active:v43:nvm_v43.0:0x82200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/GC-TITAN-RIDGE-NVM23-Elias64Fr.bin:active:v23:nvm_v23.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/0-0GC-TITAN RIDGE#1.bin:linux:v23:nvm_v23.0:0x200
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/0-1GC-TITAN RIDGE#2.bin:linux:v23:nvm_v23.0:0x200

5)
thedrom=7500000000000049185fa466a90149004918040066020881800280000000088280028000000002830b842001003c0000000000058550000009014153526f636b0015025a3337302047616d696e672d4954582f6163000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2085799/ASRock_z390_itx_new.bin:active:v14:nvm_v14.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/ASROCK_Z390_ITX_NVM20_MOD-Elias64Fr.bin:inactive:v14:nvm_v14.0:0x4200

6)
thedrom=7500000000000049187420312b0151004918040066040881800280000000088280028000000002830b842001003c0000000000058550000009014153526f636b001d025a333930205068616e746f6d2047616d696e672d4954582f6163000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/ASROCK_Z390_ITX_NVM20_MOD-Elias64Fr.bin:active:v20:nvm_v20.0:0x82200

7)
thedrom=370000000000003100cbd78eae025d00310011110101088180028000000008829001800000000883800480010000088490038001000002c50b8620010064000000000003878002c802c9058a50000002cb0701415355530012025448554e444552424f4c5445582033000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/ASUS-THUNDERBOLT-EX-3/AlpineRidgeEX3-NVM18-NATA.bin:active:v18:nvm_v18.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/ASUS-THUNDERBOLT-EX-3/AlpineRidgeEX3-NVM18-NATA.bin:inactive:v18:nvm_v18.0:0x82200

8)
thedrom=37000000000000310099debb9b0156003100555501010881800280000000088290018000000002c302c402c50b8620010064000000000003878005885040000589500000058a50000002cb0701415355530011025448554e444552424f4c54455833000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/ASUS-THUNDERBOLT-EX-3/AlpineRidgeEX3-NVM26-NATA.bin:active:v26:nvm_v26.412:0x4200

9)
thedrom=370000000000003100340ee524015e00310041600121088180028000000008829001800000000883800480010000088490038001000002c50b8620010064000000000003878005885000000589500000058a500000058b500000070141535553000a0255583535304744000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/ASUS-UX550-NVM33-Elias64Fr.bin:active:v33:nvm_v33.2404:0x4200

10)
thedrom=71000000000000ed001e00a616016a00ed0019c00201088180028000000008829001800000000883800480010000088490038001000002c50b8620010064000000000003878005885040000589500000058a500000058b5040000b01474947414259544500120247432d414c50494e45205249444745000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/GC-ALPINE RIDGE-NVM20-V1-Elias64Fr.bin:active:v20:nvm_v20.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/GC-ALPINE-RIDGE-NVM20-V2-Elias64Fr.bin:active:v20:nvm_v20.0:0x4200

11)
thedrom=71000000000000ed001a032aba026700ed0019800201088180028000000008829001800000000883800480010000088490038001000002c50b86200100640000000000038780058850400002c9058a500000058b5040000b01474947414259544500120247432d414c50494e45205249444745000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/GC-ALPINE RIDGE-NVM21-V3-NATA.bin:inactive:v21:nvm_v21.0:0x4200

12)
thedrom=9a0000000000008680870a975e016400868073200121088180028000000008829001800000000883800480010000088490038001000002c50b8620010064000000000003878005885000000589500000058a500000058b5000000801496e74656c000f0248616465732043616e796f6e000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/GC-ALPINE RIDGE-NVM21-V3-NATA.bin:active:v33:nvm_v33.0:0x82200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/NUC8i7HNK/NUC8i7HNKpatched.bin:active:v41:nvm_v41.3:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/NUC8i7HNK/NUC8i7HNKpatched.bin:inactive:v33:nvm_v33.0:0x82200

13)
thedrom=71000000000000ed009a1ec570016800ed000dc0010208818002800000000882900180000000088380048001000008849003800100000585500000058650000002c70b88200100640000000000038980058a504000058b5040000b0147494741425954450010025a34393020564953494f4e2044000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/Gigabyte-Vision-D-NVM-50-Elias64Fr-CaseySJ.bin:active:v50:nvm_v50.0:0x4200

14)
thedrom=71000000000000ed0032d4d58d016c00ed0007c0010108818002800000000882900180000000088380048001000008849003800100000585500000058650000002c70b88200100640000000000038980058a504000058b5040000b0147494741425954450014025a3339302041524f555320585452454d45000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/[SUCCESS] Gigabyte Designare Z390 (Thunderbolt 3) + i7-9700K + AMD RX 580/post-2087524/Repository of Patched Firmware Files/Z390-AORUS-XTREME-NVM33-Elias64Fr.bin:active:v33:nvm_v33.0:0x4200

15)
thedrom=9500000000000041008c6b38dd015c0041000d030101088180028000000008829001800000000883800480010000088490038001000002c50b86200180dc0000000000038780058850000002c902ca058b5000000901414b6954694f000c024e6f6465204c697465000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Node Lite [B1-25 15W]/AKiTiO T3 NodeLite Update Tool_v1.0.0.5_C1-35+4.51(16.2)/00/FwUpdateTool.FwBin.AKiTiO_T3_NodeLite_rev35_Ti_v451_20180820_SEC1_sign.bin:active:v35:nvm_v35.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Node Lite [B1-25 15W]/AKiTiO T3 NodeLite Update Tool_v1.0.0.5_C1-35+4.51(16.3)/00/FwUpdateTool.FwBin.AKiTiO_T3_NodeLite_rev35_Ti_v451_20180820_SEC1_sign.bin:active:v35:nvm_v35.0:0x4200

16)
thedrom=9500000000000041008263c8b101620041000e030101088180028000000008829001800000000883800480010000088490038001000002c50b86200100a00000000000038780058850400002c902ca058b5040000901414b6954694f0012025468756e6465723320517561642058000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Node Lite [B1-25 15W]/AKiTiO T3 NodeLite Update Tool_v1.0.0.5_C1-35+4.51(16.2)/01/FwUpdateTool.FwBin.AKiTiO_T3_QuadX_C0_23_w_TI_v4p43_SEC1_sign.bin:active:v23:nvm_v23.4304:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Node Lite [B1-25 15W]/AKiTiO T3 NodeLite Update Tool_v1.0.0.5_C1-35+4.51(16.3)/01/FwUpdateTool.FwBin.AKiTiO_T3_QuadX_C0_23_w_TI_v4p43_SEC1_sign.bin:active:v23:nvm_v23.4304:0x4200

17)
thedrom=950000000000004100bdd46443026b00410001030101088180028000000008829001800000000883800480010000088490038001000002c50b86200100500000000000038780058850400002c902ca058b5040000a01696e5874726f6e001a02414b6954694f205468756e646572332044756f2050726f000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.0.5_B1-25+4.33/00/FwUpdateTool.FwBin.AKiTiO_T3_Node_rev23_TI83_20170103_SEC1_sign.bin:active:v18:nvm_v18.7601:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.04_B1-25+4.33/00/FwUpdateTool.FwBin.AKiTiO_T3_Node_rev23_TI83_20170103_SEC1_sign.bin:active:v18:nvm_v18.7601:0x4200

18)
thedrom=9500000000000041005c207c3d024c004100080301010881800280000000088290018000000002c302c402c50b86200100dc000000000002c702c802c902ca02cb0a01696e5874726f6e000e02414b6954694f204e6f6465000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.0.5_B1-25+4.33/01/FwUpdateTool.FwBin.AKiTiO_T3_Node_rev25_Ti4_33_20170406_SEC1_sign.bin:active:v21:nvm_v21.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.04_B1-25+4.33/01/FwUpdateTool.FwBin.AKiTiO_T3_Node_rev25_Ti4_33_20170406_SEC1_sign.bin:active:v21:nvm_v21.0:0x4200

19)
thedrom=950000000000004100de0a8918014d004100080301010881800280000000088290018000000002c302c402c50b86200100dc000000000003878002c802c902ca02cb0a01696e5874726f6e000e02414b6954694f204e6f6465000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.0.5_B1-25+4.33/02/FwUpdateTool.FwBin.AKiTiO_T3_Node_rev21_10262016_SEC1_sign.bin:active:v23:nvm_v23.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.0.5_B1-25+4.33/03/FwUpdateTool.FwBin.AKiTiO_T3_PCIeBox_rev19_TI176_SEC1_sign.bin:active:v25:nvm_v25.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.04_B1-25+4.33/02/FwUpdateTool.FwBin.AKiTiO_T3_Node_rev21_10262016_SEC1_sign.bin:active:v23:nvm_v23.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.04_B1-25+4.33/04/FwUpdateTool.FwBin.AKiTiO_T3_DP_rev18_Ti176_SEC1_sign.bin:active:v25:nvm_v25.0:0x4200

20)
thedrom=9500000000000041001147c933026c00410005030101088180028000000008829001800000000883800480010000088490038001000002c50b86200100400100000000038780058850400002c902ca058b5040000a01696e5874726f6e001b02414b6954694f205468756e64657233205043496520426f78000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.0.5_B1-25+4.33/04/FwUpdateTool.FwBin.AKiTiO_T3_DP_rev18_Ti176_SEC1_sign.bin:active:v19:nvm_v19.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/AKiTiO/Thunder3, Node [25.1 15W]/AKiTiO T3 Node Update Tool_v1.0.04_B1-25+4.33/03/FwUpdateTool.FwBin.AKiTiO_T3_PCIeBox_rev19_TI176_SEC1_sign.bin:active:v19:nvm_v19.0:0x4200

21)
thedrom=370000000000003100b4c9bba70154003100056001010881800280000000088290018000000002c302c402c50b86200100dc000000000003878002c802c902ca02cb0701415355530018024153555320524f472058472053746174696f6e2032000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/ASUS/ROG XG Station 2 [v25 100W]/ASUS-ROG-XG-STATION-2_V25/ASUS_ROG_XG_Station_2_AR_EP_4C_B1_rev25_W_TI_4_3_3_NO_MOD_SEC1_sign_0419.bin:active:v25:nvm_v25.4300:0x4200

22)
thedrom=3700000000000031007123b8480150003100076001010881800280000000088290018000000002c302c402c50b86200100dc000000000003878002c802c902ca02cb0a014153555354656b00110258472053544154494f4e2050524f000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/ASUS/XG Station Pro [29.1 15W]/TBT FW V1.6/ASUS_XGPro_AR_EP_4C_C1_rev29_W_Ti_rev4_45_SEC1_sign.bin:active:v29:nvm_v29.4504:0x4200

23)
thedrom=8f0000000000000400a0067618016d00040053a1010408818002800000000882900180000000088380048001000008849003800100000585090100058609010002c70b8820010064000000000003898002ca02cb02cc02cd1401426c61636b6d616769632044657369676e000b02654750552050726f000308080000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Blackmagic/Blackmagic eGPU Firmware Updater Folder/Blackmagic_eGPU_Firmware Folder/Library/ThunderboltAccessoryFirmwareUpdates/BlackmagicDesign/Blackmagic_eGPU_Pro_Thunderbolt.bin:active:v50:nvm_v50.0:0x4200

24)
thedrom=8f0000000000000400fbce3264016e000400ffa1010308818002800000000882900180000000088380048001000008849003800100000585090100058609010002c70b8820010064000000000003898002ca02cb02cc02cd1401426c61636b6d616769632044657369676e000f026547505520525835383000030000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Blackmagic/Blackmagic eGPU Firmware Updater Folder/Blackmagic_eGPU_Firmware Folder/Library/ThunderboltAccessoryFirmwareUpdates/BlackmagicDesign/Blackmagic_eGPU_Thunderbolt.bin:active:v50:nvm_v50.0:0x4200

25)
thedrom=71000000000000ed00cf231640014d00ed0009b0011b0881800280000000088290018000000002c302c402c50b86200100dc000000000003878002c802c902ca02cb0b014749474142595445000d0247414d494e4720424f58000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Gigabyte/1st gen Gaming Box [F1.0 H2D 100W]/[Thunderbolt firmware] Default version. Achieve great balance between USB bandwidth and graphics performance/Gigabyte_RX580IXEB_8GD_Ver1.0/Gigabyte_RX580IXEB_8GD_Ver1.0.bin:active:v27:nvm_v27.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Gigabyte/1st gen Gaming Box [F1.0 H2D 100W]/[Thunderbolt firmware] Improve Host to Device bandwidth/Gigabyte_RX580IXEB_8GD_Ver1.0 H2D/Gigabyte_RX580IXEB_8GD_Ver1.0 H2D.bin:active:v27:nvm_v27.0:0x4200

26)
thedrom=cf000000000000f000aa8ceaad014f00f000660a01190881800280000000088290018000000002c302c402c50b86200100dc000000000003878002c802c902ca02cb050148500015024741312d31302d416363656c657261746f72000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/HP/OMEN Accelerator [25.25 60W]/SP86866/TB3FW/HP_GA1_10_Accelerator_Shiva_AR_EP_A68_B1_rev25_W_TI83B_020_25_SEC1_sign.bin:active:v25:nvm_v25.2000:0x4200

27)
thedrom=740000000000000801367d82f901520008010417011a0881800280000000088290018000000002c302c402c50b8620010064000000000003878002c80589500000058a50000002cb09014c656e6f766f000e02373230732d3133494b4252000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Lenovo/TB3 Graphics Dock [v003 65W]/thunderbolt_firmware_201712/720SIKBRTBTFWUpdateV03/Debug/Lenovo_720s13_KBLR_AR_HR_2C_C0_rev26_Native_SEC1_sign.bin:active:v26:nvm_v26.0:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Lenovo/TB3 Graphics Dock [v003 65W]/thunderbolt_firmware_201712/Thunderbolt Firmware Update/Debug/Lenovo_720s13_KBLR_AR_HR_2C_C0_rev26_Native_SEC1_sign.bin:active:v26:nvm_v26.0:0x4200

28)
thedrom=a40000000000002e0178b736130160002e0158e314290881800280000000088290018000000002c302c402c50b86200100dc000000000003878002c802c902ca02cb1e01534150504849524520544543484e4f4c4f4759204c494d49544544000a0247656172426f78000307010000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/Sapphire/Gearbox [41.41 60W]/SAPPHIRE_GearBox_H2D_v2/SAPPHIRE_GearBox_H2D.bin:active:v41:nvm_v41.5504:0x4200

29)
thedrom=8100000000000068015fd5786d01470068010550010102c102c20883800480010000088490038001000002c50b86200100dc000000000003878002c802c902ca02cb060154554c000c025442582d3535304341000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/Mantiz Venus [25.1 87W]/Mantiz-H2D87W.bin:active:v25:nvm_v25.3304:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/04/FwUpdateTool.FwBin.TUL_TBX_550CA_AR_EP_A68_B1_rev25_W_TI83_4p33_SEC1_sign_NO_MOD_20170710_sign.bin:active:v25:nvm_v25.3304:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/05/FwUpdateTool.FwBin.TUL_DEVIL_BOX_V10_AR_EP_A68_B1_rev25_TI_361_20171003_101_SEC1_sign.bin:active:v25:nvm_v25.3304:0x4200

30)
thedrom=810000000000006801a020894101470068016923010202c102c20883800480010000088490038001000002c50b86200100dc000000000003878002c802c902ca02cb060154554c000c02444556494c20424f58000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/00/FwUpdateTool.FwBin.TUL_DSL6540B_V02_A68_C0_V15_tps65983_Intel_Apex_Creek_CH_2_12_P45W_20170103_001.bin:active:v23:nvm_v23.6103:0x4200

31)
thedrom=810000000000006801a65fcc69014c006801035001010881800280000000088290018000000002c302c402c50b86200100640000000000038780058850400002c902ca058b504000060154554c000b0244534c3635343042000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/01/FwUpdateTool.FwBin.TUL_DSL6540B_V02_A68_C0_V14_tps65983_Intel_Apex_Creek_CH_2_12_PD45W_20161213_001.bin:active:v14:nvm_v14.6103:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/02/FwUpdateTool.FwBin.TUL_DSL6540_V10_A68_B1_V23_tps65983_Intel_Apex_Creek_2_10_PD60W_20170125_101.bin:active:v15:nvm_v15.6103:0x4200

32)
thedrom=8100000000000068019eb04ec901470068016923010102c102c20883800480010000088490038001000002c50b86200100dc000000000003878002c802c902ca02cb060154554c000c02444556494c20424f58000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/03/FwUpdateTool.FwBin.TUL_TBX_550CA_AR_EP_A68_B1_rev25_W_TI83_4p33_SEC1_sign_20170605.bin:active:v23:nvm_v23.6103:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/PowerColor Devil Box [25.101 60W]/FwUpdateTool_TUL_DEVIL_BOX_Rev25_20171003_101_SEC1/06/FwUpdateTool.FwBin.TUL_DEVIL_BOX_V10_AR_EP_A68_B1_rev23_TI_361_SEC1_relaxing_eGFX_sign.bin:active:v25:nvm_v25.6103:0x4200

33)
thedrom=73000000000000080041b846f401760008003700010102c102c20883800480010000088490038001000002c50b86200100dc000000000003878002c802c902ca058b5000001c01536f6e6e657420546563686e6f6c6f676965732c20496e632e002202427265616b6177617920426f7820446576656c6f7065722045646974696f6e000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/eGPU firmwares/TUL/Sonnet Breakaway Box [25.1 DE 60W]/Sonnet_Breakaway_Box_Developer_Edition_AR_EP_A68_B1_rev25_W_TI83_3p61_SEC1_sign.bin:active:v25:nvm_v25.6103:0x4200

34)
thedrom=71000000000000ed00c4311795025400ed000b8002010881800280000000088290018000000002c302c402c50b8620010064000000000003878002c802c9058a50000002cb0b01474947414259544500110247412d5a3137302d47414d494e47000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuGigaMac/0-0 GIGABYTE GA-Z170-GAMING.bin:linux:v21:nvm_v21.0:0x200

35)
thedrom=550000000000005a00bbc044b90162005a0016de0101088180028000000008829001800000000883800480010000088490038001000002c50b86200100dc0000000000038780058850400002c902ca058b50400006014f57430015025468756e646572626f6c74203320446f636b000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuGigaMac/0-1_OWC Thunderbolt 3 Dock.bin:linux:v20:nvm_v20.9342:0x200

36)
thedrom=cf000000000000f000bee33fc7016d00f00067040102088180028000000008829001800000000883800480010000088490038001000002c502c602c70b88200100640000000000038980058a504000058b5040000a01485020496e632e0019024850205468756e646572626f6c7420446f636b204732000308080000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuGigaMac/0-301_HP Thunderbolt Dock G2.bin:linux:v19:nvm_v19.ec03:0x200

37)
thedrom=550000000000005a00eed74ba8016c005a0013de0101088180028000000008829001800000000883800480010000088490038001000002c50b86200100dc0000000000038780058850400002c902ca058b50400018014f7468657220576f726c6420436f6d707574696e67000d0248656c696f7320544233000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacBookPro/0-101_active1 OWC Heliios 3.bin:linux:v25:nvm_v25.6103:0x200

38)
thedrom=7300000000000008000a99c267017a00080043000101088180028000000008829001800000000883800480010000088490038001000002c50b86200100dc0000000000038780058850000002c902ca058b5000001c01536f6e6e657420546563686e6f6c6f676965732c20496e632e0017024563686f20457870726573732053454c20544233000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacBookPro/0-1_active0 Sonnet Echo Express SEL.bin:linux:v34:nvm_v34.100:0x200

39)
thedrom=730000000000000800bf0d0e6e027b00080024000101088180028000000008829001800000000883800480010000088490038001000002c50b86200100dc0000000000038780058850000002c902ca058b5000001c01536f6e6e657420546563686e6f6c6f676965732c20496e632e0018024563686f20457870726573732053452d4920544233000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacBookPro/30101_active2 Sonnet Echo Express SE-I.bin:linux:v21:nvm_v21.6103:0x200

40)
thedrom=6c00000000001001006d66283501090001000c000100
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacMini/active_Trebleet.bin:linux:v47:nvm_v47.4:0x200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-473D31EABEB93F9B/Mac-473D31EABEB93F9B-B0_13.38.0-C0_41.2-R0.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-4B682C642B45593E/Mac-4B682C642B45593E-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-551B86E5744E2388/Mac-551B86E5744E2388-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-66E35819EE2D0D05/Mac-66E35819EE2D0D05-B0_13.38.0-C0_41.2-R0.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-77F17D7DA9285301/Mac-77F17D7DA9285301-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-7BA5B2D9E42DDD94/Mac-7BA5B2D9E42DDD94-C0_16.0.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-7BA5B2DFE22DDD8C/Mac-7BA5B2DFE22DDD8C-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-A5C67F76ED83108C/Mac-A5C67F76ED83108C-B0_13.38.0-C0_41.2-R0.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-B4831CEBD52A0C4C/Mac-B4831CEBD52A0C4C-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-BE088AF8C5EB4FA2/Mac-BE088AF8C5EB4FA2-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-CAD6701F7CEA0921/Mac-CAD6701F7CEA0921-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-473D31EABEB93F9B/Mac-473D31EABEB93F9B-B0_13.38.0-C0_41.2-R0.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-4B682C642B45593E/Mac-4B682C642B45593E-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-551B86E5744E2388/Mac-551B86E5744E2388-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-66E35819EE2D0D05/Mac-66E35819EE2D0D05-B0_13.38.0-C0_41.2-R0.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-77F17D7DA9285301/Mac-77F17D7DA9285301-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-7BA5B2D9E42DDD94/Mac-7BA5B2D9E42DDD94-C0_16.0.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-7BA5B2DFE22DDD8C/Mac-7BA5B2DFE22DDD8C-C0_16.0.0-C1_47.4-R0.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-A5C67F76ED83108C/Mac-A5C67F76ED83108C-B0_13.38.0-C0_41.2-R0.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-B4831CEBD52A0C4C/Mac-B4831CEBD52A0C4C-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-BE088AF8C5EB4FA2/Mac-BE088AF8C5EB4FA2-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-CAD6701F7CEA0921/Mac-CAD6701F7CEA0921-C0_5.90.0-C0_41.4-R0.bin:active:v41:nvm_v41.4:0x4200

41)
thedrom=ed0000000000006f00a0536d500256006f0001020101088180028000000008829001800000000883800480010000088490038001000002c502c602c7058850400002c902ca058b5040000f0153746172746563682e636f6d000a0254423332445032000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/0-1TB32DP2.bin:linux:v18:nvm_v18.0:0x200

42)
thedrom=ed0000000000006f0081850c9d0256006f0000020101088180028000000008829001800000000883800480010000088490038001000002c502c602c7058850400002c902ca058b5040000f0153746172746563682e636f6d000a0254423332484432000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/0-1TB32HD2.bin:linux:v18:nvm_v18.0:0x200

43)
thedrom=7a000000000000bd01be9c3676016500bd01210a01010881800280000000088290018000000002c302c402c502c602c70b88200100640000000000038980058a504000058b5040001e0157696e737461727320546563686e6f676f6c79204c696d69746564000902555441323144000308080000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/1-1 Winstar UTA21D.bin:linux:v36:nvm_v36.4306:0x200

44)
thedrom=7300000000000008009f25f48f017a00080031000101088180028000000008829001800000000883800480010000088490038001000002c50b86200100dc0000000000038780058850000002c902ca058b5000001c01536f6e6e657420546563686e6f6c6f676965732c20496e632e0017024563686f20457870726573732049494920544233000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/1-103Sonnet Echo Express III D.bin:linux:v25:nvm_v25.100:0x200

45)
thedrom=ad100000000000868064963b59006b00410001030101088180028000000008829001800000000883800480010000088490038001000002c50b86600100500000000000038780058850000002c902ca058b5000000a01696e5874726f6e001a02414b6954694f205468756e646572332044756f2050726f000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/UbuntuMacPro/1-3AKiTiO_Thunder3 Duo Pro.bin:linux:v16:nvm_v1.0:0x200

46)
thedrom=7f0100000000100100d5cc6de801090001000d000100
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-1E7E29AD0135F9BC/Mac-1E7E29AD0135F9BC-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-827FB448E656EC26/Mac-827FB448E656EC26-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-937A206F2EE63C01/Mac-937A206F2EE63C01-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-E1008331FDC96864/Mac-E1008331FDC96864-B2_2.46.0.12-C1_55.3-R1.bin:active:v55:nvm_v55.3:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-1E7E29AD0135F9BC/Mac-1E7E29AD0135F9BC-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-827FB448E656EC26/Mac-827FB448E656EC26-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-937A206F2EE63C01/Mac-937A206F2EE63C01-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-A61BADE1FDAD7B05/Mac-A61BADE1FDAD7B05-B2_2.51.0.14-C1_56.1-R1.bin:active:v56:nvm_v56.1:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-E1008331FDC96864/Mac-E1008331FDC96864-B2_2.46.0.12-C1_55.3-R1.bin:active:v55:nvm_v55.3:0x4200

47)
thedrom=db0000000000000000392fa490015800010010000100088180028000000008829001800000000883800480010000088490038001000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0010-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0010-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

48)
thedrom=db0000000000000000656f6bb4015800010011000100088180028000000008829001800000000883800480010000088490038001000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0011-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0011-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

49)
thedrom=db000000000000000081af3ad9015800010012000100088180028000000008829001800000000883800480010000088490038001000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0012-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0012-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

50)
thedrom=db0000000000000000156e5627015800010015000100088180028000000008829001800000000883800480010000088490038001000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0015-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0015-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

51)
thedrom=c801000000000000007b4cd55c015800010016000100088181028100000008829101810000000883810481010000088491038101000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0016-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0016-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

52)
thedrom=db0000000000000000adeec86e015800010017000100088180028000000008829001800000000883800480010000088490038001000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0017-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0017-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

53)
thedrom=c80100000000000000a2b9e0a5015800010018000100088181028100000008829101810000000883810481010000088491038101000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0018-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0018-B2_2.29.0.15-C1_49.4.bin:active:v49:nvm_v49.4:0x4200

54)
thedrom=db0000000000000000741bfd97015800010019000100088180028000000008829001800000000883800480010000088490038001000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x0019-B2_2.46.0.16-C1_55.2.bin:active:v55:nvm_v55.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x0019-B2_2.46.0.16-C1_55.2.bin:active:v55:nvm_v55.2:0x4200

55)
thedrom=c801000000000000001a397eec01580001001a000100088181028100000008829101810000000883810481010000088491038101000005850901000586090100028703882003898002ca02cb0d014170706c6520496e632e000c024d6163696e746f7368000000000000000000000000000000000000000000000000000000000000000000
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-27AD2F918AE68F61/Mac-0x001A-B2_2.46.0.16-C1_55.2.bin:active:v55:nvm_v55.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-27AD2F918AE68F61/Mac-0x001A-B2_2.46.0.16-C1_55.2.bin:active:v55:nvm_v55.2:0x4200

56)
thedrom=7f01000000001001006d66283501090001000c000100
sources:
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-551B86E5744E2388/Mac-551B86E5744E2388-C0_5.90.0-C0_41.4-R1.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-66E35819EE2D0D05/Mac-66E35819EE2D0D05-B0_13.38.0-C0_41.2-R1.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-7BA5B2D9E42DDD94/Mac-7BA5B2D9E42DDD94-C0_16.0.0-C0_41.4-R1.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-7BA5B2DFE22DDD8C/Mac-7BA5B2DFE22DDD8C-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-A5C67F76ED83108C/Mac-A5C67F76ED83108C-B0_13.38.0-C0_41.2-R1.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.15.5 /Mac-CAD6701F7CEA0921/Mac-CAD6701F7CEA0921-C0_5.90.0-C0_41.4-R1.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-551B86E5744E2388/Mac-551B86E5744E2388-C0_5.90.0-C0_41.4-R1.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-66E35819EE2D0D05/Mac-66E35819EE2D0D05-B0_13.38.0-C0_41.2-R1.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-7BA5B2D9E42DDD94/Mac-7BA5B2D9E42DDD94-C0_16.0.0-C0_41.4-R1.bin:active:v41:nvm_v41.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-7BA5B2DFE22DDD8C/Mac-7BA5B2DFE22DDD8C-C0_16.0.0-C1_47.4-R1.bin:active:v47:nvm_v47.4:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-A5C67F76ED83108C/Mac-A5C67F76ED83108C-B0_13.38.0-C0_41.2-R1.bin:active:v41:nvm_v41.2:0x4200
/Volumes/Work/Programming/ThunderboltProjects/Notes/USBCUpdater 10.16.0 beta/Mac-CAD6701F7CEA0921/Mac-CAD6701F7CEA0921-C0_5.90.0-C0_41.4-R1.bin:active:v41:nvm_v41.4:0x4200
Click to expand...

Thanks, I am looking through it now, trying to figure it out.
Meanwhile, if you have a copy of a good green chip, or know where one ie, I could really use it. I think my card is too new, and probably has the bad firmware that doesn't work on the Mac. 0.43.

I had looked into my ROMs a bit, and here are my MD5's, and some useful data stamps I found in the files with a hex editor:

Titan Ridge Firmware

Original Backups
Blue (7:543C: 5a8f092c7306c3d9c0764d2f4f132044a8f0cedf_09042017)
MD5 1ea78c1c29a68e2b872a1b40c0e7f6bb

Green (2:8418: a0566aa071c0a0cabf803a9532caee53ddd2ced5_03012018)
MD5 4f2b63bc8392fe87fe2075ca9253c527

New DSM2
Blue (7:441C: 5a8f092c7306c3d9c0764d2f4f132044a8f0cedf_09042017)
MD5 b0805d62b3c94bd70d1cb371b82145bf

F

Fred4

macrumors newbie
Feb 21, 2020
16
0
KevinClark said:
Here is my original Firmware V 23 of my Titan Ridge
Click to expand...
Thanks so much!
That confirms that it's not my problem though. Maybe I have another config issue, or a bad card.
It's weird though, because people are claiming they have theirs working vanilla, no OC, nothing.
I have copied the file into my OC ACPI folder. No change.
I tried to add all the entries from the zip, and killed my OC.
I will go back to trying one entry at a time, after I see if the card works in a windows box.
The MD5 on your green matches mine. "4f2b63bc8392fe87fe2075ca9253c527"
I'm going to have to find a Win machine to test the card on.
I get nothing when I plug into the USB, and system profiler isn't showing my card like other peoples screen shots. Mine looks generic, where others I have seen actually say "Titan Ridge".
I haven't even gotten in to the TB ports, I am just trying to get USB3 to work.
[automerge]1593988275[/automerge]
IndioX said:
here you will find the last 0,23 custom firmware from DSM2

forums.macrumors.com

testing TB3 AIC with MP 5,1

I am still in the Hospital but I just wanted to share with you a new and improved Firmware Version for the Titan Ridge Card. Will start to work on the SSDT stuff as soon as I am back home...
forums.macrumors.com forums.macrumors.com
Click to expand...
Yes, that's the one I flashed, and triple verified.
MD5 b0805d62b3c94bd70d1cb371b82145bf

I was thinking I had a different green, but it's the same as you have.
If USB3 should work with no mods to OC, I must have a bad card.

Last edited:
F

Fred4

macrumors newbie
Feb 21, 2020
16
0
Thanks so much everyone that helped. I was able to verify that my green ROM is the same version, and wasn't the issue. The card is bad. I tried it in a Win10 machine, and nothing....
RMA started, then begin again...

K

KevinClark

macrumors 6502
Feb 28, 2019
349
42
Which firmware is good to use the 2 ports of the titan at the same time

I have flashed with the DSM 23 firmware my titan ridge and when I plug my Apollo and my satellite thunderbolt 2 devices on the same port of the titan I need 2 boots for Apollo to work and 3 boots for my quad satellite
When I plug each device on each port sometimes it works sometimes I have nothing working
I them under Mojave and use no opencore and no windows 10

AppleDrank

AppleDrank

macrumors member
May 15, 2019
36
1
Arizona
Just an FYI - I'm just starting this process. I have a ch341a_spi I bought last week from Amazon, and it's 3.3v here out of the box (see attached photo).

My original MD5s are:

blue

dbfe57aae3e056d7570b6721bf4cef13

green

4f2b63bc8392fe87fe2075ca9253c527

Pasted Graphic 5.png

Manek43509

Manek43509

macrumors member
Aug 21, 2010
45
26
Norwich, UK
Photo 19-07-2020, 12 05 31.jpg


It is done! Excuse my messy desk in the studio, but I wanted to get a picture straight away!

Here we have a 2009 Mac Pro 5,1 driving TWO 27" Thunderbolt displays. Using only one Thunderbolt port out of the TITAN-RIDGE card, and with the two Thunderbolt displays daisychained together. (The third, smaller screen sitting on the desk is a 20" older Cinema Display connected via DVI.)

The ethernet ports built into the back of the Thunderbolt displays still work perfectly in this configuration (I am using the both), but for some reason the USB ports on them don't seem to. (I haven't tested the FireWire ports on the backs of the screens yet, but I am not hopeful.)

There are a few quirks… When you boot from cold, the Thunderbolt displays do not fire up; you have to wait until you reach the login screen and then unplug the Thunderbolt cable from the back of the Mac and plug it back in again, and then all the screens will be fine. Sometimes if you logout and then login on another user account, the desktop backgrounds you set for the Thunderbolt displays will have disappeared and you have to set them again in System Preferences. And as I mentioned, the USB ports on the backs of the displays aren't working.

Overall, it's a workable setup and I'm happy I have got it to this point. But if anyone knows any way of fixing any of the little niggles I have outlined above, do tell!

  • Like
Reactions: EvilMonk, yurc and JedNZ
K

KevinClark

macrumors 6502
Feb 28, 2019
349
42
Which firmware for titan ridge is better i Wanna use the Two ports thunderbolt at the same Time No opencore i have flashed with dsm 23

C

cdf

macrumors 68020
Jul 27, 2012
2,256
2,583
Manek43509 said:
The ethernet ports built into the back of the Thunderbolt displays still work perfectly in this configuration (I am using the both), but for some reason the USB ports on them don't seem to. (I haven't tested the FireWire ports on the backs of the screens yet, but I am not hopeful.)
Click to expand...

To get the USB ports to work you will need to connect the USB header on the CG-TITAN RIDGE card to your Mac Pro. As discussed before here, there are various ways to achieve this. I chose a clean internal approach.

J

joevt

macrumors 604
Jun 21, 2012
6,967
4,262
cdf said:
To get the USB ports to work you will need to connect the USB header on the CG-TITAN RIDGE card to your Mac Pro. As discussed before here, there are various ways to achieve this. I chose a clean internal approach.
Click to expand...
That's only if you want to connect USB 2.0 devices directly to the GC-TITAN RIDGE. USB ports from the Thunderbolt Display are provided from a USB controller in the Thunderbolt Display that is connected by PCIe to the computer via Thunderbolt 2.

It's strange that the Ethernet controller is connected by the USB controller is not. An ioregrestry dump of a properly working Thunderbolt Display (from Thunderbolt 2 Mac) compared to this MacPro5,1 setup might be interesting.

The Ethernet, FireWire, and USB controllers inside the Thunderbolt Display should appear as PCIe devices in System Information.app in the PCI section (connected as Thunderbolt slots).

  • Like
Reactions: cdf
Manek43509

Manek43509

macrumors member
Aug 21, 2010
45
26
Norwich, UK
Interesting! I could try using the USB header on the Thunderbolt card (which I don't believe is connected at the moment), although you would think USB data could simply be passed by Thunderbolt, just as Ethernet data can be… (Or, at least, I would think that!)

Here's how it looks in System Information. Six USB ports (three per screen) labelled as Thunderbolt devices are showing up under the PCI tab.

Screenshot 2020-07-20 at 17.56.43.png

Screenshot 2020-07-20 at 17.58.58.png

J

joevt

macrumors 604
Jun 21, 2012
6,967
4,262
Manek43509 said:
Interesting! I could try using the USB header on the Thunderbolt card (which I don't believe is connected at the moment), although you would think USB data could simply be passed by Thunderbolt, just as Ethernet data can be… (Or, at least, I would think that!)

Here's how it looks in System Information. Six USB ports (three per screen) labelled as Thunderbolt devices are showing up under the PCI tab.
Click to expand...
Those are USB controllers (can't find number of ports from that - need to look at the device in ioreg or look at the datasheet). I'm guessing there's a PCIe switch so that 5 devices can be connected instead of the usual max of 4.

Display 1:
8C:0.0 FireWire (not loaded)
8D:0.0 Ethernet (loaded)
8E:0.0 PCIe Switch upstream
8F:0.0 PCIe Switch downstream
90:0.0 USB OHC (not loaded) PI7C9X440SL or PI7C9X442SL? USB OHCI Controller (low-speed 1.5 Mbps, full-speed 12 Mbps)
90:0.1 USB OHC (not loaded) PI7C9X440SL or PI7C9X442SL? USB OHCI Controller (low-speed 1.5 Mbps, full-speed 12 Mbps)
90:0.2 USB EHC (not loaded) PI7C9X440SL or PI7C9X442SL? USB EHCI Controller (high speed 480 Mbps)

Display 2:
94:0.0 FireWire (not loaded)
95:0.0 Ethernet (loaded)
96:0.0 PCIe Switch upstream
97:0.0 PCIe Switch downstream
98:0.0 USB OHC (not loaded) PI7C9X442SL USB OHCI Controller (low-speed 1.5 Mbps, full-speed 12 Mbps)
98:0.1 USB OHC (not loaded) PI7C9X442SL USB OHCI Controller (low-speed 1.5 Mbps, full-speed 12 Mbps)
98:0.2 USB EHC (not loaded) PI7C9X442SL USB EHCI Controller (high speed 480 Mbps)

Actually, looking at the data sheet of PI7C9X440SL or PI7C9X442SL, it seems that the PCIe switch is part of it and included with the USB 1.1/2.0 controllers.

The controllers are visible to macOS. So the question is why don't the USB drivers load for it? Same for FireWire?

Looking at some kexts from 10.15.5 for different USB controllers and FireWire controller:
Code:
/System/Library/Extensions/IOUSBHostFamily.kext/Contents/PlugIns/AppleUSBUHCIPCI.kext/Contents/Info.plist
    "AppleUSBUHCI" => {
      "IOClass" => "AppleUSBUHCIPCI"
      "IOPCIClassMatch" => "0x0C030000"
      "IOPCITunnelCompatible" => 0
      "IOProviderClass" => "IOPCIDevice"
    }

/System/Library/Extensions/IOUSBHostFamily.kext/Contents/PlugIns/AppleUSBOHCIPCI.kext/Contents/Info.plist
    "AppleUSBOHCIPCI" => {
      "CFBundleIdentifier" => "com.apple.driver.usb.AppleUSBOHCIPCI"
      "IOClass" => "AppleUSBOHCIPCI"
      "IOPCIClassMatch" => "0x0c031000"
      "IOPCITunnelCompatible" => 0
      "IOProviderClass" => "IOPCIDevice"
    }

/System/Library/Extensions/IOUSBHostFamily.kext/Contents/PlugIns/AppleUSBEHCIPCI.kext/Contents/Info.plist
    "AppleUSBEHCIPCI" => {
      "IOClass" => "AppleUSBEHCIPCI"
      "IOPCIClassMatch" => "0x0c032000"
      "IOPCIPauseCompatible" => 1
      "IOPCITunnelCompatible" => 0
      "IOProviderClass" => "IOPCIDevice"
    }
    "AppleUSBEHCIPI7C9X440SL" => {
      "CFBundleIdentifier" => "com.apple.driver.usb.AppleUSBEHCIPCI"
      "IOClass" => "AppleUSBEHCIPI7C9X440SL"
      "IOPCIPauseCompatible" => 1
      "IOPCIPrimaryMatch" => "0x400f12d8"
      "IOPCITunnelCompatible" => 1
      "IOProbeScore" => 1000
      "IOProviderClass" => "IOPCIDevice"
    }
    "ThunderboltDisplay2011" => {
      "CFBundleIdentifier" => "com.apple.driver.AppleUSBHostMergeProperties"
      "IOClass" => "AppleUSBHostMergeProperties"
      "IOProviderClass" => "AppleUSBEHCIPCI"
      "IOProviderMergeProperties" => {
        "kUSBCompanion" => 0
        "kUSBSleepPortCurrentLimit" => 2100
        "kUSBSleepPowerSupply" => 6300
        "kUSBWakePortCurrentLimit" => 2100
        "kUSBWakePowerSupply" => 3700
        "port-count" => {length = 4, bytes = 0x01000000}
        "ports" => {
          "PRT1" => {
            "port" => {length = 4, bytes = 0x01000000}
            "UsbConnector" => 255
          }
        }
      }
      "Tunnel Endpoint Device Model ID" => {length = 4, bytes = 0x02800000}
      "Tunnel Endpoint Device Vendor ID" => {length = 4, bytes = 0x01000000}
    }
  }

/System/Library/Extensions/IOUSBHostFamily.kext/Contents/PlugIns/AppleUSBXHCIPCI.kext/Contents/Info.plist
    "AppleUSBXHCIPCI" => {
      "CFBundleIdentifier" => "com.apple.driver.usb.AppleUSBXHCIPCI"
      "IOClass" => "AppleUSBXHCIPCI"
      "IOPCIClassMatch" => "0x0c033000"
      "IOPCIPauseCompatible" => 1
      "IOPCITunnelCompatible" => 1
      "IOProviderClass" => "IOPCIDevice"
    }

/System/Library/Extensions/IOFireWireFamily.kext/Contents/PlugIns/AppleFWOHCI.kext/Contents/Info.plist
    "AppleFWOHCI,OF" => {
      "CFBundleIdentifier" => "com.apple.driver.AppleFWOHCI"
      "CFBundleVersion" => "5.6.2"
      "IOClass" => "AppleFWOHCI"
      "IONameMatch" => [
        0 => "pciclass,0c0010"
      ]
      "IOPCIPauseCompatible" => 1
      "IOPCITunnelCompatible" => 1
      "IOProbeScore" => 4096
      "IOProviderClass" => "IOPCIDevice"
    }
    "AppleFWOHCI,PCI" => {
      "CFBundleIdentifier" => "com.apple.driver.AppleFWOHCI"
      "CFBundleVersion" => "5.6.2"
      "IOClass" => "AppleFWOHCI"
      "IOPCIClassMatch" => "0x0c001000"
      "IOPCIPauseCompatible" => 1
      "IOPCITunnelCompatible" => 1
      "IOProbeScore" => 4096
      "IOProviderClass" => "IOPCIDevice"
    }

OHCI and EHCI have IOPCITunnelCompatible set to false. That means they can't be used with Thunderbolt? You could try making a codeless kext that has IOPCITunnelCompatible set to true. A codeless kext is a kext with a info.plist that points to the executable of another kext.

There is a "AppleUSBEHCIPI7C9X440SL" which might apply and it has IOPCITunnelCompatible set to true. Maybe it also needs IOPCIPauseCompatible set to true? Or maybe it doesn't match the chip in the Thunderbolt Display.

There is a "ThunderboltDisplay2011" which just adds some USB properties to the Thunderbolt Display's AppleUSBEHCIPCI but that only works if AppleUSBEHCIPCI was loaded?

For FireWire, I don't see a problem so I don't know why it wouldn't load. Maybe you need to connect a device? But the driver loads on my Mac mini 2018 (running 10.15.6) with no FireWire device connected (I have a Thunderbolt 3 dock with the same FireWire controller).

Manek43509

Manek43509

macrumors member
Aug 21, 2010
45
26
Norwich, UK
I haven't actually tried FireWire via the Thunderbolt displays yet. Something to test this week. Bear in mind I haven't gone to 10.15, and both my MacBook Pro and this Cheesegrater are on Mojave (and will be staying there for a while).

  • Like
Reactions: TheStork
J

joevt

macrumors 604
Jun 21, 2012
6,967
4,262
The list of kexts will be similar for Mojave, so you can check the info.plist files of those and compare with what I found.

AppleTomsk

AppleTomsk

macrumors member
Jul 5, 2020
47
26
I read somewhere about a new Titan Ridge Firmware by Dsm2 which is unreleased at the moment,
but cant find any news, maybe you could tell us something about it? @DSM2.Hackintosh

I am planing to build an Hackintosh and think about an Titan Ridge PCIe Card in it.

Last edited:
  • Like
Reactions: pierrox
DSM2.Hackintosh

DSM2.Hackintosh

macrumors regular
Feb 19, 2020
106
295
It will take some more time until I can release the whole thing.
The whole effort was definitely worth it, some EFI problems could be solved, so the card finally works as it should on MacPro5.1.
In the past there were some problems, which can also depend on the used hardware.
Sleep problems were fixed as well as the whole kernel panic story which could occur depending on the hardware.
Lunar will still not work, but here the problem is a lack of CPU features.
I still have to get some more hardware for testing but so far everything looks very good.

The next test will be with an Antelope Studio soundcard, which I have already ordered and will probably be delivered early next week...

Updates will come soon...

PS: By the way... the new firmware version don't need OpenCore or any SSDTs. :)

Last edited:
  • Like
Reactions: pbsxr, Sixtyhorses, Si Vis Pacem and 17 others
DSM2.Hackintosh

DSM2.Hackintosh

macrumors regular
Feb 19, 2020
106
295
Since there were further questions via PM and I have not yet disclosed everything,
I wanted to say more about the whole thing here...

The firmware will not run on the normal Titan Ridge cards...
At least not without modifications of the Thunderbolt card and you can't do this yourself.
The reason is that we have modified the cards outside of the firmware itself.
The plan is to distribute the cards via e-commerce, this means that only ready-made solutions will be sold.
No send in for modifications etc...

PS: Before any company joins in and wants to send me lawyers...
I'm not making money with this cards... I assign all rights to the company that will sell the cards.

Infos will follow up as soon as possible...

Edit: PS: I will send you a card for free @itadampf and one card will be send out to the eGPU.io owner.

Last edited:
  • Like
  • Wow
Reactions: Sixtyhorses, martyr, Si Vis Pacem and 4 others
pottersfield

pottersfield

macrumors newbie
Jan 22, 2020
13
5
DSM2.Hackintosh said:
Since there were further questions via PM and I have not yet disclosed everything,
I wanted to say more about the whole thing here...

The firmware will not run on the normal Titan Ridge cards...
At least not without modifications of the Thunderbolt card and you can't do this yourself.
The reason is that we have modified the cards outside of the firmware itself.
The plan is to distribute the cards via e-commerce, this means that only ready-made solutions will be sold.
No send in for modifications etc...

PS: Before any company joins in and wants to send me lawyers...
I'm not making money with this cards... I assign all rights to the company that will sell the cards.

Infos will follow up as soon as possible...

Edit: PS: I will send you a card for free @itadampf and one card will be send out to the eGPU.io owner.
Click to expand...

Will that require to jumper the cables, or will it work "out-of-the-box" ? do we have to prepare our Macs for this special card, or will you include everything what is needed?

Really stoked to see my MacPro will reveive in the future his last needed upgrade to stay alive for the next decade :)

U

Upnorth^

macrumors newbie
May 30, 2020
2
0
PORTUGAL
DSM2.Hackintosh said:
Since there were further questions via PM and I have not yet disclosed everything,
I wanted to say more about the whole thing here...

The firmware will not run on the normal Titan Ridge cards...
At least not without modifications of the Thunderbolt card and you can't do this yourself.
The reason is that we have modified the cards outside of the firmware itself.
The plan is to distribute the cards via e-commerce, this means that only ready-made solutions will be sold.
No send in for modifications etc...

PS: Before any company joins in and wants to send me lawyers...
I'm not making money with this cards... I assign all rights to the company that will sell the cards.

Infos will follow up as soon as possible...

Edit: PS: I will send you a card for free @itadampf and one card will be send out to the eGPU.io owner.
Click to expand...
Well, I wish I had found this thread/post only today!
From what I understand my titan ridge is going to live in the trash or I will have to scam some uninformed guy on eBay :confused:
Anyway, thank you for all your efforts to make our cMP´s relevant.

Manek43509

Manek43509

macrumors member
Aug 21, 2010
45
26
Norwich, UK
DSM2.Hackintosh said:
Since there were further questions via PM and I have not yet disclosed everything,
I wanted to say more about the whole thing here...

The firmware will not run on the normal Titan Ridge cards...
At least not without modifications of the Thunderbolt card and you can't do this yourself.
The reason is that we have modified the cards outside of the firmware itself.
The plan is to distribute the cards via e-commerce, this means that only ready-made solutions will be sold.
No send in for modifications etc...

PS: Before any company joins in and wants to send me lawyers...
I'm not making money with this cards... I assign all rights to the company that will sell the cards.

Infos will follow up as soon as possible...

Edit: PS: I will send you a card for free @itadampf and one card will be send out to the eGPU.io owner.
Click to expand...
So it will work on already 'flashed' TITAN-RIDGE cards? Or I'll need to buy a new card?

You must log in or register to reply here.
Register on MacRumors! This sidebar will go away, and you'll see fewer ads.
Top Bottom
